SIST EN 16249:2013

Tanks for the transport of dangerous goods - Service equipment - Cap for the adaptor for bottom loading and unloading

This European Standard is applicable to the cap used to provide protection and end closing for the adaptor for bottom loading and unloading of tanks for the transport of dangerous goods. It specifies the performance requirements, critical dimensions and tests necessary to verify the compliance of the equipment with this European Standard.
The equipment specified by this European Standard is suitable for use with liquid petroleum products and other dangerous substances of Class 3 of ADR  ) (flammable liquids) that have a vapour pressure not exceeding 110 kPa at 50 °C, including petrol, and that are not sub-classified as toxic or corrosive.

Tanks für die Beförderung gefährlicher Güter - Bedienungsausrüstung - Kappe für VK-Kupplung für Untenbefüllung und -entladung

Diese Europäische Norm gilt für die Kappe, die als Schutzeinrichtung und Endverschluss für VK-Kupplungen zur Untenbefüllung und  entladung von Tanks für die Beförderung gefährlicher Güter dient, und legt die Leistungs¬anforderungen, kritischen Abmessungen und Prüfungen fest, die zur Verifizierung notwendig sind, ob die Ausrüstung mit der vorliegenden Europäischen Norm übereinstimmt.
Die in dieser Europäischen Norm festgelegte Ausrüstung ist zum Umfüllen flüssiger Erdölerzeugnisse und anderer gefähr¬licher Güter der Klasse 3 des ADR ) (entflammbare Flüssigkeiten) geeignet, deren Dampfdruck bei 50 °C höchstens 110 kPa beträgt (einschließlich Ottokraftstoff) und die nicht als giftig oder ätzend eingestuft sind.

Citernes destinées au transport de matières dangereuses - Equipement de service pour citernes - Bouchon pour l'adaptateur de chargement et de déchargement par le bas

La présente Norme européenne s’applique au bouchon utilisé pour assurer la protection et une fermeture supplémentaire de l’adaptateur de chargement et de déchargement par le bas des citernes destinées au transport de matières dangereuses. Elle spécifie les exigences de performance, les dimensions essentielles et les essais à réaliser pour vérifier la conformité des équipements à la présente Norme européenne.
L’équipement spécifié dans la présente norme est adapté à une utilisation avec des produits pétroliers liquides et autres matières dangereuses de la classe 3 de l’ADR  ) (liquides inflammables) dont la tension de vapeur ne dépasse pas 110 kPa à 50 °C, y compris l’essence, et qui n’appartiennent à aucune sous-classification des produits toxiques ou corrosifs.

Cisterne za prevoz nevarnega blaga - Oprema za obratovanje - Kapa priključka za polnjenje in praznjenje s spodnje strani

Ta evropski standard se uporablja za kapo, ki se uporablja za zagotavljanje zaščite in zapiranja za priključek za polnjenje in praznjenje cistern za prevoz nevarnih snovi s spodnje strani. Določa zahteve glede zmogljivosti, kritične mere in preskuse, potrebne za preverjanje skladnosti opreme s tem evropskim standardom. Oprema, ki jo določa ta evropski standard, je primerna za uporabo s tekočimi naftnimi proizvodi in drugimi nevarnimi snovmi kategorije 3 ADR 1) (vnetljive tekočine), katerih parni tlak ne presega 110 kPa pri 50 °C, vključno z motornim bencinom, pri čemer niso dodatno opredeljeni kot strupeni ali korozivni.

General Information

• Status: Published
• Public Enquiry End Date: 09-Jul-2011
• Publication Date: 17-Nov-2013
• ICS: 13.300 - Protection against dangerous goods
• ICS: 23.020.20 - Vessels and containers mounted on vehicles
• Technical Committee: TLP - Pressure vessels
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 17-Oct-2013
• Due Date: 22-Dec-2013
• Completion Date: 18-Nov-2013
• Directive: 2008/68/EC - Directve 2008/68/EC of the European Parliament and of the council of 24 September 2008 on the inland transport of the dangerous goods
• Mandate: M/086 - Mandate to CEN for standardization in the field of transport of dangerous goods
• Ref Project: EN 16249:2013 - Tanks for the transport of dangerous goods - Service equipment - Cap for the adaptor for bottom loading and unloading

Overview

SIST EN 16249:2013 is a European standard developed by CEN that specifies the requirements for caps used with adaptors for bottom loading and unloading of tanks transporting dangerous goods. This standard focuses on service equipment designed to protect and securely close adaptors on tanks carrying flammable liquids under Class 3 of ADR, including liquid petroleum products like petrol. It establishes the performance criteria, critical dimensions, material characteristics, and testing protocols necessary to ensure the caps provide safe, reliable operation in hazardous environments.

