EN 14212:2005

Ambient air quality - Standard method for the measurement of the concentration of sulphur dioxide by ultraviolet fluorescence

This document specifies a continuous measurement method for the determination of the concentration of sulphur dioxide present in ambient air based on the ultraviolet fluorescence measuring principle. This document describes the performance characteristics and sets the relevant minimum criteria required to select an appropriate ultraviolet fluorescence analyser by means of type approval tests. It also includes the evaluation of the suitability of an anayser for use in a specific fixed site so as to meet the Directives data quality requirements and requirements during sampling, calibration and quality assurance for use.
The method is applicable to the determination of the mass concentration of sulphur dioxide present in ambient air from 0 mg/m3 to 1 000 mg/m3 sulphur dioxide. This concentration range represents the certification range for the type approval test.
NOTE 1   0 mg/m3 to 1 000 mg/m3 of SO2 corresponds to 0 nmol/mol to 376 nmol/mol of SO2.
NOTE 2   Lower ranges may be used for measurement systems applied at rural locations monitoring Ecosystems.
The method covers the determination of ambient air concentrations of sulphur dioxide in zones classified as rural areas, urban-background areas and traffic-orientated locations.
The results are expressed in mg/m3 (at 293 K and 101,3 kPa).
When the standard is used for other purposes than the EU-directive, the range and uncertainty requirements need not apply.

Luftqualität - Messverfahren zur Bestimmung der Konzentration von Schwefeldioxid mit Ultraviolett-Fluoreszenz

Dieses Dokument legt ein kontinuierliches Messverfahren zur Bestimmung der Konzentration von Schwefeldioxid in Luft nach dem Ultraviolett-Fluoreszenz-Messprinzip fest. Dieses Dokument gibt die Leistungskenngrößen an und legt die relevanten Mindestanforderungen für die Eignungsprüfung von Ultraviolett-Fluoreszenz-Messgeräten fest. Es schließt auch die Bewertung der Eignung eines Messgeräts zur Anwendung an einer spezifischen Messstelle im Hinblick auf die Datenqualitätsanforderungen der EU-Richtlinien ein und enthält Anforderungen für die Probenahme, Kalibrierung und Qualitätssicherung bei der Anwendung.
Das Verfahren ist anwendbar zur Bestimmung der Massenkonzentration von Schwefeldioxid in Luft im Bereich von 0 µg/m³ bis 1000 µg/m³. Dieser Konzentrationsbereich entspricht dem Zertifizierungsbereich für die Eignungsprüfung.
ANMERKUNG 1   0 µg/m³ bis 1000 µg/m³ SO2 entspricht 0 nmol/mol bis 376 nmol/mol SO2.
ANMERKUNG 2   Kleinere Bereiche können für Messsysteme an ländlichen Standorten zur Überwachung von Ökosystemen verwendet werden.
Das Verfahren umfasst die Bestimmung der Konzentration von Schwefeldioxid in Gebieten, die als ländliche Gebiete, Gebiete mit städtischem Hintergrund und verkehrsbezogene Standorte klassifiziert sind.
Die Ergebnisse werden in µg/m³ (bei 293 K und 101,3 kPa) angegeben.
Wenn diese Norm für andere als in der EU-Richtlinie festgelegte Zwecke eingesetzt wird, müssen die Anforderungen hinsichtlich Anwendungsbereich und Unsicherheit nicht gestellt werden.

Qualité de l'air ambiant - Méthode normalisée pour le mesurage de la concentration de soufre par fluorescence U.V.

Le présent document spécifie une méthode de mesurage en continu pour la détermination de la concentration en dioxyde de soufre (SO2) dans l'air ambiant, selon le principe de mesure par fluorescence U.V. Le présent document décrit les caractéristiques de performance et fixe les critères minimums requis pour sélectionner un analyseur par fluorescence U.V. à l'aide d'essais d'approbation de type. Il présente également l'évaluation de l'aptitude à l'emploi d'un analyseur sur un site fixe spécifique de manière à répondre aux exigences de qualité des données prescrites dans les Directives ainsi qu'aux exigences à observer au cours du prélèvement, de l'étalonnage et de l'assurance qualité.
La méthode s'applique à la détermination de la concentration massique en SO2 présent dans l'air ambiant dans une plage de concentration en SO2 comprise entre 0 mg/m3 et 1 000 mg/m3. Cette plage de concentration représente l'étendue de mesure certifiée pour l'essai d'approbation de type.
NOTE 1   La plage comprise entre 0 mg/m3 et 1 000 mg/m3 de SO2 correspond à la plage de 0 nmol/mol à 376 nmol/mol de SO2.
NOTE 2   Des plages inférieures peuvent être utilisées pour les systèmes de mesure appliqués aux zones rurales contrôlant des écosystèmes.
La méthode couvre la détermination des concentrations en SO2 présent dans l'air ambiant dans les zones classées comme zones rurales, périurbaines et proches d'axes de circulation automobile.
Les résultats sont exprimés en mg/m3 (à 293 K et 101,3 kPa).
Lorsque la norme est utilisée à d'autres fins que la Directive UE, les exigences relatives à la plage et à l'incertitude peuvent ne pas être appliquées.

