Household and similar electrical appliances - Safety - Part 2-105: Particular requirements for multifunctional shower cabinets

This International Standard deals with the safety of electric multifunctional shower cabinets
and electric separate multifunctional shower units for household and similar purposes,
their rated voltage being not more than 250 V for single-phase appliances and 480 V for
other appliances.
Appliances not intended for normal household use but which nevertheless may be a source of
danger to the public, such as appliances intended to be used by laymen in hotels, fitness
centres and similar locations, are within the scope of this standard.
As far as is practicable, this standard deals with the common hazards presented by
appliances that are encountered by all persons in and around the home. However, in general,
it does not take into account
– persons (including children) whose
• physical, sensory or mental capabilities; or
• lack of experience and knowledge
prevents them from using the appliance safely without supervision or instruction;
– children playing with the appliance.
NOTE 101 Attention is drawn to the fact that
– for appliances intended to be used in vehicles or on board ships or aircraft, additional requirements may be
necessary;
– in many countries, additional requirements are specified by the national health authorities, the national water
supply authorities, the national authorities responsible for the protection of labour and similar authorities;
– in many countries, mechanical strength, impact resistance and shattering properties of shower enclosures can
be covered by national regulations.
NOTE 102 If an appliance incorporates a part that is within the scope of IEC 60065, IEC 60598 or IEC 60950, the
part is tested in accordance with the relevant standard as far as reasonable.
NOTE 103 This standard does not apply to
– instantaneous water heaters used for showering (IEC 60335-2-35);
– shower-boost pumps (IEC 60335-2-41);
– appliances intended for medical purposes;
– appliances intended to be used in locations where special conditions prevail, such as the presence of a
corrosive or explosive atmosphere (dust, vapour or gas)

Sicherheit elektrischer Geräte für den Hausgebrauch und ähnliche Zwecke - Teil 2-105: Besondere Anforderungen für mulitifunktionelle Duscheinrichtungen

Appareils électrodomestiques et analogues - Sécurité - Partie 2-105: Règles particulières pour les cabines de douche multifonctions

L'IEC 60335-2-105:2016 traite de la sécurité des cabines de douche multifonctions électriques et des colonnes de douche multifonctions électriques pour usages domestiques et analogues, dont la tension assignée n'est pas supérieure à 250 V pour les appareils monophasés et à 480 V pour les autres appareils. Les appareils qui ne sont pas destinés à un usage domestique normal, mais qui peuvent néanmoins constituer une source de danger pour le public, tels que les appareils destinés à être utilisés par des usagers non avertis dans des hôtels, des centres de conditionnement physique et lieux similaires, relèvent du domaine d'application de la présente norme. Dans la mesure du possible, la présente norme traite des dangers ordinaires que présentent les appareils, encourus par tous les individus à l'intérieur et autour de l'habitation. Cependant, cette norme ne tient en général pas compte des personnes (y compris des enfants) dont les capacités physiques, sensorielles ou mentales; ou le manque d'expérience et de connaissance les empêchent d'utiliser l'appareil en toute sécurité sans surveillance ou instruction; de l'utilisation de l'appareil comme jouet par des enfants. Cette deuxième édition annule et remplace la première édition parue en 2004 y compris son Amendement 1 (2008) et son Amendement 2 (2013). Cette édition constitue une révision technique. Les modifications majeures dans la présente édition par rapport à la première édition de l'IEC 60335-2-105 sont les suivantes (les modifications mineures ne sont pas indiquées): - révision de l'application d'une partie active (8.1.4); - alignement des limites des échauffements des surfaces susceptibles d'être en contact avec la peau avec le Guide IEC 117 pour une durée de contact d'une minute (Tableau 3). Cette publication doit être lue conjointement avec la IEC 60335-1:2010. Elle a été établie sur la base de la cinquième édition (2010) de cette norme. L'attention des Comités nationaux est attirée sur le fait que les fabricants d'appareils et les organismes d'essai peuvent avoir besoin d'une période transitoire après la publication d'une nouvelle publication IEC, ou d'une publication amendée ou révisée, pour fabriquer des produits conformes aux nouvelles exigences et pour adapter leurs équipements aux nouveaux essais ou aux essais révisés. Le comité recommande que le contenu de l'amendement 2 soit entériné au niveau national au plus tôt 12 mois ou au plus tard 36 mois après la date de publication. Mots-Clés: douche, cabines de douche, multifonctions

Gospodinjski in podobni električni aparati - Varnost - 2-105. del: Posebne zahteve za večnamenske kabine za prhanje

Ta mednarodni standard obravnava varnost električnih večnamenskih kabin za prhanje in električnih ločenih večnamenskih enot za prhanje za gospodinjsko uporabo in podobne namene, pri čemer njihova nazivna napetost ni večja od 250 V za enofazne aparate in 480 V za druge aparate.
Na področje uporabe tega standarda spadajo aparati, ki niso namenjeni za običajno gospodinjsko uporabo, vendar so lahko vir nevarnosti za javnost, kot so aparati, namenjeni za laično uporabo v hotelih, centrih za telesno vadbo in na podobnih lokacijah.
Ta standard v največji možni meri obravnava splošne nevarnosti, ki jih predstavljajo aparati ter s katerimi se srečujejo osebe doma in v okolici doma. Vendar na splošno ne vključuje primerov:
– oseb (tudi otrok), ki zaradi
fizičnih, senzoričnih ali umskih sposobnosti oziroma
pomanjkanja izkušenj in znanja
ne morejo varno uporabljati aparata brez nadzora ali navodil;
– otrok, ki se igrajo z aparatom.
OPOMBA 101: Opozoriti je treba, da:
– so za aparate, ki so namenjeni za uporabo v vozilih ali na krovu ladij ali letal, morda potrebne dodatne zahteve;
– v številnih državah nacionalni zdravstveni organi, nacionalni organi za oskrbo z vodo, nacionalni organi, odgovorni za varstvo pri delu, ter drugi podobni organi določajo dodatne zahteve;
– so lahko v številnih državah lastnosti mehanske trdnosti, odpornosti na udarce in lomljivosti zaslonov za prhanje zajete v nacionalnih predpisih.
OPOMBA 102: Če aparat vključuje del, ki spada na področje uporabe standarda IEC 60065, IEC 60598 ali IEC 60950, je treba zadevni del preskusiti v skladu z ustreznim standardom, če je to primerno.
OPOMBA 103: Ta standard se ne uporablja za:
– pretočne grelnike vode za uporabo pri prhanju (IEC 60335-2-35);
– črpalke za prhanje (IEC 60335-2-41);
– aparate za medicinske namene;
– aparate, ki so namenjeni za uporabo na lokacijah, kjer veljajo posebne razmere, kot je prisotnost korozivne ali eksplozivne atmosfere (prah, hlapi ali plin).
