EN 15610:2009

Railway applications - Noise emission - Rail roughness measurement related to rolling noise generation

1.1 This European Standard specifies a direct method for characterizing the surface roughness of the rail
associated with rolling noise ("acoustic roughness"), in the form of a one-third octave band spectrum.
This standard describes a method for:
a) selecting measuring positions;
b) data acquisition;
c) measurement data processing in order to estimate a set of one-third octave band roughness spectra;
d) presentation of this estimate for comparison with limits of acoustic roughness;
e) comparison with a given upper limit in terms of a one-third octave band wavelength spectrum.
1.2 It is applicable to the:
a) performance testing of reference track sections for the measurement, within a period of three months
before or after roughness characterization, of noise emitted by railway vehicles for acceptance testing
purposes;
b) acceptance of the rail surface condition only in the case where the result of the direct measurement of the
acoustic roughness is regarded as an established acceptance criterion.
1.3 It is not applicable to the:
a) measurement of rail roughness using an indirect method;
b) measurement of combined wheel-rail roughness;
c) analysis of the effect of wheel-rail interaction, such as a “contact filter”;
d) approval of rail reprofiling, including rail grinding operations, except for those where the acoustic
roughness (and not the level of corrugation) is an established approval criterion;
e) characterization of track geometry.
Testing and approval of measuring apparatus are not part of the scope of this standard.

Bahnanwendungen - Geräuschemission - Messung der Schienenrauheit im Hinblick auf die Entstehung von Rollgeräusch

Diese Europäische Norm legt ein direktes Verfahren zur Charakterisierung der Rauheit der Schienenfahrfläche
im Hinblick auf das Rollgeräusch fest (akustische Rauheit), dargestellt in Form eines Terzspektrums.
Die vorliegende Norm gibt ein Verfahren an
- zur Auswahl der Messpositionen,
- zur Messwerterfassung,
- zur Verarbeitung der Messwerte, mit dem Ziel ein Rauheits-Terzspektrum abzuschätzen,
- zur Darstellung der Ergebnisse zum Vergleich mit einer Grenzkurve für die akustische Rauheit,
- zur Bewertung in Bezug auf eine obere Grenzkurve, die als Terzspektrum über der Wellenlänge
vorgegeben ist.
Sie ist anwendbar
- zur Güteprüfung von Referenz-Gleisabschnitten, auf denen im Rahmen der Abnahmeprüfung der Fahrzeuge
(Typprüfung) innerhalb von drei Monaten Messungen der Schallemissionen von Schienenfahrzeugen
durchgeführt werden,
- zur Abnahmeprüfung der Schienenfahrflächen-Qualität, sofern das direkte Messergebnis der akustischen
Rauheit ein vereinbartes Abnahmekriterium ist.
Sie ist nicht anwendbar
- zur Messung der Schienenrauheit mittels eines indirekten Verfahrens,
- zur Messung der kombinierten Rad-Schiene-Rauheit,
- zur Analyse der Auswirkungen der Rad-Schiene-Wechselwirkung, wie etwa der Filterwirkung des Rad-
Schiene-Kontakts,
- zur Abnahmeprüfung der Schienenfahrflächen-Qualität nach erfolgter Reprofilierung, einschließlich
Schienenschleifen, es sei denn, die akustische Rauheit (nicht die Riffel) ist ein vereinbartes Abnahmekriterium,
- zur Beschreibung der Gleisgeometrie.
Prüfung und Zulassung der Messgeräte werden in dieser Norm nicht behandelt.

Applications ferroviaires - Emission de bruit - Mesurage de la rugosité des rails relative à la génération du bruit de roulement

La présente norme européenne spécifie une méthode directe de caractérisation de la rugosité de la surface du rail associée au bruit de roulement (« rugosité acoustique »), sous la forme d’un spectre par bandes de tiers d’octave.
Ce document présente une méthode pour :
-   la sélection des positions de mesurage,
-   l’acquisition de données,
-   le traitement des données de mesurage de façon à estimer un jeu de spectres de rugosité par bandes de tiers d’octave,
-   la présentation de ces estimations pour la comparaison avec des limites de rugosité acoustique,
-   la comparaison avec une limite supérieure donnée, en termes de spectre de longueurs d’ondes par bandes de tiers d’octave.
Il est applicable pour :
-   le test des performances de sections de voies de référence pour le mesurage, réalisé dans une période de trois mois sur cette voie, du bruit émis par les véhicules ferroviaires, dans le cadre d’essais de réception,
-   la réception de la qualité de surface des rails, seulement dans le cas où le résultat de la mesure directe de la rugosité acoustique est considéré comme un critère de réception établi.
Il n’est pas applicable :
-   au mesurage de la rugosité du rail par une méthode indirecte,
-   au mesurage de la rugosité combinée roue-rail,
-   à l’analyse de l’effet de l’interaction roue-rail comme celle du filtre de contact,
-   à la réception d’opérations de reprofilage de rails incluant le meulage, à l’exception de celles où la rugosité acoustique (et non l’usure ondulatoire) est un critère établi de réception,
-   à la caractérisation de la géométrie de la voie.
Les essais et l’homologation des appareils de mesurage ne sont pas du domaine d’application de cette norme.

