SIST EN 13658-1:2005

Metal lath and beads - Definitions, requirements and test methods - Part 1: Internal plastering

This European Standard specifies the requirements and test methods of metal lath and beads for internal plaster-ing.
This European Standard covers metal lath intended to be used for fixing to structures or solid backgrounds to pro-vide a key to hold the plaster in position. Metal lath is used vertically to support linings for walls, partitions and col-umns and horizontally to support linings for ceilings and beams. Used in this way it enables fire protecting plaster-ing systems to be provided.
This European Standard covers metal beads intended to be used to improve the protection of corners and also provide features to the internal finish of the construction as well as metal beads intended to be used as depth gauge beads and movement or expansion beads. They also contribute to fire protection.

Putzträger und Putzprofile aus Metall - Begriffe, Anforderungen und Prüfverfahren - Teil 1: Innenputze

Dieses Dokument legt die Anforderungen an Putzträger und Putzprofile aus Metall für Innenputze und die entsprechenden Prüfverfahren fest.
Dieses Dokument gilt für Putzträger aus Metall, die an Unterkonstruktionen oder festen Untergründen befestigt werden, um einen Putzgrund zu schaffen, der die Haftung des Putzes sicherstellt. Putzträger aus Metall werden vertikal als Putzuntergrund für Wände, Trennwände und Stützen und horizontal als Putzuntergrund für Decken und Balken verwendet. Auf diese Art verwendet, ermöglichen sie die Herstellung von Brandschutz-Putzsystemen.
Dieses Dokument gilt auch für Putzprofile aus Metall, die zur Verbesserung des Eckenschutzes und als dekorative Putzanschlüsse und Putzabschlüsse verwendet werden, sowie für Putzprofile, die als Schnellputzleisten und Bewegungs- oder Dehnungsfugenprofile verwendet werden. Putzprofile aus Metall tragen auch zum Brandschutz bei.

Lattis et cornieres métalliques - Définitions, exigences et méthodes d'essai - Partie 1: Enduits intérieurs

La présente norme européenne définit les exigences et les méthodes d�essai applicables aux lattis et aux cornières
métalliques destinés à l�application d�enduits intérieurs.
La présente norme s�appliquent aux lattis métalliques destinés à permettre la fixation à des structures ou à des
supports solides, afin de fournir un support d�accrochage de l�enduit. Le lattis s�emploie verticalement comme
support d�enduit des revêtements de murs, de cloisons et de colonnes, et horizontalement comme support d�enduit
des revêtements de plafonds et de poutres. Le lattis permet, dans ce type d�utilisation, la mise en place de
systèmes d�enduits de protection contre l�incendie.
La présente Norme européenne concerne les cornières métalliques destinées à être utilisées pour améliorer la
protection des angles et obtenir les caractéristiques des finitions intérieures de la construction ainsi que les
cornières métalliques destinées à être utilisées en tant qu�indicateurs d�épaisseur, cornières de mouvement ou
d�expansion. Les cornières contribuent également à la protection contre l�incendie.

Kovinski profili - Definicije, zahteve in preskusne metode – 1. del: Notranji omet

General Information

• Status: Published
• Publication Date: 30-Jun-2005
• ICS: 77.140.65 - Steel wire, wire ropes and link chains
• ICS: 91.100.10 - Cement. Gypsum. Lime. Mortar
• Technical Committee: CAA - Mineral binders and masonry
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Jul-2005
• Due Date: 01-Jul-2005
• Completion Date: 01-Jul-2005
• Directive: 305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
• Directive: 89/106/EEC - Construction products
• Mandate: M/106 - Mandate to CEN/CENELEC concerning the execution of standardization work for harmonized standards on gypsum products
• Ref Project: EN 13658-1:2005 - Metal lath and beads - Definitions, requirements and test methods - Part 1: Internal plastering

Relations

• Revises: oSIST prEN 13658-1:2017 - Metal lath and beads - Definitions, requirements and test methods - Part 1: Internal plastering
• Effective Date: 18-Jan-2023
• Revised: oSIST prEN 13658-1:2017 - Metal lath and beads - Definitions, requirements and test methods - Part 1: Internal plastering
• Effective Date: 01-Oct-2017

Overview

EN 13658-1:2005 - "Metal lath and beads - Definitions, requirements and test methods - Part 1: Internal plastering" is a CEN European Standard that specifies definitions, material and dimensional requirements, test methods and conformity procedures for metal lath and metal beads intended for internal plastering. The standard covers products used to provide a mechanical key for plaster, to support linings for walls, partitions, columns, ceilings and beams, and to improve corner protection, finishing details, depth control and movement joints. It also addresses aspects of fire protection and CE marking under the EU Construction Products framework.

