EN 10034:1993
(Main)Structural steel I and H sections - Tolerances on shape and dimensions
Structural steel I and H sections - Tolerances on shape and dimensions
This European standard specifies tolerances on shape dimensions and mass of structural steel I and H sections. These requirements do not apply to I and H sections rolled from stainless steel. These requirements do not apply to taper flange sections. Note: Until a European standard for dimensions of I and H beams is published, Euronorm 19 and Euronorm 53 or corresponding national standards may be used.
I- und H-Profile aus Baustahl - Grenzabmaße und Formtoleranzen
Diese europäische Norm gilt für die Grenzabmasse, Formtoleranzen und Grenzabweichungen der Masse von I-Profilen aus Stahl mit mittelbreiten (I) und breiten Flanschen (H). Die Anforderungen gelten nicht für I- und H-Profile aus nichtrostenden Stählen. Die Anforderungen gelten ferner nicht für I-Profile mit geneigten inneren Flanschflächen. Anmerkung: Bis zur Veröffentlichung einer europäischen Norm für die Nennmasse von I- und H-Profilen, können Euronorm 19 und Euronorm 53 oder entsprechende nationale Normen angewendet werden.
Poutrelles I et H en acier de construction - Tolérances de formes et de dimensions
La présente norme européenne spécifie les tolérances sur les dimensions et la masse des poutrelles I et H en acier de construction. Ces exigences ne sont pas applicables aux poutrelles I et H en acier inoxydable. Elle ne s'appliquent pas non plus aux poutrelles à ailes côniques. Note: en attendant la publication d'une norme européenne sur les dimensions des poutrelles I et H, les Euronorms 19 et 53 ou les normes nationales correspondantes peuvent être utilisées.
Profili I in H iz konstrukcijskih jekel - Mejni odstopki mer in tolerance oblik
General Information
- Status
- Published
- Publication Date
- 14-Sep-1993
- Withdrawal Date
- 30-Mar-1994
- Technical Committee
- ECISS/TC 103 - Structural steels other than reinforcements
- Drafting Committee
- ECISS/TC 11 - Structural steel sections
- Current Stage
- 9093 - Decision to confirm - Review Enquiry
- Start Date
- 02-Oct-2020
- Completion Date
- 23-Sep-2025
Overview
EN 10034:1993 is a European standard established by CEN that specifies the tolerances on shape, dimensions, and mass of structural steel I and H sections. These steel profiles are widely used in construction and engineering for their load-bearing properties. This standard ensures the uniformity and quality of these structural elements through clearly defined dimensional and shape tolerances. Notably, the standard excludes tapered flange sections and stainless steel I and H profiles.
Until a dedicated European standard for I and H beam dimensions is published, EN 10034:1993 recommends using Euronorm 19, Euronorm 53, or equivalent national standards for dimensions. This standard harmonizes tolerance requirements across manufacturers and users involved in steel construction.
Key Topics
- Scope of Standard: Defines tolerances related to the shape, dimensions, and mass of structural steel I and H sections made from carbon steel.
- Exclusions:
- Stainless steel I and H sections are not covered.
- Taper flange I and H profiles are excluded.
- Tolerance Specifications:
- Dimensional limits for web thickness, flange width, depth, and other critical dimensions.
- Shape tolerances to control warping, twisting, and bending irregularities.
- Mass tolerances control allowable deviations from nominal weight per meter.
- Interim Application:
- Use of Euronorm 19, Euronorm 53, or national standards for dimensions until a dedicated European dimensioning standard is published.
- Quality Assurance: Ensures consistency in steel profiles to facilitate interoperability and structural safety.
Applications
EN 10034:1993 applies to manufacturers, suppliers, structural engineers, and quality inspectors involved with steel construction components. Its practical benefits include:
- Structural Steel Fabrication: Ensures steel I and H sections meet stringent tolerance levels necessary for reliable load-bearing applications.
- Construction Engineering: Provides confidence in the uniformity of steel sections used in beams, columns, and frameworks.
- Quality Control: Serves as a reference for acceptance criteria during production and inspection phases.
- International Trade: Harmonizes tolerance requirements to facilitate cross-border steel product trade within Europe.
- Design Verification: Allows engineers to design with precise data on possible deviations in steel profiles.
By adhering to EN 10034:1993, stakeholders secure structural integrity, ease assembly, and reduce material waste.
Related Standards
- Euronorm 19 & Euronorm 53: Standards currently used for defining dimensions of I and H beams before a dedicated European dimension standard is released.
- EN 10025 Series: Covers hot-rolled structural steel products, often used in conjunction with EN 10034.
- EN 1090-1: Execution of steel structures - may reference EN 10034 tolerances for compliance.
- National Standards: Many countries have national standards aligned with EN 10034 to regulate steel profile tolerances.
Using EN 10034:1993 alongside complementary standards ensures comprehensive oversight of structural steel quality, contributing to safer and more efficient construction projects across Europe and beyond.
Keywords: EN 10034:1993, structural steel, I sections, H sections, steel profile tolerances, shape tolerances, dimensional tolerances, steel beam standards, CEN standards, European steel tolerances, construction steel profiles, steel fabrication standards, quality control steel profiles
