The present document specifies technical characteristics and methods of measurements for audio frequency induction
loop drivers operating from 10 Hz to 9 kHz used in Audio Frequency Induction Loop System (AFILS) with an upper
limit of 45 Arms.
NOTE 1: The object of an AFILS is to transmit an audio signal to people with hearing difficulties. The receiver in
this case is normally a hearing aid or cochlear implant with a built in telecoil, both of which are covered
by ETSI EN 300 422-4 [i.11].
These radio equipment types are capable of operating in the frequency band within the 10 Hz to 9 kHz range:
• with (an) output connection(s);
• for audio frequency baseband transmission (un-modulated and without the use of a carrier).
The present document covers induction loop drivers with output connectors. Integral antenna systems are covered by
ETSI EN 300 422-4 [i.11].
NOTE 2: The relationship between the present document and essential requirements of article 3.2 of Directive
2014/53/EU [i.1] is given in annex A.