This standard is essential for manufacturers, operators, and safety professionals involved in the transport and handling of flammable liquids, ensuring compliance, interoperability, and enhanced safety when using bottom loading and unloading systems.

Key Topics

• Scope and Application
  SIST EN 16249:2013 applies specifically to caps for adaptors on tanks transporting flammable liquids with vapor pressures not exceeding 110 kPa at 50 °C. It excludes substances classified as toxic or corrosive, focusing on liquid petroleum products and related substances.

• Performance and Safety Requirements
  The cap must provide:

  • Containment of dangerous substances inside the tank
  • Mechanical protection for the adaptor’s sealing face
  • Safe pressure release mechanisms to prevent accidents during cap removal

• Design and Construction
  Caps must meet precise dimensional and pressure requirements, including a minimum working pressure of 40 kPa. Materials used must resist corrosion, especially in friction contact with aluminium components, and comply with electrical resistance thresholds to reduce static risks. Sustainable, recyclable materials are encouraged.

• Testing Protocols
  Two main categories of testing are required:

  • Production Tests: Tightness and operability tests carried out routinely on manufacturing lots with sampling per ISO 2859-1 (AQL 2.5)
  • Type Tests: Performance and mechanical strength verifications on representative samples conducted at design temperature limits

• Marking and Traceability
  Permanent markings on caps must include the standard reference, manufacturer’s identity, serial or batch numbers, and any special operating instructions to ensure traceability and compliance.

• Installation and Maintenance
  The standard mandates clear guidelines for installation, operation, and maintenance to support safe, efficient use throughout the service life of the cap.

Applications

SIST EN 16249:2013 is vital for ensuring safety and functionality in the transport of flammable liquids by road tanks equipped with bottom loading/unloading systems. The cap protects critical adaptor interfaces from contamination, damage, and leakage during transit and handling operations. Typical applications include:

• Tank vehicles carrying petrol and other flammable liquids under ADR regulations
• Bottom loading and unloading stations in fuel depots and terminals
• Service equipment manufacturing for road tankers and similar transport containers
• Safety management systems for hazardous goods transport operators

By conforming to SIST EN 16249:2013, equipment manufacturers and logistics providers mitigate risks of spillage, vapor release, and accidental ignition, ensuring regulatory compliance and safe handling during fuel transportation.

Related Standards

SIST EN 16249:2013 is part of a comprehensive suite of CEN standards covering service equipment for tanks transporting liquid dangerous goods, including:

• EN 13083:2008 – Adaptor for bottom loading and unloading
• EN 13315:2002 – Gravity discharge coupler
• EN 14564:2013 – Terminology related to tanks for dangerous goods
• EN 13081, EN 13082 – Vapour collection adaptor and valves for tanks
• EN 13317, EN 14595 – Manhole covers and breather vents for tanks
• EN 13314, EN 13316 – Footvalves and fill hole covers for tanks

Together, these standards establish robust safety and interoperability frameworks across the design, testing, installation, and operation of specialized equipment for dangerous goods transport by road.

---

Keywords: SIST EN 16249:2013, bottom loading tank caps, dangerous goods tanks, flammable liquids transport, ADR Class 3, tank adaptor protection, service equipment for tanks, transport safety standards, petroleum product transport, CEN standards, tank vehicle equipment.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Tanks für die Beförderung gefährlicher Güter - Bedienungsausrüstung - Kappe für VK-Kupplung für Untenbefüllung und -entladungCiternes destinées au transport de matières dangereuses - Equipement de service pour citernes - Bouchon pour l'adaptateur de chargement et de déchargement par le basTanks for the transport of dangerous goods - Service equipment - Cap for the adaptor for bottom loading and unloading23.020.20Posode in vsebniki, montirani na vozilaVessels and containers mounted on vehicles13.300Varstvo pred nevarnimi izdelkiProtection against dangerous goodsICS:Ta slovenski standard je istoveten z:EN 16249:2013SIST EN 16249:2013en,fr,de01-december-2013SIST EN 16249:2013SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 16249
August 2013 ICS 23.020.20 English Version
Tanks for the transport of dangerous goods - Service equipment - Cap for the adaptor for bottom loading and unloading
Citernes destinées au transport de matières dangereuses -Equipement de service - Chapeau pour l'adapteur pour le chargement et déchargement par le bas
Tanks für die Beförderung gefährlicher Güter - Bedienungsausrüstung - Kappe für VK-Kupplung für Untenbefüllung und -entladung This European Standard was approved by CEN on 29 June 2013.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2013 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 16249:2013: ESIST EN 16249:2013
...