Kakovost zunanjega zraka – Standardna metoda za določanje koncentracije žveplovega dioksida z ultravijolično fluorescenco

General Information

• Status: Withdrawn
• Publication Date: 08-Mar-2005
• Withdrawal Date: 21-Aug-2012
• ICS: 13.040.20 - Ambient atmospheres
• Technical Committee: CEN/TC 264 - Air quality
• Drafting Committee: CEN/TC 264/WG 12 - Reference method for determination of SO2/NO2/O3/CO in ambient air
• Current Stage: 9960 - Withdrawal effective - Withdrawal
• Start Date: 22-Aug-2012
• Completion Date: 22-Aug-2012
• Directive: 1999/30/EC - Limit values for sulphur dioxide, nitrogen dioxide and oxides of nitrogen, particulate matter and lead in ambient air
• Directive: 96/62/EC - Ambient air quality assessment and management
• Mandate: M/256 - Standardization mandate to CEN for standard measuring methods of SO2, NO2, CO, 03 in ambiant air
• Ref Project: SIST EN 14212:2005 - Ambient air quality - Standard method for the measurement of the concentration of sulphur dioxide by ultraviolet fluorescence

Relations

• Replaced By: EN 14212:2012 - Ambient air - Standard method for the measurement of the concentration of sulphur dioxide by ultraviolet fluorescence
• Effective Date: 08-Jun-2022

Standards Content (Sample)

SLOVENSKI STANDARD
01-september-2005
.DNRYRVW]XQDQMHJD]UDND±6WDQGDUGQDPHWRGD]DGRORþDQMHNRQFHQWUDFLMH
åYHSORYHJDGLRNVLGD]XOWUDYLMROLþQRIOXRUHVFHQFR
Ambient air quality - Standard method for the measurement of the concentration of
sulphur dioxide by ultraviolet fluorescence
Luftqualität - Messverfahren zur Bestimmung der Konzentration von Schwefeldioxid mit
Ultraviolett-Fluoreszenz
Qualité de l'air ambiant - Méthode normalisée pour le mesurage de la concentration de
soufre par fluorescence U.V.
Ta slovenski standard je istoveten z: EN 14212:2005
ICS:
13.040.20 Kakovost okoljskega zraka Ambient atmospheres
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

EUROPEAN STANDARD
EN 14212
NORME EUROPÉENNE
EUROPÄISCHE NORM
March 2005
ICS 13.040.20
English version
Ambient air quality - Standard method for the measurement of
the concentration of sulphur dioxide by ultraviolet fluorescence
Qualité de l'air ambiant - Méthode normalisée pour le Luftqualität - Messverfahren zur Bestimmung der
mesurage de la concentration de SO2 par fluorescence UV Konzentration von Schwefeldioxid mit Ultraviolett-
Fluoreszenz
This European Standard was approved by CEN on 10 December 2004.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European
Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national
standards may be obtained on application to the Central Secretariat or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation
under the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the official
versions.
CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,
Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia,
Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre: rue de Stassart, 36  B-1050 Brussels
© 2005 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN 14212:2005: E
worldwide for CEN national Members.

