Railway applications - Bodyside entrance systems for rolling stock

This document applies to passenger body side entrance systems of all newly designed railway vehicles such as tram, metro, suburban, mainline and high-speed trains that carry passengers. The requirements of this document also apply to existing vehicles undergoing refurbishment of the door equipment, as far as it is reasonably practicable.
This document also specifies the requirements for testing of entrance systems.
This document makes reference to manual and power operated entrance systems. For manual doors, clauses referring to power operation are not applicable.
This document does not apply to the following:
-   entrance systems for equipment access, inspection or maintenance purposes and for crew only use;
-   doors on freight wagons; and
-   doors or hatches specifically provided for escape under emergency conditions.

Bahnanwendungen - Seiteneinstiegssysteme für Schienenfahrzeuge

Dieses Dokument gilt für Fahrgast-Seiteneinstiegssysteme von allen neu konstruierten Bahnfahrzeugen zur Personenbeförderung, wie z. B. Straßenbahnen, U-Bahnen, S-Bahnen und Regionalbahnen, Fernverkehrsbahnen und Hochgeschwindigkeitsbahnen. Die Anforderungen dieses Dokuments gelten auch, sofern es vernünftigerweise durchführbar ist, für vorhandene Fahrzeuge, bei denen die Türanlage modernisiert wird.
Dieses Dokument legt auch Prüfanforderungen für Einstiegssysteme fest.
Dieses Dokument bezieht sich auf handbetätigte und angetriebene Einstiegssysteme. Bei handbetätigten Türen gelten die Abschnitte, die sich auf einen Antrieb beziehen, nicht.
Dieses Dokument gilt nicht für Folgendes:
—   Einstiegssysteme, die dem Zugang zur Ausrüstung oder zu Inspektions- oder Instandhaltungszwecken oder nur dem Zugang des Zugpersonals dienen;
—   Türen von Güterwagen; und
—   Türen oder Klappen, die ausschließlich für die Flucht in Notfällen vorgesehen sind.

Applications ferroviaires - Systèmes d'accès latéraux pour matériel roulant

Le présent document s’applique aux systèmes d'accès voyageurs latéraux de tous les véhicules ferroviaires de conception nouvelle destinés aux tramways, aux métros, aux trains de banlieue, aux trains grande ligne et grande vitesse transportant des voyageurs. Les exigences du présent document s'appliquent également aux véhicules existants en rénovation, pour autant qu'il soit raisonnable de les satisfaire.
Le présent document spécifie également les exigences pour les essais des systèmes d'accès.
Le présent document fait référence aux systèmes d'accès manuels et motorisés. Pour les portes manuelles, les articles faisant référence à des opérations motorisées ne sont pas applicables.
Le présent document ne s'applique pas :
- aux systèmes d'accès donnant accès aux équipements, ni à ceux destinés aux activités d'inspection ou de maintenance, ni à ceux réservés à l'usage des agents de train ;
- aux portes pour les wagons de fret ; et
- aux portes ou agrès de transbordement spécifiquement prévus pour l’évacuation dans des conditions de secours.

Železniške naprave - Vrata in zapiralni sistemi na železniških potniških vozilih

Ta evropski standard se uporablja za potniška vrata in zapiralne sisteme na novo zasnovanih železniških potniških vozilih, kot so tramvaji, podzemne železnice, primestni in glavni vlaki ter vlaki z velikimi hitrostmi, ki prevažajo potnike. Zahteve tega evropskega standarda veljajo tudi za obstoječa vozila, pri katerih se izvaja obnova opreme vrat, v kolikor je to smiselno izvedljivo.
Ta evropski standard opredeljuje tudi zahteve za preskušanje vrat in zapiralnih sistemov.
Ta evropski standard se navezuje na ročno ter električno krmiljena vrata in zapiralne sisteme. Točke, ki se navezujejo na električno krmiljena vrata, ne veljajo za ročno krmiljena vrata.
Ta evropski standard se ne uporablja za:
– vrata in zapiralne sisteme, ki so namenjeni za dostop do opreme, preglede ali vzdrževanje, ali za tiste, ki jih uporablja samo posadka;
– vrata na tovornih vagonih; in
– vrata ali lopute, ki so posebej namenjeni za izhod v sili.
