SIST EN 62820-1-1:2017
(Main)Building intercom systems - Part 1-1: General requirements
Building intercom systems - Part 1-1: General requirements
IEC 62820-1-1:2016 specifies the technical requirements for the composition, functions, performance, and test methods of general building intercom systems. This part is applicable to the general intercom systems for building entry in residential or commercial buildings. General building intercom systems have been classified into two grades: Grade 1 adopts lower requirements to cover door-entry-systems not used for relevant security applications while grade 2 adopts higher requirements for building intercom systems for security applications. Each grade may adopt different functional and performance requirements, test methods and normative references.
Gebäude-Sprechanlagen - Teil 1-1: Generelle Systemanaforderungen
Systèmes d'interphone de bâtiment - Partie 1-1: Exigences du système - Généralités
L'IEC 62820-1-1:2016 spécifie les exigences techniques relatives à la composition, aux fonctions, aux performances, et aux méthodes d'essai des systèmes généraux d'interphone de bâtiment. La présente partie est applicable aux systèmes généraux d'interphone pour entrée de bâtiments résidentiels ou commerciaux. Les systèmes généraux d'interphone de bâtiment ont été classés en deux niveaux. Le niveau 1 adopte des exigences moins strictes pour couvrir les systèmes de contrôle d'accès non utilisés pour les applications de sécurité correspondantes, le niveau 2 s'appuyant sur des exigences plus strictes pour les systèmes d'interphone de bâtiment destinés aux applications de sécurité. Chaque niveau peut s'appuyer sur des exigences fonctionnelles et de performances, des méthodes d'essai et des références normatives différentes.
Notranja komunikacija v stavbah - 1-1. del: Splošne zahteve
Ta del standarda IEC 62820 določa tehnične zahteve za sestavo, funkcije, zmogljivost in preskusne metode za splošno notranjo komunikacijo v stavbah.
Ta del se uporablja za splošno notranjo komunikacijo v stavbah pri vhodu v stanovanjske ali poslovne stavbe.
Domofon je enostavna vrsta priročnega sistema notranje komunikacije v stavbah, ki je namenjen predvsem udobju uporabnika. Ta dokument v delu 1-1 razvršča splošne sisteme notranje komunikacije v stavbah v dva razreda. 1. razred zajema nižje zahteve za domofone glede varnosti, medtem ko 2. razred zajema višje zahteve za sisteme notranje komunikacije v stavbah glede varnosti. Vsak razred lahko zajema različne zahteve glede funkcionalnosti in zmogljivosti, preskusne metode in zveze s standardi.
OPOMBA: različne zahteve med 1. in 2. razredom so povzete v preglednici C.1.
General Information
Relations
Standards Content (Sample)
SLOVENSKI STANDARD
01-januar-2017
Notranja komunikacija v stavbah - 1-1. del: Splošne zahteve
Building intercom systems - Part 1-1: General requirements
Gebäude-Sprechanlagen - Teil 1-1: Generelle Systemanaforderungen
Systèmes d'interphone de bâtiment - Partie 1-1: Exigences du système - Généralités
Ta slovenski standard je istoveten z: EN 62820-1-1:2016
ICS:
35.240.67 Uporabniške rešitve IT v IT applications in building
gradbeništvu and construction industry
97.120 Avtomatske krmilne naprave Automatic controls for
za dom household use
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
EUROPEAN STANDARD EN 62820-1-1
NORME EUROPÉENNE
EUROPÄISCHE NORM
November 2016
ICS 13.320
English Version
Building intercom systems - Part 1-1: System requirements -
General
(IEC 62820-1-1:2016)
Systèmes d'interphone de bâtiment - Partie 1-1: Exigences Gebäude-Sprechanlagen - Teil 1-1: Generelle
du système - Généralités Systemanaforderungen
(IEC 62820-1-1:2016) (IEC 62820-1-1:2016)
This European Standard was approved by CENELEC on 2016-10-27. CENELEC members are bound to comply with the CEN/CENELEC
Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation
under the responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the
same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia,
Lithuania, Luxembourg, Malta, the Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Turkey and the United Kingdom.
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Avenue Marnix 17, B-1000 Brussels
© 2016 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
Ref. No. EN 62820-1-1:2016 E
European foreword
The text of document 79/559/FDIS, future edition 1 of IEC 62820-1-1, prepared by IEC/TC 79 "Alarm
and electronic security systems" was submitted to the IEC-CENELEC parallel vote and approved by
CENELEC as EN 62820-1-1:2016.