Key topics and requirements

• Scope & product types: Defines types of metal lath (expanded flat, corrugated, ribbed, paperbacked wire lath, claylath, stainless options) and metal beads (angle, stop, featured, movement and corner movement beads).
• Materials & coatings: Requirements for corrosion‑resistant materials (steel, aluminium, stainless steel, zinc alloys) and coating thickness measurements.
• Dimensions & profiles: Specified dimensional checks including thickness/diameter, length, width, straightness and profile dimensions for beads and lath.
• Fire behaviour: Classification and requirements for reaction to fire and for use in fire‑protecting plastering systems (references to relevant fire test standards).
• Testing & sampling: Test methods for dimensional verification, coating thickness, straightness and other product characteristics.
• Conformity & factory controls: Procedures for type testing, Factory Production Control (FPC), traceability, marking and handling of non‑conforming products.
• Marking & CE: Requirements for marking, labelling and packaging; informative Annex ZA links the standard to EU Construction Products Directive procedures and CE marking.

Applications

• Provide a mechanical key and structural support for internal plaster layers on walls, partitions, ceilings, beams and columns.
• Protect and reinforce internal corners, edges and finishes with metal beads.
• Create depth gauges and controlled movement/expansion joints (movement beads allow ±1.5 mm movement at the plaster surface).
• Enable reliable specification and verification where fire‑protecting plastering systems are required.

Who uses this standard

• Manufacturers of metal lath and plaster beads (product design, FPC, labelling and CE compliance)
• Architects & specifiers (product selection for internal plastering, fire protection and finish requirements)
• Contractors & plastering installers (installation guidance, compatibility with plaster systems)
• Test laboratories & certification bodies (type testing, conformity assessment)
• Regulators & building control authorities (verification of CE marking and performance claims)

Related standards

• EN 13658-2 (External rendering)
• EN 13501-1 / EN 13501-2 (Fire classification)
• EN 1364 / EN 1365 series (Fire resistance test methods)
• EN 13914-2 (Design and application for internal plastering)
• Material standards referenced for steels, aluminium and coatings (e.g., EN 10088, EN 10169)

Keywords: EN 13658-1:2005, metal lath, metal beads, internal plastering, test methods, requirements, fire protection, CE marking, factory production control.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Metal lath and beads - Definitions, requirements and test methods - Part 1: Internal plasteringKovinski profili - Definicije, zahteve in preskusne metode – 1. del: Notranji ometLattis et cornieres métalliques - Définitions, exigences et méthodes d'essai - Partie 1: Enduits intérieursPutzträger und Putzprofile aus Metall - Begriffe, Anforderungen und Prüfverfahren - Teil 1: InnenputzeTa slovenski standard je istoveten z:EN 13658-1:2005SIST EN 13658-1:2005en91.100.1077.140.65ICS:SLOVENSKI
STANDARDSIST EN 13658-1:200501-julij-2005

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 13658-1May 2005ICS 77.140.65; 91.100.10English versionMetal lath and beads - Definitions, requirements and testmethods - Part 1: Internal plasteringLattis et cornières métalliques - Définitions, prescriptions etméthodes d'essai - Partie 1 : Enduits intérieursPutzträger und Putzprofile aus Metall - Begriffe,Anforderungen und Prüfverfahren - Teil 1: InnenputzeThis European Standard was approved by CEN on 24 March 2005.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia,Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2005 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 13658-1:2005: E

Clauses of this European Standard addressing the provisions of the EU Construction Products Directive.31 ZA.1 Scope and relevant characteristics.31 ZA.2 Procedure(s) for the attestation of conformity of metal lath and beads.32 ZA.3 CE marking and labelling.33

Raw gypsum
A1 – Gypsum binders for direct use or further processing
A2 – Direct use on site
A3 – Further processing
Gypsum plasters: B1 – Gypsum building plaster B2 – Gypsum based building plaster B3 – Gypsum-lime building plaster B4 – Lightweight gypsum building plasterB5 – Lightweight gypsum based building plaster B6 – Lightweight gypsum-lime building plaster
B7 – Gypsum plaster with enhanced surface hardness
Gypsum plasters for special purposes: C1 – Gypsum plaster for
fibrous plasterworksC2 – Gypsum bricklaying
plaster C3 – Acoustic plaster C4 – Thermal insulating plaster C5 – Fire protection plaster C6 – Thin coat plaster
Manufactured elements, e. g.:  gypsum blocks  fibrous plaster casts  ceiling tiles  plasterboards  gypsum boards with fibrous rein-forcement  metal lath and beads
Diagram 1  Family of gypsum products