Contents
Page
Foreword.4
1 Scope .5
2 Normative references .5
3 Terms and definitions .6
4 Symbols and abbreviated terms .9
5 Principle.12
5.1 General.12
5.2 Measuring principle.13
5.3 Type approval test .14
6 Sampling equipment .14
6.1 General.14
6.2 Sampling location.14
6.3 Sample inlet and sampling line .14
6.4 Particulate filter.15
6.5 Control and regulation of sample flow rate .15
6.6 Sampling pump for the manifold.15
7 Analyser equipment .16
7.1 General.16
7.2 Selective traps for interfering agents .16
7.3 Optical assembly .16
7.4 Pressure measurement .16
7.5 Flow rate indicator.16
7.6 Sampling pump for the analyser.17
7.7 Internal span source.17
8 Type approval of sulphur dioxide UV fluorescence analysers .17
8.1 General.17
8.2 Relevant performance characteristics and performance criteria .17
8.3 Design changes .19
8.4 Procedures for determination of the performance characteristics during the laboratory test .19
8.5 Determination of the performance characteristics during the field test.30
8.6 Expanded uncertainty calculation for type approval.33
9 Field operation and ongoing quality control .34
9.1 General.34
9.2 Suitability evaluation.34
9.3 Initial installation.36
9.4 Ongoing quality control .36
9.5 Calibration of the analyser.38
9.6 Checks .38
9.7 Maintenance .41
9.8 Data handling and data reports.42
10 Expression of results .42
11 Test reports and documentation.42
11.1 Type approval test .42
11.2 Field operation .42
Annex A (normative) Calculation of lack of fit.44
Annex B (informative) Sampling equipment.46
Annex C (informative) Sampling on micro-scale [2] .48
Annex D (informative) Schematic diagram of a fluorescence analyser.49
Annex E (informative) Manifold testing equipment .50
Annex F (normative) Type approval .51
Annex G (normative) Calculation of uncertainty in field operation at the hourly limit value .73
Annex H (normative) Calculation of uncertainty in field operation at the annual limit value.86
Bibliography.103

Foreword
This document (EN 14212:2005) has been prepared by Technical Committee CEN/TC 264 “Air quality”, the
secretariat of which is held by DIN.
This European Standard shall be given the status of a national standard, either by publication of an identical text or
by endorsement, at the latest by September 2005, and conflicting national standards shall be withdrawn at the
latest by September 2005.
According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following
countries are bound to implement this European Standard: Austria, Belgium, Cyprus, Czech Republic, Denmark,
Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta,
Netherlands, Norway, Poland, Portugal, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
1 Scope
This document specifies a continuous measurement method for the determination of the concentration of sulphur
dioxide present in ambient air based on the ultraviolet fluorescence measuring principle. This document describes
the performance characteristics and sets the relevant minimum criteria required to select an appropriate ultraviolet
fluorescence analyser by means of type approval tests. It also includes the evaluation of the suitability of an
analyser for use in a specific fixed site so as to meet the Directives data quality requirements and requirements
during sampling, calibration and quality assurance for use.
The method is applicable to the determination of the mass concentration of sulphur dioxide present in ambient air
3 3
from 0 µg/m to 1 000 µg/m sulphur dioxide. This concentration range represents the certification range for the
type approval test.
3 3
NOTE 1 0 µg/m to 1 000 µg/m of SO corresponds to 0 nmol/mol to 376 nmol/mol of SO .
2 2
NOTE 2 Lower ranges may be used for measurement systems applied at rural locations monitoring Ecosystems.
The method covers the determination of ambient air concentrations of sulphur dioxide in zones classified as rural
areas, urban-background areas and traffic-orientated locations.
The results are expressed in µg/m (at 293 K and 101,3 kPa).
When the standard is used for other purposes than the EU-directive, the range and uncertainty requirements need
not apply.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated references,
only the edition cited applies. For undated references, the latest edition of the referenced document (including any
amendments) applies.
ENV 13005, Guide to the expression of uncertainty in measurement
EN ISO 14956:2002, Air quality — Evaluation of the suitability of a measurement procedure by comparison with a
required measurement uncertainty (ISO 14956:2002)
ISO 6142, Gas analysis — Preparation of calibration gas mixtures — Gravimetric method
ISO 6143, Gas analysis — Comparison methods for determining and checking the composition of calibration gas
mixtures
ISO 6144, Gas analysis — Preparation of calibration gas mixtures — Static volumetric method
ISO 6145 (all parts), Gas analysis — Preparation of calibration gas mixtures using dynamic volumetric methods
3 Terms and definitions
For the purpose of this document, the following terms and definitions apply.
3.1
ambient air
)
outdoor air in the troposphere, excluding workplace air
3.2
sample gas temperature
temperature at the sample inlet outside the monitoring station
3.3
availability of the analyser
fraction of the total time period for which u
...