The following dates are fixed:
(dop) 2017-07-27
• latest date by which the document has to be
implemented at national level by
publication of an identical national
standard or by endorsement
• latest date by which the national (dow) 2019-10-27
standards conflicting with the
document have to be withdrawn
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CENELEC [and/or CEN] shall not be held responsible for identifying any or all such
patent rights.
Endorsement notice
The text of the International Standard IEC 62820-1-1:2016 was approved by CENELEC as a
European Standard without any modification.
In the official version, for Bibliography, the following notes have to be added for the standards indicated:
IEC 62676-4:2014 NOTE Harmonized as EN 62676-4:2015.
Annex ZA
(normative)
Normative references to international publications
with their corresponding European publications
The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any amendments) applies.
NOTE 1 When an International Publication has been modified by common modifications, indicated by (mod), the relevant
EN/HD applies.
NOTE 2 Up-to-date information on the latest versions of the European Standards listed in this annex is available here:
www.cenelec.eu.
Publication Year Title EN/HD Year
IEC 60065 (mod) 2014 Audio, video and similar electronic EN 60065 2014
apparatus - Safety requirements
IEC 60529 1989 Degrees of protection provided by EN 60529 1991
enclosures (IP Code)
- - + corrigendum May 1993
+ A1 1999 + A1 2000
+ A2 2013 + A2 2013
IEC 60950-1 (mod) 2005 Information technology equipment - Safety EN 60950-1 2006
- Part 1: General requirements
- - + A11 2009
- - + A12 2011
- - + AC 2011
IEC 61000-6-1 - Electromagnetic compatibility (EMC) Part FprEN 61000-6-1 -
6-1: Generic standards - Immunity
standard for residential, commercial and
light-industrial environments
IEC 61000-6-3 - Electromagnetic compatibility (EMC) -- Part EN 61000-6-3 -
6-3: Generic standards - Emission
standard for residential, commercial and
light-industrial environments
IEC 62262 - Degrees of protection provided by EN 62262 -
enclosures for electrical equipment against
external mechanical impacts (IK code)
IEC 62599-1 - Alarm systems -- Part 1: Environmental - -
test methods
IEC 62599-2 - Alarm systems -- Part 2: Electromagnetic - -
compatibility - Immunity requirements for
components of fire and security alarm
systems
ISO 12233 2014 Photography - Electronic still picture - -
imaging - Resolution and spatial frequency
responses
ITU-T P.501 - Test signals for use in telephonometry - -
ITU-T P.50 - Artificial voices - -
ITU-T P.51 1996 Artificial mouth - -
ITU-T P.79 2007 Calculation of loudness ratings for - -
telephone sets
IEC 62820-1-1 ®
Edition 1.0 2016-09
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
colour
inside
Building intercom systems –
Part 1-1: System requirements – General
Systèmes d'interphone de bâtiment –
Partie 1-1: Exigences du système – Généralités
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
INTERNATIONALE
ICS 13.320 ISBN 978-2-8322-3626-0
– 2 – IEC 62820-1-1:2016 © IEC 2016
CONTENTS
FOREWORD . 5
INTRODUCTION . 7
1 Scope . 8
2 Normative references. 8
3 Terms, definitions and abbreviations . 9
3.1 Terms and definitions . 9
3.2 Abbreviations . 11
4 Functional requirements . 11
4.1 Basic functional requirements . 11
4.1.1 General . 11
4.1.2 Requirements for building intercom system with SMU . 12
4.2 Additional functions . 13
5 Performance requirements . 13
5.1 Audio characteristics . 13
5.1.1 Acoustic pressure level . 13
5.1.2 Overall loudness rating (OLR) . 13
5.1.3 Overall sensitivity . 13
5.1.4 Frequency response . 15
5.1.5 Acoustic distortion . 15
5.1.6 Channel S/N ratio . 15
5.1.7 Sidetone masking rating (STMR) . 15
5.1.8 Idle channel noise . 15
5.1.9 Ringtone sound pressure . 15
5.1.10 Acoustic stability (Larsen effect) . 15
5.1.11 Acoustic safety . 15
5.2 Video characteristics . 16
5.2.1 Image resolution . 16
5.2.2 Gray scale . 16
5.2.3 Focus distance . 16
5.2.4 Color reproduction . 16
5.2.5 Environmental illuminance adaptability . 16
5.3 Environmental adaptability requirements . 16
5.3.1 Environmental classes . 16
5.3.2 Environmental adaptability . 16
5.4 Safety requirements . 17
5.5 Additional protection under fault conditions . 17
5.6 Electromagnetic compatibility requirements . 18
