ISO 6148:2001
(Main)Photography — Micrographic films, spools and cores — Dimensions
Photography — Micrographic films, spools and cores — Dimensions
This International Standard provides specifications for _ dimensions (thickness, width, length) of raw stock roll and sheet films for micrographic applications, including silver-gelatin, diazo, and vesicular films, designed for document recording, computer output microfilming (COM), and duplicating or printing. These products require wet chemical, vapour, or heat processing after an image-forming exposure with actinic radiation; _ winding requirements for roll films; _ location and width of the heading area for 105 mm wide rolls and sheets, and the width and thickness of the backing of that area; _ dimensions of spools, made either of metal or plastic, for 16 mm, 35 mm, and 105 mm microfilms; other spool materials are excluded, as well as spools that are integral components of cartridges, cassettes or magazines of microfilm-recording equipment; _ dimensions of plastic and metal cores of 16 mm, 35 mm, and 105 mm widths. Dimensions for thin-walled paper-board cores with wall thickness of 7,6 mm or less, used routinely for sensitized duplicating material, are not included in this International Standard. This International Standard is not applicable to processed-film dimensions in micrographic applications.
Photographie — Films micrographiques, bobines et noyaux — Dimensions
General Information
Relations
Standards Content (Sample)
INTERNATIONAL ISO
STANDARD 6148
Second edition
2001-04-01
Photography — Micrographic films, spools
and cores — Dimensions
Photographie — Films micrographiques, bobines et noyaux — Dimensions
Reference number
ISO 6148:2001(E)
©
ISO 2001
---------------------- Page: 1 ----------------------
ISO 6148:2001(E)
PDF disclaimer
This PDF file may contain embedded typefaces. In accordance with Adobe's licensing policy, this file may be printed or viewed but shall not
be edited unless the typefaces which are embedded are licensed to and installed on the computer performing the editing. In downloading this
file, parties accept therein the responsibility of not infringing Adobe's licensing policy. The ISO Central Secretariat accepts no liability in this
area.
Adobe is a trademark of Adobe Systems Incorporated.
Details of the software products used to create this PDF file can be found in the General Info relative to the file; the PDF-creation parameters
were optimized for printing. Every care has been taken to ensure that the file is suitable for use by ISO member bodies. In the unlikely event
that a problem relating to it is found, please inform the Central Secretariat at the address given below.
© ISO 2001
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronic
or mechanical, including photocopying and microfilm, without permission in writing from either ISO at the address below or ISO's member body
in the country of the requester.
ISO copyright office
Case postale 56 � CH-1211 Geneva 20
Tel. + 41 22 749 01 11
Fax + 41 22 749 09 47
E-mail copyright@iso.ch
Web www.iso.ch
Printed in Switzerland
ii © ISO 2001 – All rights reserved
---------------------- Page: 2 ----------------------
ISO 6148:2001(E)
Contents Page
Foreword.v
Introduction.vi
1 Scope .1
2 Normative references .1
3 Terms and definitions .1
4 Conditions for measurement of dimensions .3
5 Film thickness.3
6 Films in rolls.4
6.1 Width of rolls.4
6.2 Length of rolls.4
6.3 Winding.5
6.4 Splices .5
7 Spools .6
7.1 Dimensions.6
7.2 Preferred design .6
7.3 Offset drive holes.6
7.4 Dimension K .6
7.5 Dimensions J and J .6
1
7.6 Dimension P .6
7.7 Flanges .
...
