12 V lithium-ion secondary batteries for automotive starting, lighting, ignition (SLI) applications and auxiliary purposes - Part 1: General requirements and methods of test

IEC 63118-1:2024 specifies the general tests and requirements for the performance of lithium secondary batteries with a nominal voltage of 12 V permanently installed in road vehicles not for propulsion. The replacement of secondary batteries permanently installed in road vehicles not for propulsion is covered by this document. The following are typical applications that utilize the batteries under the scope of this document: power source for the starting of internal combustion engines, lighting, stop and start function, on-board auxiliary equipment and energy absorption for regeneration from braking. This document includes: - electrical characteristics tests methods and requirements; - a life duration tests method.

12-Volt-Lithium-Ionen-Sekundärbatterien für Anwendungen und Hilfsanwendungen von Fahrzeug-SLI-Batterien - Teil 1: Allgemeine Anforderungen und Prüfverfahren

Accumulateur ion-lithium 12 V pour les applications de démarrage, d'éclairage, d'allumage (SLI) et les utilisations auxiliaires des véhicules automobiles - Partie 1 - Exigences et méthodes d’essai générales

IEC 63118-1:2024 spécifie les essais et les exigences générales applicables aux performances des accumulateurs au lithium d'une tension nominale de 12 V installés de façon permanente dans les véhicules routiers, mais non destinés à la propulsion. Le remplacement des accumulateurs installés de façon permanente dans les véhicules routiers, mais non destinés à la propulsion, est couvert par le présent document. Les applications suivantes sont des applications types qui utilisent les batteries qui relèvent du domaine d’application du présent document: source électrique pour le démarrage des moteurs à combustion interne, éclairage, fonction de mise en marche et d’arrêt, matériel auxiliaire embarqué et source d’absorption d'énergie pour la récupération par freinage. Le présent document inclut: - les méthodes et les exigences d’essai relatives aux caractéristiques électriques; - une méthode d’essais de durée de vie.

Litij-ionske sekundarne baterije 12 V za zagon, osvetlitev, vžig in pomožne sisteme v avtomobilih - 1. del: Splošne zahteve in preskusne metode

General Information

Status
Published
Publication Date
28-Mar-2024
Current Stage
6060 - Document made available - Publishing
Start Date
29-Mar-2024
Completion Date
29-Mar-2024

Buy Standard

Draft
prEN IEC 63118:2022
English language
13 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)


SLOVENSKI STANDARD
oSIST prEN IEC 63118:2022
01-november-2022
Litij-ionske sekundarne baterije 12 V za zagon, osvetlitev, vžig in pomožne sisteme
v avtomobilih - 1. del: Splošne zahteve in preskusne metode
12V Lithium-ion Secondary Battery for Automotive Starting, Lighting, Ignition (SLI)
Applications and Auxiliary purposes Part 1 - General requirements and methods of test
Accumulateur ion-lithium 12 V pour les applications de démarrage, d'éclairage,
d'allumage (SLI) et les utilisations auxiliaires des véhicules automobiles – Partie 1 –
Exigences et méthodes d’essai générales
Ta slovenski standard je istoveten z: prEN IEC 63118:2022
ICS:
29.220.30 Alkalni sekundarni členi in Alkaline secondary cells and
baterije batteries
oSIST prEN IEC 63118:2022 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

oSIST prEN IEC 63118:2022
oSIST prEN IEC 63118:2022
21/1151/CDV
COMMITTEE DRAFT FOR VOTE (CDV)
PROJECT NUMBER:
IEC 63118 ED1
DATE OF CIRCULATION: CLOSING DATE FOR VOTING:
2022-09-02 2022-11-25
SUPERSEDES DOCUMENTS:
21/1089/CD, 21/1146/CC
IEC TC 21 : SECONDARY CELLS AND BATTERIES
SECRETARIAT: SECRETARY:
France Mr Yves Boudou
OF INTEREST TO THE FOLLOWING COMMITTEES: PROPOSED HORIZONTAL STANDARD:

Other TC/SCs are requested to indicate their interest, if any,
in this CDV to the secretary.
FUNCTIONS CONCERNED:
EMC ENVIRONMENT QUALITY ASSURANCE SAFETY
SUBMITTED FOR CENELEC PARALLEL VOTING NOT SUBMITTED FOR CENELEC PARALLEL VOTING
Attention IEC-CENELEC parallel voting
The attention of IEC National Committees, members of
CENELEC, is drawn to the fact that this Committee Draft for
Vote (CDV) is submitted for parallel voting.
The CENELEC members are invited to vote through the
CENELEC online voting system.
This document is still under study and subject to change. It should not be used for reference purposes.
Recipients of this document are invited to submit, with their comments, notification of any relevant patent rights of which they
are aware and to provide supporting documentation.

TITLE:
12V Lithium-ion Secondary Battery for Automotive Starting, Lighting, Ignition (SLI) Applications and
Auxiliary purposes
Part 1 - General requirements and methods of test

PROPOSED STABILITY DATE: 2027
NOTE FROM TC/SC OFFICERS:
electronic file, to make a copy and to print out the content for the sole purpose of preparing National Committee positions.
You may not copy or "mirror" the file or printed version of the document, or any part of it, for any other purpose without
permission in writing from IEC.

oSIST prEN IEC 63118:2022
21/1151/CDV – 2 – IEC CDV 63118 © IEC 2022

1 CONTENTS
3 FOREWORD . 4
4 1 Scope . 6
5 2 Normative references . 6
6 3 Terms and definitions . 6
7 4 Parameter measurement tolerances . 8
8 5 Marking and designation . 8
9 6 Electrical tests . 8
10 6.1 General . 8
11 6.2 Charging procedure for test purposes . 8
12 6.3 Capacity . 9
13 6.3.1 Method . 9
14 6.3.2 Acceptance criteria . 9
15 6.4 Discharge performance at low temperature . 9
16 6.4.1 Discharge performance at -18 °C. . 9
17 6.4.1.1 Method. 9
18 6.4.1.2 Acceptance criteria . 9
19 6.4.2 Discharge performance at -29°C. . 9
20 6.4.2.1 Method. 9
21 6.4.2.2 Acceptance criteria . 9
22 6.5 Charge performance at 0 °C and -18 °C . 10
23 6.5.1 Charge performance at 0 °C . 10
24 6.5.1.1 Method. 10
25 6.5.1.2 Acceptance criteria . 10
26 6.5.2 Charge performance at -18 °C . 10
27 6.5.2.1 Method. 10
28 6.5.2.2 Acceptance criteria . 10
29 6.6 Charge retention . 10
30 6.6.1 Method . 10
31 6.6.2 Acceptance criteria: . 11
32 6.7 Endurance . 11
33 6.7.1 Endurance in cycles . 11
34 6.7.1.1 Method. 11
35 6.7.1.2 Check-up sequence . 11
36 6.7.1.2.1 Capacity measurement . 11
37 6.7.1.2.2 Discharge performance at low temperature
38 measurement . 11
39 6.7.1.2.3 Acceptance criteria . 12
40 6.7.2 Floating-calendar life test . 12
41 6.7.2.1 Method. 12
42 6.7.2.2 Check-up sequence . 12
43 6.7.2.2.1 Capacity measurement . 12
44 6.7.2.2.2 Discharge performance at low temperature
45 measurement . 12
46 6.7.2.2.3 Acceptance criteria . 13
47 7 Type test conditions . 13

oSIST prEN IEC 63118:2022
21/1151/CDV – 3 – IEC CDV 63118 © IEC 2022

48 7.1 General . 13
49 7.2 Test items . 13
51 Table 1 – Type test . 1Error! Bookmark not defined.
oSIST prEN IEC 63118:2022
21/1151/CDV – 4 – IEC CDV 63118 © IEC 2022