5.6.1 Electromagnetic compatibility immunity requirements . 18
5.6.2 Additional electromagnetic compatibility immunity requirements . 18
5.6.3 Electromagnetic compatibility emission requirements . 18
5.7 Markings and mechanical structural requirements . 18
5.7.1 Markings . 18
5.7.2 Mechanical structure . 19
5.7.3 Enclosure protection capability . 19
5.7.4 Anti-vandalism . 19
6 Test methods . 19
IEC 62820-1-1:2016 © IEC 2016 – 3 –
6.1 Test conditions . 19
6.1.1 Test environmental conditions . 19
6.1.2 Electrical connection . 20
6.2 Function test . 20
6.3 Audio characteristics test . 20
6.4 Video characteristics test . 20
6.5 Environmental adaptability test . 20
6.6 Safety test . 20
6.7 Protection under fault conditions test . 20
6.8 Electromagnetic compatibility test . 20
6.8.1 Electromagnetic compatibility immunity test . 20
6.8.2 Additional electromagnetic compatibility immunity test . 20
6.8.3 Electromagnetic compatibility emission test . 21
6.9 Markings and mechanical structure test . 21
6.9.1 Markings and scrub resistance test . 21
6.9.2 Mechanical structure test . 21
6.9.3 Enclosure protection capability test . 21
6.9.4 Anti-vandalism test . 21
7 Documentation . 22
Annex A (normative) Test of audio characteristics . 23
A.1 Test conditions . 23
A.2 Acoustic pressure level test . 23
A.2.1 Methods . 23
A.2.2 Calibration of test equipment . 24
A.2.3 Test of the acoustic pressure level . 24
A.3 Overall loudness rating (OLR) test . 25
A.3.1 Measurement of sound pressure P at the MRP . 25
m
A.3.2 Measurement of output sound pressure P of the hands-free EUT . 25
o
A.3.3 Measurement of output sound pressure P of the handset EUT . 26
e
A.3.4 Calculations of the OLR . 27
A.4 Overall sensitivity test . 28
A.4.1 Test of the overall sensitivity at the hands-free EUT . 28
A.4.2 Test of the overall sensitivity at the handset EUT . 28
A.5 Frequency response test . 28
A.6 Acoustic distortion test . 29
A.7 Channel S/N ratio test . 29
A.8 Sidetone masking rating (STMR) test . 29
A.9 Idle channel noise test . 30
A.10 Ringtone sound pressure test . 30
A.11 Acoustic stability (Larsen Effect) test . 30
A.12 Acoustic safety test . 31
Annex B (normative) Test of video characteristics . 33
B.1 Test conditions . 33
B.2 Connection of the tested system . 33
B.3 Image resolution test . 33
B.4 Gray scale test . 34
B.5 Focus distance test . 34
B.6 Color reproduction test . 35
B.7 Environmental illumination adaptability test . 36
– 4 – IEC 62820-1-1:2016 © IEC 2016
Annex C (normative) Different requirements between grade 1 and grade 2 . 37
Annex D (normative) Safety requirements correspondence in IEC 60065 or
IEC 60950-1 . 39
Bibliography . 40
Figure 1 – Overall sensitivity at the hands-free unit . 14
Figure 2 – Overall sensitivity at the handset unit . 14
Figure A.1 – Measurement of sound pressure P at the MRP . 25
m
Figure A.2 – Measurement of output sound pressure P when connected with the
o
handset unit . 25
Figure A.3 – Measurement of output sound pressure P when connected with the
o
hands-free unit . 26
Figure A.4 – Measurement of output sound pressure P when connected with the
e
handset unit . 26
Figure A.5 – Measurement of output sound pressure P when connected with the
e
hands-free unit . 26
Figure A.6 – Measurement of STMR at the handset EUT . 30
Figure A.7 – Measurement of ringtone sound pressure . 30
Figure A.8 – Acoustic stability test for handset EUT . 31
Figure A.9 – Acoustic stability test for hands-free EUT . 31
Figure A.10 – Acoustic safety test . 32
Figure B.1 – Connection diagram for test of video characteristics . 33
Figure B.2 – TE170 test chart . 34
Figure B.3 – TE83 test chart . 34
Figure B.4 – Focus test chart . 35
Figure B.5 – Position of the external ring area . 35
Figure B.6 – TE106 test chart . 36
Table 1 – Environmental adaptability requirements . 17
Table A.1 – Factors for OLR . 28
Table C.1 – Requirements of grade 1 and grade 2 . 37
Table D.1 – Correspondence between IEC 60065 and IEC 60950-1 . 39
IEC 62820-1-1:2016 © IEC 2016 – 5 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
BUILDING INTERCOM SYSTEMS –
Part 1-1: System requirements – General
FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote international
co-operation on all questions concerning standardization in the electrical and electronic fields. To this end and in
