SIST EN 10163-2:2005

Delivery requirements for surface condition of hot-rolled steel plates, wide flats and sections - Part 2: Plate and wide flats

This Part 2 in addition to Part 1 of this European Standard specifies the delivery requirements which apply to the surface condition of hot-rolled plates and surface condition of the faces of wide flats with thicknesses of 3 mm = t = 400 mm.
NOTE   For plates with a thickness > 400 mm special agreements should be made at the time of the order.

Lieferbedingungen für die Oberflächenbeschaffenheit von warmgewalzten Stahlerzeugnissen (Blech, Breitflachstahl und Profile) - Teil 2: Blech und Breitflachstahl

Zusatzlich zu EN 10163-1 enthalt dieses Dokument die Lieferbedingungen fur die Oberflachenbeschaffenheit
von warmgewalztem Blech und die Oberflachenbeschaffenheit der Flachen von Breitflachstahl in Dicken von
3 mm ¡Ât ¡Â400 mm
ANMERKUNG Fur Bleche in Dicken > 400 mm sollten bei der Bestellung besondere Vereinbarungen getroffen werden.

Conditions de livraison relatives a l'état de surface des tôles, larges plats et profilés en acier laminés a chaud - Partie 2: Tôles et larges plats

En plus de EN 10163-1, le présent document spécifie les exigences de livraison qui s�appliquent à l�état de surface
des tôles laminées à chaud et l�état de surface des faces des larges plats dans la gamme d�épaisseur
3 mm £ t £ 400 mm.
NOTE Pour les tôles d�épaisseur > 400 mm, il est recommandé que les exigences fassent l�objet d�un accord spécial au
moment de la commande.

Zahteve za kakovost površine pri dobavi vroče valjane jeklene pločevine, širokih ploščatih izdelkov in profilov – 2. del: Pločevina in široki ploščati izdelki

General Information

• Status: Published
• Publication Date: 31-Jan-2005
• ICS: 77.140.50 - Flat steel products and semi-products
• ICS: 77.140.70 - Steel profiles
• Technical Committee: IFEK - Ferrous metals
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Feb-2005
• Due Date: 01-Feb-2005
• Completion Date: 01-Feb-2005
• Ref Project: EN 10163-2:2004 - Delivery requirements for surface condition of hot-rolled steel plates, wide flats and sections - Part 2: Plate and wide flats

Relations

• Replaces: SIST EN 10163-2:1997 - Delivery requirements for surface condition of hot rolled steel plates, wide flats and sections - Part 2: Plate and wide flats
• Effective Date: 01-Feb-2005

Overview

EN 10163-2:2004 (CEN) defines delivery requirements for the surface condition of hot‑rolled steel plates and the faces of wide flats with thicknesses 3 mm ≤ t ≤ 400 mm. It supplements EN 10163-1 (General requirements) and establishes criteria for identifying, classifying and repairing surface discontinuities (imperfections and defects) visible on hot‑rolled products. Note: plates thicker than 400 mm require special agreement at order.

Key topics and technical requirements

• Scope and classification
  • Applies to hot‑rolled plates and wide flats; surface requirements are subdivided into Class A and Class B, each with subclasses 1–3 that control permitted repair methods.
• Imperfections vs defects
  • Defines imperfections (shallow/small area) and defects (deeper or larger, and all cracks, shells, seams).
• Depth and area limits
  • Numeric limits are given by product nominal thickness (see the standard’s tables). Example: for very thin plates (3 ≤ t < 8 mm) maximum permissible imperfection depth is 0.2 mm (Table 1); deeper discontinuities have larger limits in Table 2.
• Permissible area percentages
  • Surfaces with limited reductions in remaining thickness may be acceptable up to 15% of inspected area; larger repairs or deeper ground areas are restricted to 2% or lower limits depending on depth.
• Repair methods
  • Grinding: permitted to specified depths; tables (Table 3 and 4) detail maximum grinding allowances below minimum thickness.
  • Welding: controlled by subclass - Subclass 1 allows welding with limits (single welded area ≤ 0.125 m²; total welded area ≤ 0.125 m² or 2% of surface, whichever is greater). Subclass 2 allows welding only if agreed at order; Subclass 3 disallows welding.
• Remaining thickness requirements
  • Class B requires remaining thickness after repair to be at or above the minimum tolerances given in EN 10029 / EN 10051; Class A permits some reductions within defined limits.
• Inspection condition
  • If the purchaser requires all visible discontinuities to be identified and repaired before delivery, products should be ordered descaled.

Applications and who uses it

• Used by steel producers, service centers, fabricators, purchasers, inspection bodies and quality engineers to:
  • Specify surface acceptance criteria in purchase orders
  • Decide allowable repairs (grinding/welding) during production or prior to delivery
  • Create inspection and non‑conformance reports for hot‑rolled plates and wide flats
  • Integrate surface condition requirements into fabrication and coating preparation workflows

Related standards

• EN 10163-1 (General requirements)
• EN 10163-3 (Sections)
• EN 10029 (Tolerances on dimensions, shape and mass)
• EN 10051 (Tolerances for hot‑rolled uncoated plate and strip)

This standard is essential for controlling surface condition, acceptance criteria, and permitted repair procedures on hot‑rolled steel plates and wide flats, ensuring consistent quality in procurement and fabrication.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Lieferbedingungen für die Oberflächenbeschaffenheit von warmgewalzten Stahlerzeugnissen (Blech, Breitflachstahl und Profile) - Teil 2: Blech und BreitflachstahlConditions de livraison relatives a l'état de surface des tôles, larges plats et profilés en acier laminés a chaud - Partie 2: Tôles et larges platsDelivery requirements for surface condition of hot-rolled steel plates, wide flats and sections - Part 2: Plate and wide flats77.140.70Jekleni profiliSteel profiles77.140.50SROL]GHONLFlat steel products and semi-productsICS:Ta slovenski standard je istoveten z:EN 10163-2:2004SIST EN 10163-2:2005en01-februar-2005SIST EN 10163-2:2005SLOVENSKI
STANDARDSIST EN 10163-2:19971DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 10163-2
December 2004 ICS 77.140.50 Supersedes EN 10163-2:1991 English version
Delivery requirements for surface condition of hot-rolled steel plates, wide flats and sections - Part 2: Plate and wide flats
Conditions de livraison relatives à l'état de surface des tôles, larges plats et profilés en acier laminés à chaud - Partie 2: Tôles et larges plats
Lieferbedingungen für die Oberflächenbeschaffenheit von warmgewalzten Stahlerzeugnissen (Blech, Breitflachstahl und Profile) - Teil 2: Blech und Breitflachstahl This European Standard was approved by CEN on 4 November 2004.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the Central Secretariat or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre: rue de Stassart, 36
B-1050 Brussels © 2004 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 10163-2:2004: ESIST EN 10163-2:2005

Classes and subclasses for surface conditions with their respective requirements.10 SIST EN 10163-2:2005
...
