IEC 60034-8:2007

Rotating electrical machines - Part 8: Terminal markings and direction of rotation

Applies to a.c. and d.c. machines and specifies rules for the identification of winding connection points; marking of winding terminals; direction of rotation; relationship between terminal markings and direction of rotation; terminal marking of auxiliary devices; connection diagrams of machines for common applications. The main change with respect to the previous edition consists of changed terminal markings for d.c. machines.

Machines électriques tournantes - Partie 8: Marques d'extrémité et sens de rotation

S'applique aux machines à courant continu et à courant alternatif et spécifie les règles d'identification des points de couplage; le marquage des bornes d'enroulement; le sens de rotation; la relation entre les marques d'extrémité et le sens de rotation; les marques d'extrémité des appareils auxiliaires; les schémas de connexion des machines pour applications communes. La modification principale par rapport à l'édition précédente consiste du marquage des extrémités modifié pour les machines à courant continu.
