SIST EN IEC 61967-8:2023
(Main)Integrated circuits - Measurement of electromagnetic emissions - Part 8: Measurement of radiated emissions - IC stripline method (IEC 61967-8:2023)
Integrated circuits - Measurement of electromagnetic emissions - Part 8: Measurement of radiated emissions - IC stripline method (IEC 61967-8:2023)
SIST EN IEC 61967-8:2023 is available as IEC 61967-8:2023 which contains the International Standard and its Redline version, showing all changes of the technical content compared to the previous edition.
IEC 61967-8:2023 defines a method for measuring the electromagnetic radiated emission from an integrated circuit (IC) using an IC stripline. The IC being evaluated is mounted on an EMC test board (PCB) between the active conductor and the ground plane of the IC stripline arrangement. This edition includes the following significant technical changes with respect to the previous edition:
a) frequency range of 150 kHz to 3 GHz was deleted from the scope;
b) extension of upper usable frequency to 6 GHz or higher as long as the defined requirements are fulfilled.
Integrierte Schaltungen - Messung von elektromagnetischen Aussendungen - Teil 8: Messung der abgestrahlten Aussendungen - IC-Streifenleiterverfahren (IEC 61967-8:2023)
Circuits intégrés - Mesure des émissions électromagnétiques - Partie 8: Mesure des émissions rayonnées - Méthode de la ligne TEM à plaques (stripline) pour CI (IEC 61967-8:2023)
IEC 61967-8:2023 est disponible sous forme de IEC 61967-8:2023 RLV qui contient la Norme internationale et sa version Redline, illustrant les modifications du contenu technique depuis l'édition précédente.
L’IEC 61967-8:2023 définit une méthode de mesure des émissions électromagnétiques rayonnées d’un circuit intégré (CI) à l’aide d’une ligne TEM à plaques (stripline) pour circuit intégré. Le CI à évaluer est monté sur une carte d’essai CEM (carte à circuit imprimé) entre le conducteur actif et le plan de masse du dispositif de la stripline pour CI. Cette édition inclut les modifications techniques majeures suivantes par rapport à l’édition précédente:
a) la plage de fréquences de 150 kHz à 3 GHz a été retirée du domaine d’application;
b) la fréquence utile supérieure est étendue à 6 GHz ou plus dans la mesure où les exigences définies sont remplies.
Integrirana vezja - Meritve elektromagnetnega sevanja - 8. del: Merjenje sevanega oddajanja - Metoda z IC na tračnem valovodu (IEC 61967-8:2023)
SIST EN IEC 61967-8:2023 je na voljo kot standard IEC 61967-8:2023, ki vsebuje mednarodni standard in njegovo različico z revizijami, ki prikazujejo vse spremembe tehnične vsebine v primerjavi s prejšnjo izdajo. Standard IEC 61967-8:2023 določa metodo za merjenje elektromagnetnega sevanega oddajanja iz integriranega vezja (IC) z uporabo tračnega valovoda. Integrirano vezje, ki se vrednoti, je nameščeno na plošči tiskanega vezja (PCB) za preskus elektromagnetne združljivosti (EMC) med aktivnim vodnikom in ozemljitveno ploščo v ureditvi tračnega valovoda. Ta izdaja v primerjavi s prejšnjo vključuje naslednje pomembne tehnične spremembe:
a) iz področja uporabe je bilo izbrisano frekvenčno območje med 150 kHz in 3 GHz;
b) razširitev zgornje uporabne frekvence na 6 GHz ali več, če so izpolnjene opredeljene zahteve.
