IEC 61968-1:2020

Application integration at electric utilities - System interfaces for distribution management - Part 1: Interface architecture and general recommendations

IEC 61968-1:2020 is the first in a series that, taken as a whole, defines interfaces for the major elements of an interface architecture for power system management and associated information exchange.
This document identifies and establishes recommendations for standard interfaces based on an Interface Reference Model (IRM). Subsequent clauses of this document are based on each interface identified in the IRM. This set of standards is limited to the definition of interfaces. They provide for interoperability among different computer systems, platforms, and languages. IEC 61968-100 gives recommendations for methods and technologies to be used to implement functionality conforming to these interfaces.
As used in IEC 61968, distribution management consists of various distributed application components for the utility to manage electrical distribution networks. These capabilities include monitoring and control of equipment for power delivery, management processes to ensure system reliability, voltage management, demand-side management, outage management, work management, network model management, facilities management, and metering. The IRM is specified in Clause 3. The IRM defines the high-level view of the TC 57 reference architecture and the detailed in the relevant 61968 series, 61970 series or 62325 series. The goal of the IRM is to provide a common relevant context view for TC 57 that covers domains like transmission, distribution, market, generation, consumer, regional reliability operators, and regulators.
This third edition cancels and replaces the second edition published in 2012. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
a) update of IRM section, which has been out of date since the 2nd edition;
b) update to IRM model using ArchiMate modelling language;
c) addition of missing business functions and business objects;
d) alignment with newly released documents from the technical committee;
e) alignment with IEC 61968-100;
f) update of annexes.

Intégration d'applications pour les services électriques - Interfaces système pour la gestion de distribution - Partie 1: Architecture des interfaces et recommandations générales

IEC 61968-1:2020 est la première d'une série qui, prise dans son ensemble, définit les interfaces pour les éléments principaux d'une architecture d'interface pour la gestion des systèmes électriques et les échanges d'informations associés.
Le présent document identifie et établit des recommandations pour des interfaces normalisées reposant sur un modèle d'interface de référence (IRM). Les articles suivants de ce document reposent sur chaque interface identifiée dans le modèle IRM. Cet ensemble de normes se limite à la définition des interfaces. Celles-ci assurent l'interopérabilité entre les différents systèmes informatiques, plateformes et langages. L'IEC 61968-100 fournit des recommandations concernant les méthodes et technologies à utiliser pour mettre en œuvre une fonctionnalité conforme à ces interfaces.
Au sens de l'IEC 61968, la gestion de la distribution repose sur plusieurs composants d'application distribués qui permettent à l'entreprise de gérer ses réseaux de distribution électriques. Ces fonctions incluent la surveillance et la commande des équipements de fourniture d'énergie, les processus de gestion qui assurent la fiabilité du système, la gestion de la tension, la gestion de la demande, la gestion des interruptions de service, la gestion des travaux, la gestion des modèles de réseau, la gestion des installations et le comptage. Le modèle IRM est spécifié à l'Article 3. Le modèle IRM définit la vue générale de l'architecture de référence du CE 57 et la vue détaillée dans la série 61968, 61970 ou 62325 pertinente. L'objectif du modèle IRM est de fournir un contexte pertinent commun pour le CE 57 qui couvre différents domaines comme le transport, la distribution, le marché, la production, les consommateurs et les opérations de fiabilité régionales.
Cette troisième édition annule et remplace la deuxième édition parue en 2012. Cette édition constitue une révision technique.
Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) mise à jour du paragraphe traitant du modèle d'interface de référence (IRM) qui était obsolète depuis la deuxième édition;
b) mise à jour du modèle d'interface de référence à l'aide du langage de modélisation ArchiMate;
c) ajout de fonctions métier et d'objets métier manquants;
d) alignement sur les documents du comité d'études récemment publiés;
e) alignement sur le contenu de l'IEC 61968-100;
f) mise à jour des annexes.