addition to other activities, IEC publishes International Standards, Technical Specifications, Technical Reports,
Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC Publication(s)”). Their
preparation is entrusted to technical committees; any IEC National Committee interested in the subject dealt with
may participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. IEC collaborates closely with the International Organization for
Standardization (ISO) in accordance with conditions determined by agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence between
any IEC Publication and the corresponding national or regional publication shall be clearly indicated in the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and expenses
arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of patent
rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 62820-1-1 has been prepared by IEC technical committee 79: Alarm
and electronic security systems.
The text of this standard is based on the following documents:
FDIS Report on voting
79/559/FDIS 79/563/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.
A list of all parts in the IEC 62820 series, published under the general title Building intercom
systems, can be found on the IEC website.
– 6 – IEC 62820-1-1:2016 © IEC 2016
The committee has decided that the contents of this publication will remain unchanged until the
stability date indicated on the IEC website under "http://webstore.iec.ch" in the data related to
the specific publication. At this date, the publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
IMPORTANT – The 'colour inside' logo on the cover page of this publication indicates
that it contains colours which are considered to be useful for the correct understanding
of its contents. Users should therefore print this document using a colour printer.
IEC 62820-1-1:2016 © IEC 2016 – 7 –
INTRODUCTION
This part of IEC 62820 specifies the technical requirements for building intercom systems and
equipment used for building entry. Building intercom systems can function independently and
may be extendable to support building security management functions, e.g. extendable with
security management unit (SMU) operated by security staff (door-man, concierge,
security-guard, porter, etc.), or in conjunction with other systems as per the security
requirements of the building. It may consist of: Visitor call unit (VCU), user receiver unit (URU),
SMU, power supply, auxiliary device as well as interface-unit to other security-systems.
The IEC 62820 series of standards set out the technical requirements for the composition,
functions, performance, test methods of building intercom systems for building entry and
application guidelines and consist of five parts:
Part 1-1: System requirements – General
Part 1-2: System requirements – IP building intercom systems
Part 2: Requirements for advanced security building intercom systems
Part 3-1: Application guidelines – General
Part 3-2: Application guidelines – Advanced security building intercom systems
The Part 1-1 of IEC 62820 is based on Chinese standard GB/T 31070.1-2014 and European
standard EN 50486:2008.
– 8 – IEC 62820-1-1:2016 © IEC 2016
BUILDING INTERCOM SYSTEMS –
Part 1-1: System requirements – General
1 Scope
This Part of IEC 62820 specifies the technical requirements for the composition, functions,
performance, and test methods of general building intercom systems.
This part is applicable to the general intercom systems for building entry in residential or
commercial buildings.
Door-Entry-System (DES) is a simple kind of convenient Building-Intercom-System (BIS) mainly
for user’s comfort. This document has classified the general building intercom systems into two
grades in Part 1-1. Grade 1 adopts lower requirements to cover DES not used for relevant
security applications while grade 2 adopts higher requirements for building intercom systems for
security applications. Each grade may adopt different functional and performance requirements,
test methods and normative references.
NOTE The different requirements between grade 1 and grade 2 are summarized in Table C.1.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies.
For undated references, the latest edition of the referenced document (including any
amendments) applies.
