EN 10245-5:2011

Steel wire and wire products - Organic coatings on steel wire - Part 5: Polyamide coated wire

Complementary to prEN 10245-1, this European Standard specifies the characteristics and requirements for steel wire and wire products coated with Polyamide (PA6).

Stahldraht und Drahterzeugnisse - Organische Beschichtungen auf Stahldraht - Teil 5: Polyamid-beschichteter Draht

Ergänzend zu EN 10245 1 legt diese Europäische Norm Eigenschaften und Anforderungen für Stahldraht und Drahterzeugnisse fest, die mit Polyamid (PA6) beschichtet sind.

Fils et produits tréfilés en acier - Revêtements organiques sur fils d'acier - Partie 5: Fils à revêtement de polyamide

En complément de l’EN 10245-1, cette norme européenne spécifie les caractéristiques et les exigences relatives aux fils et produits tréfilés en acier revêtus de polyamide (PA6).

Jeklena žica in žični izdelki - Organske prevleke na jekleni žici - 5. del: S poliamidi prevlečena žica

Ta evropski standard dopolnjuje EN 10245-1 in določa karakteristike in zahteve za jeklene žice in žične izdelke, prevlečene s poliamidom (PA6).

General Information

• Status: Published
• Publication Date: 25-Oct-2011
• Withdrawal Date: 29-Apr-2012
• ICS: 25.220.60 - Organic coatings
• ICS: 77.140.65 - Steel wire, wire ropes and link chains
• Technical Committee: ECISS/TC 106 - Wire rod and wires
• Drafting Committee: ECISS/TC 106 - Wire rod and wires
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 03-Dec-2021
• Completion Date: 14-Apr-2025
• Ref Project: SIST EN 10245-5:2012 - Steel wire and wire products - Organic coatings on steel wire - Part 5: Polyamide coated wire

Overview

EN 10245-5:2011 - issued by CEN - is the European standard that specifies characteristics, testing and performance requirements for steel wire and wire products coated with Polyamide (PA6). It is complementary to EN 10245-1 (General rules) and covers both the coating material (powder or granules) and the applied coating on finished wire. The standard defines methods of application, classification of PA6 coatings, material properties, inspection and quality assurance requirements.

Key Topics

• Scope and classification
  • Applies to PA6 (polyamide) coatings used on steel wire and wire products.
  • Coating classes based on application and adhesion: Class 1a, 1b, 2a, 2b (extrusion vs. powder/fluidised bed, with/without primer).
• Methods of application
  • Extrusion, fluidised bed, thermal fusion or electrostatic powder spraying.
• Material requirements
  • Density, hardness and mechanical properties are specified for PA6 coating material (e.g., density < 1.15 g/cm3; Rockwell M hardness ≤ 82; tensile strength ≥ 30 MPa; elongation ≥ 200% - measured after conditioning).
• Coating requirements on wire
  • Appearance, colour, gloss, coating thickness, concentricity (minimum 60% concentricity) and adhesion criteria (referenced classes and pull-out resistance where applicable).
• Performance testing
  • Accelerated weathering and colour stability tests (e.g., xenon-arc or QUV per EN ISO 4892 series and ISO 4582) and other test methods referenced to EN 10245-1 and applicable EN/ISO test standards.
• Quality assurance
  • Inspection per EN 10021 and certification/documentation options (EN 10204, certificates of compliance). Traceability recommendations (batch numbers, inspection references).

Applications and Who Uses It

• Manufacturers and applicators of polyamide-coated steel wire (fence wire, fasteners, springs, preformed wire products).
• Specifiers and purchasers in construction, agricultural, automotive and general industrial sectors who require durable organic-coated wire.
• Testing laboratories and QA engineers responsible for verifying compliance with coating material properties and finished-wire performance.
• Procurement and standards committees drafting product specifications or tender documents referencing EN 10245-5:2011.

Related Standards

• EN 10245-1:2008 - General rules for organic coatings on steel wire
• Other parts of EN 10245 series: Part 2 (PVC), Part 3 (PE), Part 4 (Polyester)
• EN 10021 (delivery conditions), EN ISO 1183, EN ISO 527, EN ISO 2813, EN ISO 4892 series, ISO 4582 (referenced test methods)

EN 10245-5:2011 is essential when specifying or verifying polyamide (PA6) coated wire, ensuring consistent material properties, reproducible coating application and defined performance under accelerated weathering and mechanical tests.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Stahldraht und Drahterzeugnisse - Organische Beschichtungen auf Draht - Teil 5: Polyamid beschichteter DrahtFils et produits tréfilés en acier - Revêtements organiques sur fils d'acier - Partie 5: Fils à revêtement de polyamideSteel wire and wire products - Organic coatings on steel wire - Part 5: Polyamide coated wire77.140.65Jeklene žice, jeklene vrvi in verigeSteel wire, wire ropes and link chains25.220.60Organske prevlekeOrganic coatingsICS:Ta slovenski standard je istoveten z:EN 10245-5:2011SIST EN 10245-5:2012en,de01-januar-2012SIST EN 10245-5:2012SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 10245-5
October 2011 ICS 25.220.60; 77.140.65 English Version
Steel wire and wire products - Organic coatings on steel wire - Part 5: Polyamide coated wire
Fils et produits tréfilés en acier - Revêtements organiques sur fils d'acier - Partie 5: Fils à revêtement de polyamide
Stahldraht und Drahterzeugnisse - Organische Beschichtungen auf Stahldraht - Teil 5: Polyamid-beschichteter Draht This European Standard was approved by CEN on 17 September 2011.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2011 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 10245-5:2011: ESIST EN 10245-5:2012

 Part 1: General Rules;  Part 2: PVC finished wire;  Part 3: PE coated wire;  Part 4: Polyester coated wire;  Part 5: Polyamide coated wire. According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and the United Kingdom.
...
