IEC 62642-2-2 ®
Edition 1.0 2010-10
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Alarm systems – Intrusion and hold-up systems –
Part 2-2: Intrusion detectors – Passive infrared detectors
Systèmes d'alarme – Systèmes d'alarme contre l’intrusion et les hold-up –
Partie 2-2: Détecteurs d'intrusion – Détecteurs à infrarouges passifs
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
PRICE CODE
INTERNATIONALE
X
CODE PRIX
ICS 13.320 ISBN 978-2-88912-197-7
– 2 – 62642-2-2 © IEC:2010
CONTENTS
FOREWORD.5
INTRODUCTION.7
1 Scope.8
2 Normative references .8
3 Terms, definitions and abbreviations .8
3.1 Terms and definitions .8
3.2 Abbreviations .9
4 Functional requirements .9
4.1 Event processing.9
4.2 Detection.11
4.2.1 Detection performance .11
4.2.2 Indication of detection .12
4.2.3 Significant reduction of range .12
4.3 Operational requirements .13
4.3.1 Time interval between intrusion signals or messages .13
4.3.2 Switch on delay .13
4.3.3 Self tests .13
4.4 Immunity to incorrect operation .13
4.4.1 Immunity to air flow .13
4.4.2 Immunity to visible and near infrared radiation.13
4.5 Tamper security .13
4.5.1 Resistance to and detection of unauthorised access to components
and means of adjustment.14
4.5.2 Detection of removal from the mounting surface .14
4.5.3 Resistance to, or detection of, re-orientation .14
4.5.4 Immunity to magnetic field interference .14
4.5.5 Detection of masking .14
4.6 Electrical requirements.15
4.6.1 Detector current consumption .15
4.6.2 Slow input voltage change and voltage range limits .15
4.6.3 Input voltage ripple.15
4.6.4 Input voltage step change.15
4.7 Environmental classification and conditions.16
4.7.1 Environmental classification .16
4.7.2 Immunity to environmental conditions .16
5 Marking, identification and documentation .16
5.1 Marking and/or identification.16
5.2 Documentation .16
6 Testing .17
6.1 General test conditions.17
6.1.1 Standard conditions for testing .17
6.1.2 General detection testing environment and procedures.17
6.1.3 Testing environment .17
6.1.4 Standard walk test target.17
6.1.5 Testing procedures.18
6.2 Basic detection test .18
62642-2-2 © IEC:2010 – 3 –
6.2.1 Basic detection target (BDT).18
6.2.2 Basic test of detection capability.18
6.3 Walk testing .19
6.3.1 General walk test method .19
6.3.2 Verification of detection performance.19
6.3.3 Detection across and within the detection boundary .19
6.3.4 Verify the high-velocity detection performance.20
6.3.5 Verify the intermittent movement detection performance.20
6.3.6 Verify the close-in detection performance .21
6.3.7 Verify the significant reduction of specified range .21
6.4 Switch-on delay, time interval between signals and indication of detection .21
6.5 Self tests.21
6.6 Immunity to incorrect operation .22
6.6.1 Immunity to air flow .22
6.6.2 Immunity to visible and near infrared radiation.22
6.7 Tamper security .22
6.7.1 Resistance to and detection of unauthorised access to the inside of
the detector through covers and existing holes .23
6.7.2 Detection of removal from the mounting surface .23
6.7.3 Resistance to or detection of re-orientation of adjustable mountings.23
6.7.4 Resistance to magnetic field interference .23
6.7.5 Detection of detector masking .23
6.7.6 Immunity to false masking signals .24
6.8 Electrical tests.25
6.8.1 Detector current consumption .25
6.8.2 Slow input voltage change and input voltage range limits .25
6.8.3 Input voltage ripple.25
6.8.4 Input voltage step change.26
6.8.5 Total loss of power supply .26
6.9 Environmental classification and conditions.26
6.10 Marking, identification and documentation .28
6.10.1 Marking and/or identification.28
6.10.2 Documentation .28
Annex A (normative) Dimensions and requirements of the standardised test magnets .29
Annex B (normative) General testing matrix .32
Annex C (informative) Walk test diagrams .34
Annex D (normative) Procedure for calculation of average temperature difference.37
Annex E (informative) Basic detection target for the basic test of detection capability .39
Annex F (informative) Equipment for walk test velocity control .40
Annex G (informative) Immunity to visible and near infrared radiation – Notes on
calibration of the light source .41
Annex H (informative) Example list of small tools.42
Annex I (informative) Test for resistance to re-orientation of adjustable mountings .43
Bibliography.45
Figure A.1 – Test magnet – Magnet type 1.30
Figure A.2 – Test magnet – Magnet type 2.31
Figure C.1 – Detection across the boundary .34
– 4 – 62642-2-2 © IEC:2010
Figure C.2 – Detection within the boundary.34
Figure C.3 – High velocity and intermittent movement.35
Figure C.4 – Close-in detection.35
Figure C.5 – Significant range reduction .36
Figure I.1 – Re-orientation test .44
Table 1 – Events to be processed by grade .10
Table 2 – Generation of signals or messages .11
Table 3 – General walk test velocity and attitude requirements .12
Table 4 – Tamper security requirements .15
Table 5 – Electrical requirements.15
Table 6 – Range of materials for masking tests.24
Table 7 – Operational tests.27
Table 8 – Endurance tests .27