corrosion resistant diamond shaped mesh to provide a key for plastering (see Figure 3a) 3.1.2 expanded corrugated metal lath
corrosion resistant diamond mesh to provide extra stiffness (see Figure 3b) 3.1.3 expanded ribbed lath
corrosion resistant mesh formed by expanding with integral solid ribs of at least 7 mm height to provide extra stiff-ness (see Figure 4) 3.1.4 expanded mini ribbed lath corrosion resistant mesh formed by expanding with integral solid ribs between 4 mm and 7 mm height (see Figure 4) 3.1.5 stainless steel ribbed lath stainless steel mesh with integral solid ribs of at least 7 mm height 3.1.6 paperbacked ribbed lath corrosion protected paperbacked mesh with integral ribs of at least 7 mm height 3.1.7 standard paperbacked wire lath corrosion resistant wire spot welded to form a square mesh to provide a key for plastering; between the horizontal and vertical wires a sheet of cardboard is positioned (see Figure 5) 3.1.8 reinforced paperbacked wire lath same as 3.1.7, but the reinforcing wires are thicker and less widely spaced in order to increase stiffness 3.1.9 high ribbed paperbacked wire lath same as 3.1.8, but with thicker wires to provide still greater stiffness

3.2.4 movement bead corrosion resistant profiled section connected with a flexible plastic extrusion capable of a movement within the range of ± 1,5 mm of the internal plaster surface NOTE this section can also be fabricated from wire 3.2.5 corner movement bead corrosion resistant profiled section as 3.2.4, with a flexible plastic extrusion used for 90° inner corners (maximum movement ± 1,5 mm) 3.2.6 expansion bead corrosion resistant profiled section with a flexible extrusion capable of movement greater than ± 1,5 mm, i.e. to al-low for background movement which provides vertical and horizontal flexibility 3.2.7 corner expansion bead corrosion resistant profiled section as 3.2.6 to allow for background movement in 90° inner corners 3.2.8 depth gauge bead profiled section which can be set on plane surfaces to control the depth of plaster applied

See Table 1 for geometric profiles 4 Requirements 4.1 Fire behaviour 4.1.1 Reaction to fire When the intended use of metal lath and beads is for situations in building construction works where there is a risk of exposure to fire, metal lath and beads shall be classified A1 without the need of testing1 unless they have or-ganic coatings or flexible middle parts. In this case they shall be tested and classified in accordance with EN 13501-1. 4.1.2 Fire resistance Metal lath and beads can be used in walls, partitions and ceilings and encasement systems providing fire ratings. When required, the fire rating of the system shall be tested to EN 1364-1, EN 1364-2, EN 1365-1, EN 1365-3 and EN 1365-4 as appropriate and classified to EN 13501-2. 4.2 Requirements for lath 4.2.1 Material Lath shall be manufactured from the materials and finishes shown in Table 2. The corrosion resistant selected ma-terial and finish shall provide a satisfactory level of protection against corrosion under conditions of intended use, i.e. regional requirements. 4.2.2 Description a) Expanded lath, ribbed lath and wire lath shall be formed to provide the functional requirements of stiffness to span between supports or fixings and have aperture sizes to provide an efficient keying matrix for the plaster. Typical products meeting these requirements are given in Tables 3 and 4 and in Figures 3, 4 and 5 ; b) normal and stainless steel claylath are produced in open, half open and closed versions (see Figure 7). At least 60 % of the surface area shall be covered with clay.
1 According to Commission Decision 96/603/EC as amended.

NOTE The dimensions are for "clear aperture" not centre to centre of strands. 4.2.3.4 Standard paperbacked wire lath The wires shall have a minimum nominal equivalent diameter of 1,4 mm (see Figure 5 and Table 4). 4.2.3.5 Reinforced paperbacked wire lath Same as 4.2.3.4, but the reinforcing wires shall have a minimum nominal equivalent wire diameter of 3,0 mm spaced at distances not greater than 150 mm. The moment of inertia in the direction where increased stiffness is required shall be at least 10 mm4. 4.2.3.6 High ribbed paperbacked wire lath Same as 4.2.3.4 but the reinforcing wires shall have a minimum nominal equivalent wire diameter of 3,9 mm spaced at distances not greater than 150 mm. The moment of inertia in the direction where increased stiffness is required shall be at least 30 mm4. 4.2.3.7 Normal and stainless steel claylath For requirements, see Table 5 and Figure 7. The figure shows the open type. In half open and closed claylath the apertures between the crosses may be closed with fired clay.

(1)  for stop and featured beads 600L
(2)
...