IEC 60065:2014, Audio, video and similar electronic apparatus – Safety requirements
IEC 60529:1989, Degrees of protection provided by enclosures (IP Code)
IEC 60529:1989/AMD1:1999
IEC 60529:1989/AMD2:2013
IEC 60950-1:2005, Information technology equipment – Safety – Part 1: General requirements
IEC 61000-6-1, Electromagnetic compatibility (EMC) – Part 6-1: Generic standards – Immunity
for residential, commercial and light-industrial environments
IEC 61000-6-3, Electromagnetic compatibility (EMC) – Part 6-3: Generic standards – Emission
standard for residential, commercial and light-industrial environments
IEC 62262, Degrees of protection provided by enclosures for electrical equipment against
external mechanical impacts (IK code)
IEC 62599-1, Alarm systems – Part 1: Environmental test methods
IEC 62599-2, Alarm systems – Part 2: Electromagnetic compatibility – Immunity requirements
for components of fire and security alarm systems
ISO 12233:2014, Photography – Electronic still picture imaging – Resolution and spatial
frequency responses
IEC 62820-1-1:2016 © IEC 2016 – 9 –
ITU-T P.50, Artificial voices
ITU-T P.51-1996, Artificial mouth
ITU-T P.79-2007, Calculation of loudness ratings for telephone sets
ITU-T P.501, Test signals for use in telephonometry
3 Terms, definitions and abbreviations
3.1 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following
addresses:
• IEC Electropedia: available at http://www.electropedia.org/
• ISO Online browsing platform: available at http://www.iso.org/obp
3.1.1
2-way speech
speech between any two units (VCU, URU or SMU) in each direction which may be simultaneous
or non-simultaneous
3.1.2
acoustic distortion
distortion of signals at the receiving terminal of the system as a result of system transmission
non-linearity and ground noise, expressed as a ratio percentage of the harmonic signal and
ground noise at the receiving terminal in proportion to the overall sound pressure
3.1.3
acoustic pressure level
measurement of the acoustic pressure level generated by the equipment under test (EUT) in
normal conditions
3.1.4
artificial ear
device used to calibrate the receiver and containing an acoustic coupler and a calibrated
microphone used to measure sound pressure
Note 1 to entry: Its overall acoustic impedance within a given frequency band is similar to that of the average human
ear, and its characteristics comply with the requirements of type 1 or type 3.2 provided by Article 5 of
ITU-T P.57-2011.
3.1.5
artificial mouth
analogue device the sound characteristics of which are similar to the directivity and radiation
pattern of the average human mouth
Note 1 to entry: It conforms to the requirements set forth in Article 5 of ITU-T P.51-1996.
3.1.6
auxiliary device
device which extends or facilitates additional functions and interfaces of a building intercom
rd
system, such as communications, remote control, 3 party devices interfaces etc.
– 10 – IEC 62820-1-1:2016 © IEC 2016
3.1.7
building intercom system
BIS
system designed for entry communication in residential or commercial buildings which provides
addressing calls, speech and optional video function and is equipped with an electronic
unlocking device
3.1.8
channel S/N
sound pressure ratio between signal and ground noise at the receiving terminal under excitation
of the nominal sound pressure at the transmitting terminal, expressed in dB
3.1.9
handset unit
device typically coupled to the ear by hand as can be a handset URU or handset SMU
3.1.10
hands-free unit
device that does not need to use the hand during the communication as can be a VCU,
hands-free URU or hands-free SMU
3.1.11
idle channel noise
noise expressed in dB(A) which is received in the terminal after the channel connection is
established when no signal is transferred
3.1.12
loudness rating guard-ring position
LRGP
fixed position in which the handset of the URU or SMU is used to measure the rating of system
loudness
[SOURCE: adapted from ITU-T P.64:2007]
3.1.13
overall loudness rating
OLR
measurement of the loudness in the entire channel from the reference point of the mouth at the
transmitting terminal to the ear reference point (ERP) at the receiving terminal, expressed in dB
[SOURCE: adapted from ITU-T P.79:2007]
3.1.14
overall sensitivity
gain of the sound pressure at the reference point of the ear at the reception terminal relative to
the excitation sound pressure at the mouth reference point (MRP) at the transmitting terminal,
expressed in dB
Note 1 to entry: It is a function of frequency.