54 INTERNATIONAL ELECTROTECHNICAL COMMISSION
55 ____________
57 12V Lithium-ion Secondary Battery for Automotive
58 Starting, Lighting, Ignition (SLI) Applications and
59 Auxiliary purposes
60 Part 1 - General requirements and methods of test
63 FOREWORD
64 1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
65 all national electrotechnical committees (IEC National Committees). The object of IEC is to promote international
66 co-operation on all questions concerning standardization in the electrical and electronic fields. To this end and
67 in addition to other activities, IEC publishes International Standards, Technical Specifications, Technical Reports,
68 Publicly Available Specifications (PAS) and Guides (hereafter referred to as "IEC Publication(s)"). Their
69 preparation is entrusted to technical committees; any IEC National Committee interested in the subject dealt with
70 may participate in this preparatory work. International, governmental and non-governmental organizations liaising
71 with the IEC also participate in this preparation. IEC collaborates closely with the International Organization for
72 Standardization (ISO) in accordance with conditions determined by agreement between the two organizations.
73 2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
74 consensus of opinion on the relevant subjects since each technical committee has representation from all
75 interested IEC National Committees.
76 3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
77 Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
78 Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
79 misinterpretation by any end user.
80 4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
81 transparently to the maximum extent possible in their national and regional publications. Any divergence between
82 any IEC Publication and the corresponding national or regional publication shall be clearly indicated in the latter.
83 5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
84 assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
85 services carried out by independent certification bodies.
86 6) All users should ensure that they have the latest edition of this publication.
87 7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
88 members of its technical committees and IEC National Committees for any personal injury, property damage or
89 other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
90 expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC P ublications.
91 8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
92 indispensable for the correct application of this publication.
93 9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of patent
94 rights. IEC shall not be held responsible for identifying any or all such patent rights.
96 International Standard IEC 63118 Ed.1 has been prepared by IEC technical committee 21:
97 Secondary cells and batteries.
98 The text of this International Standard is based on the following documents:
FDIS Report on voting
100 Full information on the voting for the approval of this International Standard can be found in the
101 report on voting indicated in the above table.
102 This document has been drafted in accordance with the ISO/IEC Directives, Part 2.

oSIST prEN IEC 63118:2022
21/1151/CDV – 5 – IEC CDV 63118 © IEC 2022

103 The committee has decided that the contents of this document will remain unchanged until the
104 stability date indicated on the IEC website under "http://webstore.iec.ch" in the data related to
105 the specific document. At this date, the document will be
106 • reconfirmed,
107 • withdrawn,
108 • replaced by a revised edition, or
109 • amended.
IMPORTANT – The 'colour inside' logo on the cover page of this publication indicates
that it contains colours which are considered to be useful for the correct understanding
of its contents. Users should therefore print this document using a colour printer.
oSIST prEN IEC 63118:2022
21/1151/CDV – 6 – IEC CDV 63118 © IEC 2022

112 12V Lithium-ion Secondary Battery for Automotive
113 Starting, Lighting, Ignition (SLI) Applications and
114 Auxiliary purposes
115 Part 1: General requirements and methods of test
119 1 Scope
120 This International Standard specifies general tests and requirements for the performance of
121 lithium secondary batteries with a nominal voltage of 12 V permanently installed in road vehicles
122 not for propulsion. Replacement of secondary batteries permanently installed in road vehicles
123 not for propulsion are covered by this standard.
124 The following are typical applications that utilize the batteries under the scope of this standard.
125 A power source for the starting of internal combustion engines, lighting, stop & start function,
126 on-board auxiliary equipment and energy absorption for regeneration from braking.
127 The batteries primarily used for propulsion of electric vehicles (EV) including battery electric
128 vehicles (BEV), hybrid electric vehicles (HEV), and plug-in hybrid electric vehicles (PHEV) are
129 not covered by this standard.
130 This standard includes:
131 -electrical characteristics tests methods and requirements
132 -life duration tests method
133 This standard does not include:
134 -dimensions
135 -system communication protocol
136 -safety
...