Železniške naprave - Hrup - Merjenje valovitosti vozne površine tirnice, ki povzroča hrup med vožnjo

General Information

• Status: Withdrawn
• Publication Date: 12-May-2009
• Withdrawal Date: 30-Apr-2019
• ICS: 17.140.30 - Noise emitted by means of transport
• ICS: 93.100 - Construction of railways
• Technical Committee: CEN/TC 256 - Railway applications
• Drafting Committee: CEN/TC 256/WG 3 - Noise emission
• Current Stage: 9960 - Withdrawal effective - Withdrawal
• Completion Date: 01-May-2019
• Directive: 2001/16/EC - Directive 2001/16/EC of the European Parliament and of the Council of 19 March 2001 on the interoperability of the trans-European conventional rail system
• Directive: 2008/57/EC - Directive 2008/57/EC of the European Parliament and of the Council of 17 June 2008 on the interoperability of the rail system within the Community (Recast)
• Directive: 96/48/EC - Interoperability of the trans-European high-speed rail system
• Mandate: M/275 - Mandate to CEN/CENELEC/ETSI for standardization in the field of railway equipment on the interoperability of the Trans-European high-speed rail system
• Mandate: M/334 - Mandate for programming and standardisation addressed to CEN, CENELEC and ETSI in the field of the Interoperability of the trans-european conventional rail system
• Ref Project: SIST EN 15610:2009 - Railway applications - Noise emission - Rail roughness measuement related to rolling noise generation

Relations

• Replaced By: EN 15610:2019 - Railway applications - Acoustics - Rail and wheel roughness measurement related to noise generation
• Effective Date: 18-Jun-2014

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Bahnanwendungen - Geräuschemission - Messung der Schienenrauheit im Hinblick auf die Entstehung von RollgeräuschApplications ferroviaires - Bruit a l'émission - Mesurage de la rugosité des rails relative a la génération du bruit de roulementRailway applications - Noise emission - Rail roughness measuement related to rolling noise generation45.080Rails and railway components17.140.30Emisija hrupa transportnih sredstevNoise emitted by means of transportICS:Ta slovenski standard je istoveten z:EN 15610:2009SIST EN 15610:2009en01-september-2009SIST EN 15610:2009SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 15610
May 2009 ICS 17.140.30; 93.100 English Version
Railway applications - Noise emission - Rail roughness measurement related to rolling noise generation
Applications ferroviaires - Bruit à l'émission - Mesurage de la rugosité des rails relative à la génération du bruit de roulement
Bahnanwendungen - Geräuschemission - Messung der Schienenrauheit im Hinblick auf die Entstehung von Rollgeräusch This European Standard was approved by CEN on 16 April 2009.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2009 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 15610:2009: ESIST EN 15610:2009

Examples of rail defects . 17 Annex B (informative)
Example of program code to implement acoustic roughness processing . 19 B.1 Purpose . 19 B.2 Conditions of use. 19 B.3 List of Matlab program files . 19 B.4 Input data file requirements . 19 B.5 Processing options. 20 B.6 Spectral analysis. 20 B.7 1/3 octave reporting . 20 B.8 Output . 20 SIST EN 15610:2009

Algorithm used to synthesize a one-third octave band spectrum from a corresponding narrow band spectrum . 31 Annex ZA (informative)
Relationship between this
European
Standard and the Essential Requirements
of EU Directive EU 2008/57/EC . 32 Bibliography . 34
1 Scope 1.1 This European Standard specifies a direct method for characterizing the surface roughness of the rail associated with rolling noise ("acoustic roughness"), in the form of a one-third octave band spectrum. This standard describes a method for: a) selecting measuring positions; b) data acquisition; c) measurement data processing in order to estimate a set of one-third octave band roughness spectra; d) presentation of this estimate for comparison with limits of acoustic roughness; e) comparison with a given upper limit in terms of a one-third octave band wavelength spectrum. 1.2 It is applicable to the: a) performance testing of reference track sections for the measurement, within a period of three months before or after roughness characterization, of noise emitted by railway vehicles for acceptance testing purposes; b) acceptance of the rail surface condition only in the case where the result of the direct measurement of the acoustic roughness is regarded as an established acceptance criterion. 1.3 It is not applicable to the: a) measurement of rail roughness using an indirect method; b) measurement of combined wheel-rail roughness; c) analysis of the effect of wheel-rail interaction, such as a “contact filter”; d) approval of rail reprofiling, including rail grinding operations, except for those where the acoustic roughness (and not the level of corrugation) is an established approval criterion; e) characterization of track geometry. Testing and approval of measuring apparatus are not part of the scope of this standard. 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 61260, Electroacoustics — Octave-band and fractional-octave-band filters (IEC 61260:1995) EN ISO 266, Acoustics — Preferred frequencies (ISO 266:1997) SIST EN 15610:2009

3.2 acoustic roughness spectrum )(~λr amplitude of the acoustic roughness expressed as a function of the wavelength λ
3.3 acoustic roughness level Lr level expressed in decibels, given by the following equation:
⋅=202rrlog10RMSrL
(1) where: Lr is the acoustic roughness level in dB,
rRMS is the root mean square roughness in µm,
r0 is the reference roughness; r0 = 1 µm. NOTE This definit
...