3.1.15
security management unit
SMU
device which can be addressed from the call unit (VCU, URU or SMU), provides the means of
addressing the calling signal to the desired receiver unit(s) which can be URU or SMU, 2-way
speech, the activation of the audio and/or video connection with the VCU and the means to
initiate remote unlocking of the controlled entrance
IEC 62820-1-1:2016 © IEC 2016 – 11 –
3.1.16
sidetone masking rating
STMR
measurement of sidetone loudness after factoring in the masking effects of the human head on
sidetone, expressed in dB
[SOURCE: adapted from ITU-T P.79:2007]
3.1.17
user receiver unit
URU
addressable user device which provides 2-way speech with optional video, and a means to
initiate remote unlocking of the controlled entrance
3.1.18
visitor call unit
VCU
device installed outside a controlled entrance which provides the means of addressing the
calling signal to the desired URU or SMU and 2-way speech with optional video capture
Note 1 to entry: The device can also provide the means of unlocking the controlled entrance and other function(s) or
these function(s) can be contained within a separate associated device normally located within the controlled
premises and which can also contain the system power supply.
3.2 Abbreviations
BIS building intercom system
DES door entry system
ERP ear reference point
EUT equipment under test
Lpm level (sound) pressure mean
LRGP loudness rating guard-ring position
MRP mouth reference point
OLR overall loudness rating
PIN personal identification number
SMU security management unit
STMR sidetone masking rating
URU user receiver unit
VCU visitor call unit
4 Functional requirements
4.1 Basic functional requirements
4.1.1 General
A building intercom system shall meet the following requirements:
a) Call function
The VCU shall be able to address the desired URU. The VCU shall be able to produce a
visible and/or audible call alert signal. The URU shall be able to produce a response prompt
signal that can be visible, audible, etc.
b) Speech function
– 12 – IEC 62820-1-1:2016 © IEC 2016
2-way speech shall be provided, which can be either non-simultaneous or simultaneous. It
may be of limited duration controlled by a system timer such that the speech channel cannot
be accidentally occupied for an unlimited time.
c) Unlocking function
The unlocking function shall be provided with an electric or electronic signal to an electric or
electronic locking device for securing a building entrance. This function shall be controlled
by URU at the user’s discretion. In grade 2 the URU shall be in communication with the VCU
to perform the unlocking function.
The unlocking function could also be activated by other means:
1) The VCU may be provided with a means for authorized users to directly activate the
unlocking function, such as by PIN code or secure proximity card or other security grade
dependent means.
2) Request to exit button or switch located inside the controlled area and normally adjacent
to the controlled entrance. According to the security requirements of the installation this
button or switch may be a simple switch or require a PIN or other secure means of
operation.
3) Other system signal such as an activated fire alarm signal, a building evacuation signal
etc.
d) Nighttime operability
Grade 1: No requirement;
Grade 2: The VCU shall provide illumination or visible prompts to facilitate the visitor’s
operations at night.
e) Video and image recording and replaying function
When a URU is equipped with a video function it shall be able to display images captured by
the VCU. The functions of storing, replaying the visitor’s images are optional.
f) Operational indication
The system shall provide the operating and operational information to the visitor. The VCU
should provide a comfort indication that the call is being processed, such as a low level
audible tone and/ or visible indication. The VCU should also give audio and/or visible
indication when the lock has been released and that entry to the premises is permitted.
NOTE The VCU can give clear indication or prompts to the visitor how to address the desired URU.
g) Anti listen-in
Grade 1: No requirement.
Grade 2: After connecting the VCU with the URU, the audio information shall not be
monitored by other URU connected to the system.
4.1.2 Requirements for building intercom system with SMU
A building intercom system with SMU shall meet the following requirements:
a) The SMU shall be able to address and initiate calls to selected URU. The VCU and the URU
shall be able to initiate calls to the SMU. If multiple SMU are connected to the system, they
shall be able to call each other. All the calls shall be able to produce call alert and response
prompt signals. The signals can be visible, audible, etc.
b) The SMU shall be capable of 2-way speech with the VCU or the URU. If multiple SMU are
connected to the system, they shall be capable of 2-way speech with each other.
c) The SMU shall be able to control the VCU to perform electrical or electronic unlocking.
d) When a SMU is equipped with a video function it shall be able to display images captured by
the VCU. The URU shall be able to display images captured by SMU equipped with a video
camera.
e) For grade 2: After connecting the SMU with the VCU or the URU, the audio and video
information shall not be monitored by other URU connected to the system.
