Service diagnostic interface for consumer electronics products and networks - Implementation for ECHONET

IEC 62394:2017 specifies requirements for service diagnostic software to be implemented in products that incorporate a digital interface. The Service Diagnostic Interface (SDI) requires an external controller (exclusive or general-purpose/PC) into which service diagnostic software can be loaded. Parts of the controller software should be standardized while other parts should be unique to the manufacturer. The SDI is based upon ECHONET specification version 2.11, ECHONET Lite specification version 1.11, and APPENDIX Detailed Requirements for ECHONET Device objects Release G, because this interface will be used in future products. The use of this connection and existing communication protocols enable implementation in products at a low cost, with maximum flexibility and efficiency.

General Information

Status
Published
Publication Date
10-Apr-2017
Current Stage
DELPUB - Deleted Publication
Completion Date
22-Jul-2022
Ref Project

Buy Standard

Standard
IEC 62394:2017 - Service diagnostic interface for consumer electronics products and networks - Implementation for ECHONET
English language
358 pages
sale 15% off
Preview
sale 15% off
Preview

Standards Content (sample)

IEC 62394
Edition 3.0 2017-04
INTERNATIONAL
STANDARD
colour
inside
Service diagnostic interface for consumer electronics products and networks –
Implementation for echonet
IEC 62394:2017-04(en)
