Network Technologies (NTECH) - Network Attachment - e2 interface based on the DIAMETER protocol

The present document specifies a Diameter application for use between a Connectivity session Location and repository
Function (CLF) and an Application Function (AF).

Omrežne tehnologije (NTECH) - Omrežne priključitve - Vmesnik e2 na podlagi protokola DIAMETER

Ta dokument določa uporabo protokola Diameter za uporabo med funkcijo za lokacijo naročnikov (CLF) in funkcijo aplikacije (AF).

General Information

Status
Published
Publication Date
26-Mar-2018
Current Stage
6060 - National Implementation/Publication (Adopted Project)
Start Date
19-Mar-2018
Due Date
24-May-2018
Completion Date
27-Mar-2018

Buy Standard

Standard
ETSI ES 283 035 V3.2.1 (2018-01) - Network Technologies (NTECH); Network Attachment; e2 interface based on the DIAMETER protocol
English language
30 pages
sale 15% off
Preview
sale 15% off
Preview
Standard
ETSI ES 283 035 V3.2.1 (2017-11) - Network Technologies (NTECH); Network Attachment; e2 interface based on the DIAMETER protocol
English language
30 pages
sale 15% off
Preview
sale 15% off
Preview
Standardization document
SIST ES 283 035 V3.2.1:2018
English language
30 pages
sale 10% off
Preview
sale 10% off
Preview

e-Library read for
1 day

Standards Content (sample)

ETSI ES 283 035 V3.2.1 (2018-01)
ETSI STANDARD
Network Technologies (NTECH);
Network Attachment;
e2 interface based on the DIAMETER protocol
