IEC 61987-24-1:2015 provides Operating Lists of Properties (OLOPs) for the description of the operating parameters and the collection of requirements for valve/actuator accessories, that can be used for every valve/actuator accessory, Device Lists of Properties (DLOPs) for positioners and I/P converters.
Mesure et commande dans les processus industriels - Structures de données et éléments dans les catalogues d'équipement de processus - Partie 24-1: Listes de propriétés (LOP) des positionneurs et des covertisseurs I/P pour l'échange électronique de données
L'IEC 61987-24-1:2015 fournit des listes de propriétés fonctionnelles (OLOP) pour la description des paramètres fonctionnels et l'ensemble des exigences pour les accessoires d'actionneur/de vanne, qui peuvent être utilisées pour chaque accessoire d'actionneur/de vanne; des listes de propriétés d'appareils (DLOP) pour les positionneurs et les convertisseurs I/P.
