SIST EN 17098-2:2018

Plastics - Barrier films for agricultural and horticultural soil disinfection by fumigation - Part 2: Method for film permeability determination using a static technique

This document specifies a method for determining the gas permeability of films using a static technique.
This document is applicable to thermoplastic barrier films for agricultural and horticultural soil disinfection using the fumigation technique.

Kunststoffe - Sperrschichtfolien zur Desinfektion durch Begasung von Landwirtschafts- und Gartenbauböden - Teil 2: Verfahren zur Bestimmung der Durchlässigkeit einer Folie unter Verwendung einer statischen Technik

Dieses Dokument legt ein Verfahren zur Bestimmung der Gasdurchlässigkeit von Folien unter Verwendung einer statischen Technik fest.
Dieses Dokument gilt für thermoplastische Sperrschichtfolien für die Desinfektion von Landwirtschafts- und Gartenbauböden durch Begasung.

Plastiques - Films barrière pour la désinfection par fumigation des sols agricoles et horticoles - Partie 2 : Méthode de détermination de la perméabilité d’un film utilisant une technique statique

Le présent document spécifie une méthode de détermination de la perméabilité au gaz des films utilisant une technique statique.
Ce document s’applique aux films barrière en thermoplastiques destinés à la désinfection des sols agricoles et horticoles par la technique de fumigation.

Polimerni materiali - Zaporne folije za razkuževanje kmetijske in vrtnarske zemlje z zaplinjevanjem - 2. del: Metoda za ugotavljanje prepustnosti folije z uporabo statične tehnike

Ta evropski standard določa metodo za ugotavljanje prepustnosti plinov folij z uporabo statične tehnike.
Uporablja se za plastomerne zaporne folije za razkuževanje kmetijske in vrtnarske zemlje z zaplinjevanjem.

General Information

• Status: Published
• Public Enquiry End Date: 17-May-2017
• Publication Date: 04-Feb-2018
• ICS: 65.060.99 - Other agricultural machines and equipment
• ICS: 83.140.10 - Films and sheets
• Technical Committee: IPMA - Polimer materials and products
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 18-Jan-2018
• Due Date: 25-Mar-2018
• Completion Date: 05-Feb-2018
• Ref Project: EN 17098-2:2018 - Plastics - Barrier films for agricultural and horticultural soil disinfection by fumigation - Part 2: Method for film permeability determination using a static technique

Overview

SIST EN 17098-2:2018 is a European standard developed by CEN that specifies a method for determining the gas permeability of thermoplastic barrier films used in agricultural and horticultural soil disinfection by fumigation. This part of the EN 17098 series focuses on the static technique for measuring film permeability, providing essential guidelines for testing and verifying the effectiveness of barrier films designed to contain fumigants during soil treatment processes.

This standard is critical in ensuring the reliable performance of barrier films in preventing gas leakage, which directly affects soil disinfection efficiency and environmental safety. It is applicable across the agricultural sector, particularly for films designed to control the emission of fumigant gases.

Key Topics

• Scope and Application:
  Applicable to thermoplastic barrier films used for soil disinfection in agricultural and horticultural fumigation processes. It outlines a static test method for evaluating gas permeability.

• Test Principle:
  The film specimen acts as a sealed barrier between two chambers of a transmission cell. A test gas is introduced to one chamber and permitted to permeate through the film. Concentrations in both chambers are monitored over time using gas chromatography to calculate the mass transfer coefficient.

• Test Gases Supported:

  • 1,3-Dichloropropene
  • Dimethyl disulphide (DMDS)
  • Methyl isothiocyanate (MITC)
  • Chloropicrin (PIC)
    The method accommodates other gases if compatibility is verified.

• Apparatus Requirements:

  • Transmission cell with two airtight chambers (120–150 mm diameter, 40–60 mm height)
  • Temperature-controlled environment to maintain consistent test conditions
  • Gas chromatograph for accurate analysis of gas concentrations
  • VOC-meter for leak detection

• Test Conditions:

  • Typical atmospheres at 25 ± 2 °C with relative humidity of either 95 ± 5% or 50 ± 10%
  • Conditioning of specimens and test chamber for at least 24 hours before testing

• Calculation Method:
  The mass transfer coefficient (h) quantifies gas permeability and is calculated mathematically based on concentration changes over time in the source and receiving chambers.

• Acceptance and Reporting:
  At least three test specimens are evaluated, with results averaged to assess conformity with agreed permeability criteria. Detailed test reports are required.

Applications

SIST EN 17098-2:2018 primarily serves manufacturers, quality control laboratories, and regulatory bodies involved in:

• Soil fumigation processes that require effective containment of fumigant gases to enhance pest and pathogen control while minimizing environmental emissions.
• Development and certification of barrier films used in agriculture to ensure compliance with performance standards for permeability.
• Environmental compliance and safety assurance by quantifying permeability characteristics to prevent fumigant leakage during soil disinfection.
• Quality assurance testing for thermoplastic films used in agricultural mulching and soil treatment applications.

This method supports sustainability goals by promoting the use of high-performance films that optimize fumigant retention and reduce off-gassing, thereby protecting human health and the environment.

Related Standards

• EN 17098-1:2018 – Specifications for barrier films used in agricultural and horticultural soil disinfection.
• ASTM E2945-14 – Standard test method for film permeability determination using static permeability cells, which forms the basis of the method described in EN 17098-2.
• EN ISO 472:2013 – Provides vocabulary for plastics, including terminology related to permeability.
• EN ISO 291 – Provides additional environmental test conditions that can be adopted by agreement.

Keywords:

Barrier films, gas permeability, soil disinfection, fumigation, thermoplastic films, agricultural films, horticultural soil treatment, static permeability test, mass transfer coefficient, gas chromatography, environmental safety, fumigant containment.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Kunststoffe - Sperrschichtfolien zur Desinfektion durch Begasung von Landwirtschafts- und Gartenbauböden - Teil 2: Verfahren zur Bestimmung der Durchlässigkeit einer Folie unter Verwendung einer statischen TechnikPlastiques - Films barrière pour la désinfection par fumigation des sols agricoles et horticoles - Partie 2 : Méthode de détermination de la perméabilité d’un film utilisant une technique statiquePlastics - Barrier films for agricultural and horticultural soil disinfection by fumigation - Part 2: Method for film permeability determination using a static technique83.140.10Filmi in folijeFilms and sheets65.060.99Drugi kmetijski stroji in opremaOther agricultural machines and equipmentICS:Ta slovenski standard je istoveten z:EN 17098-2:2018SIST EN 17098-2:2018en,fr,de01-marec-2018SIST EN 17098-2:2018SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 17098-2
January
t r s z ICS
z uä s v rä s r English Version
Plastics æ Barrier films for agricultural and horticultural soil disinfection by fumigation æ Part
tã Method for film permeability determination using a static technique Plastiques æ Films barrière pour la désinfection par fumigation des sols agricoles et horticoles æ Partie
tã Méthode de détermination de la perméabilité d 5un film utilisant une technique statique
Kunststoffe æ Sperrschichtfolien für die Desinfektion durch Begasung von Landwirtschaftsæ und Gartenbauböden æ Teil
tã Verfahren zur Bestimmung der Durchlässigkeit einer Folie unter Verwendung einer statischen Technik This European Standard was approved by CEN on
t r November
t r s yä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Serbiaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Rue de la Science 23,
B-1040 Brussels
t r s z CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
s y r { zæ tã t r s z ESIST EN 17098-2:2018
...
