IEC 60268-23:2023

Sound system equipment - Part 23: TVs and monitors - Loudspeaker systems

IEC 60268-23:2023 specifies acoustical measurement methods that apply to TV sets, monitors with built-in loudspeakers, and other audio devices having similar acoustical properties (e.g. flat-panel loudspeakers). The acoustical measurements are performed under free-field conditions and in-situ.
This document does not assess the perception and cognitive evaluation of the reproduced sound, nor the impact of perceived sound quality.

Équipements pour systèmes électroacoustiques - Partie 23: Téléviseurs et moniteurs - Systèmes de haut-parleurs

L'IEC 60268-23:2023 spécifie des méthodes de mesurage acoustique qui s'appliquent aux téléviseurs, aux moniteurs avec haut-parleurs intégrés et à d'autres appareils audio qui présentent des propriétés acoustiques similaires (haut-parleurs plats, par exemple). Les mesurages acoustiques sont réalisés dans des conditions de champ libre et in situ.
Le présent document n'évalue pas la perception et l'évaluation cognitive du son reproduit, ni l'incidence de la qualité perçue du son.

General Information

• Status: Published
• Publication Date: 23-Feb-2023
• ICS: 33.160.01 - Audio, video and audiovisual systems in general
• ICS: 33.160.50 - Accessories
• Technical Committee: TA 20 - Analogue and digital audio
• Drafting Committee: PT 60268-23 - TC 100/TA 20/PT 60268-23
• Current Stage: PPUB - Publication issued
• Start Date: 03-Apr-2023
• Completion Date: 24-Feb-2023

Standards Content (Sample)

IEC 60268-23
®

Edition 1.0 2023-02
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
colour
inside
Sound system equipment –
Part 23: TVs and monitors – Loudspeaker systems

Équipements pour systèmes électroacoustiques –
Partie 23: Téléviseurs et moniteurs – Systèmes de haut-parleurs

IEC 60268-23:2023-02(en-fr)
