Metallic and oxide coatings - Measurement of coating thickness - Microscopical method (ISO 1463:2021)

This document specifies a method for the measurement of the local thickness of metallic coatings, oxide layers, and porcelain or vitreous enamel coatings, by the microscopical examination of cross-sections using an optical microscope.

Metall- und Oxidschichten - Schichtdickenmessung - Mikroskopisches Verfahren (ISO 1463:2021)

Dieses Dokument legt ein Verfahren zur Messung der örtlichen Schichtdicke von metallischen Überzügen, Oxidschichten und Emailschichten durch Untersuchung der Querschnittflächen mit einem Lichtmikroskop fest.
WARNUNG - Die Anwendung dieses Dokumentes kann den Einsatz gefährlicher Stoffe, Arbeitsgänge und Ausrüstungen mit sich bringen. Dieses Dokument erhebt nicht den Anspruch, auf alle Sicherheitsprobleme hinzuweisen, die mit ihrer Anwendung verbunden sind. Es liegt in der Verantwortung des Anwenders dieses Dokumentes, vor ihrer Anwendung geeignete Maßnahmen für die Sicherheit und den Gesundheitsschutz des Personals zu ergreifen.

Revêtements métalliques et couches d'oxyde - Mesurage de l'épaisseur de revêtement - Méthode par coupe micrographique (ISO 1463:2021)

Le présent document spécifie une méthode de mesure de l'épaisseur locale des revêtements métalliques, des couches d'oxyde, et des revêtements de porcelaine ou d'émail vitrifié, par examen de coupes transversales à l'aide d'un microscope optique.