IEC 62820-1-1:2016 © IEC 2016 – 13 –
f) For grade 2: The SMU shall be able to address and communicate to selected VCU.
4.2 Additional functions
A building intercom system can also provide the following functions:
a) If the unsecured state of the controlled entrance lasts beyond the configured time, the SMU
may be able to receive a warning message.
NOTE Unsecured state: the door opened for too long, the tamper switch triggered, etc.
b) The system may have the possibility of transmitting images and texts to the URU.
c) The SMU may have a timed and dated event log with security graded access and recording
access events at the VCU.
1) URU’s called and if unlocking function operated by the URU.
2) VCU unlocking carried out directly at the VCU, identifying the authorized user.
3) Programming events such as adding or subtracting users and URU’s.
4) Identification of the operator accessing the event log.
d) SMU may intercept incoming calls from a VCU directed to an URU and then redirect the call
to desired URU.
e) If a SMU operator is not available, SMU may record details of URU which called the SMU in
order to allow the operator to call back the URU.
5 Performance requirements
5.1 Audio characteristics
5.1.1 Acoustic pressure level
Grade 1: Acoustic pressure level shall meet the following requirements:
a) Acoustic pressure level value generated by hands-free unit:
– For discrete measurement shall be ≥ 70 dBSPL.
– For continue measurement shall be ≥ 70 dB(A).
b) Acoustic pressure level value generated by handset unit:
– For discrete measurement shall be ≥ 77 dBSPL.
– For continue measurement shall be ≥ 77 dB(A).
Grade 2: No requirement.
5.1.2 Overall loudness rating (OLR)
Grade 1: No requirement.
Grade 2: The OLR shall meet the following requirements:
+10
a) At the VCU: dB.
−5
+10
b) At the hands-free URU and hands-free SMU: dB.
−5
c) At the handset unit: (15 ± 5) dB.
5.1.3 Overall sensitivity
Grade 1: No requirement.
– 14 – IEC 62820-1-1:2016 © IEC 2016
Grade 2: The typical curve and its tolerance range of overall sensitivity between 500 Hz and
3 400 Hz shall meet the following requirements:
a) At the hands-free unit: The typical curve is the dotted line shown in Figure 1 and its tolerance
range is the solid line shown in Figure 1.
b) At the handset unit: the typical curve is the dotted line shown in Figure 2 and its tolerance
range is the solid line shown in Figure 2.
NOTE Best fit or floating mask, refer to Figure 1 and Figure 2.
–4
–8
–12
–16
Frequency (Hz)
IEC
Figure 1 – Overall sensitivity at the hands-free unit
–4
–8
–12
–16
Frequency (Hz)
IEC
Figure 2 – Overall sensitivity at the handset unit
Relative sensitivity (dB) Relative sensitivity (dB)
100 100
125 125
160 160
200 200
250 250
500 500
630 630
800 800
1 000
1 000
1 250 1 250
1 600 1 600
2 000 2 000
20 dB
23 dB
2 500 2 500
3 150
3 150
3 400 3 400
4 000 4 000
5 000
5 000
6 300 6 300
IEC 62820-1-1:2016 © IEC 2016 – 15 –
5.1.4 Frequency response
Grade 1: Once the VCU, the URU and the SMU are connected for speech, the difference
between the higher and lower measurement of acoustic pressure level shall not be greater than
25 dB.
Grade 2: No requirement.
5.1.5 Acoustic distortion
Grade 1: No requirement.
Grade 2: The acoustic distortion shall meet the following requirements when the excitation
sound pressure is 0 dBPa:
a) At the hands-free unit: shall not be greater than 10 %.
b) At the handset unit: shall not be greater than 7 %.
5.1.6 Channel S/N ratio
Grade 1: No requirement.
Grade 2: The channel S/N ratio shall meet the following requirements when the excitation sound
pressure is 0 dBPa:
a) At the hands-free unit: shall not be less than 25 dB.
b) At the handset unit: shall not be less than 30 dB.
5.1.7 Sidetone masking rating (STMR)
Grade 1: No requirement.
Grade 2: The STMR of the handset unit shall not be less than 5 dB.
5.1.8 Idle channel noise
Grade 1: No requirement.
Grade 2: The idle channel noise shall meet the following requirements:
a) At the hands-free unit: shall not be greater than 45 dB(A
...