General Information

• Status: Published
• Publication Date: 28-Apr-2020
• ICS: 33.060.20 - Receiving and transmitting equipment
• ICS: 33.200 - Telecontrol. Telemetering
• Technical Committee: TC 57 - Power systems management and associated information exchange
• Drafting Committee: WG 14 - TC 57/WG 14
• Current Stage: PPUB - Publication issued
• Start Date: 29-Apr-2020
• Completion Date: 20-Mar-2020

Relations

• Revises: IEC 61968-1:2012 - Application integration at electric utilities - System interfaces for distribution management - Part 1: Interface architecture and general recommendations
• Effective Date: 05-Sep-2023

Overview

IEC 61968-1:2020 is a key international standard developed by the International Electrotechnical Commission (IEC), focusing on application integration at electric utilities. Specifically targeting distribution management systems (DMS), this third edition outlines the system interface architecture and provides general recommendations for interoperability across power distribution networks. It defines a comprehensive Interface Reference Model (IRM) to enable seamless information exchange among heterogeneous utility software applications, platforms, and technologies. As the foundational part of the IEC 61968 series, this edition updates previous models using the ArchiMate modeling language, expands business functions and objects, and aligns with related standards such as IEC 61968-100.

Key Topics

• Interface Reference Model (IRM): Describes a high-level view of system interfaces for electric utility distribution management, covering domains like asset management, customer management, fault management, network operation, and market operations.

• Business Function Standardization: Defines business functions and corresponding business objects for distributed application components in distribution management to ensure consistent data handling and communication.

• Interoperability Framework: Focuses on enabling interoperability between diverse computer systems, platforms, and programming languages by specifying standardized interface profiles and implementation guidelines.

• Information Exchange Model: Covers message structures, compliance philosophy, and data extension methods, ensuring robust and flexible data communication between utility applications.

• Security and Error Handling: Addresses component reporting, error message handling, security, and authentication aspects to maintain system integrity and operational reliability.

• Maintenance and Performance: Discusses ongoing maintenance considerations and performance optimization for inter-application integration in electric utility environments.

Applications

IEC 61968-1:2020 is widely applicable in the electric utility industry for designing, developing, and deploying integrated distribution management systems with interoperable components. Practical applications include:

• Utility System Integration: Facilitates integration of legacy and modern applications managing electric power distribution networks.

• Distribution Network Automation: Supports real-time monitoring, control, and management of distribution grid components to improve reliability and operational efficiency.

• Outage and Fault Management: Enhances coordination between applications responsible for fault detection, isolation, and restoration through standardized data exchanges.

• Demand-Side Management: Enables communication between customer management and network operation systems for better load balancing and energy efficiency initiatives.

• Market and Settlement Operations: Provides a common interface architecture supporting interconnected systems for retail market operation and financial settlements.

• Regulatory Compliance: Aligns electric distribution system interfaces with industry regulations via compliance management functions specified in the IRM.

Related Standards

IEC 61968-1:2020 is part of a broader family of IEC TC 57 standards designed to harmonize electric utility systems and facilitate interoperability:

• IEC 61968 Series: Focuses on system interfaces for distribution management with multiple parts defining specific interfaces and protocols.

• IEC 61970 Series: Addresses energy management system application program interfaces, complementing 61968 in transmission and distribution contexts.

• IEC 62325 Series: Covers standards for electricity market communications, supporting market operations referenced in 61968-1.

• IEC 61968-100: Provides implementation guidelines and recommended technologies for fulfilling the functional requirements of the standardized interfaces.

By adhering to IEC 61968-1:2020 and related standards, electric utilities can achieve more agile, scalable, and interoperable distribution management systems capable of supporting smart grid initiatives and improving operational excellence in power delivery.

---

Keywords: IEC 61968-1, electric utilities, application integration, distribution management system, interface architecture, interoperability, power system management, Interface Reference Model, IEC standards, smart grid, asset management, fault management, network operation, market operation.
