SIST EN 10244-1:2009

Steel wire and wire products - Non-ferrous metallic coatings on steel wire - Part 1: General principles

This part of this European Standard specifies the requirements for the mass, other properties and testing of non-ferrous metal coatings on steel wire and steel wire products of circular or other cross-section.
This European Standard deals with requirements of general application and is of use for those coatings for which no particular requirements have been laid down in the following parts (2 to 6). Deviations are possible, particularly if required for well-defined products. In such cases, appropriate requirements shall be part of the relevant product standard.

Stahldraht und Drahterzeugnisse - Überzüge aus Nichteisenmetall auf Stahldraht - Teil 1: Allgemeine Regeln

Dieser Teil dieser Europäischen Norm legt Anforderungen an Masse, andere Eigenschaften und Prüfung von
Überzügen aus Nichteisenmetall auf Stahldraht und Stahldrahterzeugnissen mit rundem oder anderem
Querschnitt fest.
Die vorliegende Europäische Norm behandelt Anforderungen für die allgemeine Anwendung und gilt für
diejenigen Überzüge, für die keine besonderen Anforderungen in EN 10244-2 bis EN 10244-6 festgelegt sind.
Abweichungen sind möglich, insbesondere wenn sie für bestimmte Produkte verlangt werden. In diesen
Fällen sollten die entsprechenden Anforderungen Bestandteil der jeweiligen Produktnorm sein.

Fils et produits tréfilés en acier - Revêtements métalliques non ferreux sur fils d'acier - Partie 1: Principes généraux

Cette partie de la présente Norme européenne spécifie les exigences en matière de masse, autres
caractéristiques et essais de revêtements métalliques non ferreux sur fils et produits tréfilés en acier de
section circulaire ou autre.
La présente Norme européenne traite des exigences d'application générale et concerne les revêtements pour
lesquels aucune exigence particulière n'a été établie dans les autres parties (2 à 6). Des dérogations sont
possibles, en particulier si elles sont nécessaires pour obtenir des produits spécifiques. Dans ce cas, des
exigences appropriées doivent être données dans la norme de produit correspondante.

Jeklena žica in žični izdelki - Neželezne kovinske prevleke na jekleni žici - 1. del: Splošna načela

General Information

• Status: Published
• Publication Date: 06-May-2009
• ICS: 25.220.40 - Metallic coatings
• ICS: 77.140.65 - Steel wire, wire ropes and link chains
• Technical Committee: IFEK - Ferrous metals
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 15-Apr-2009
• Due Date: 20-Jun-2009
• Completion Date: 07-May-2009
• Ref Project: EN 10244-1:2009 - Steel wire and wire products - Non-ferrous metallic coatings on steel wire - Part 1: General principles

Relations

• Replaces: SIST EN 10244-1:2002 - Steel wire and wire products - Non-ferrous metallic coatings on steel wire - Part 1: General principles
• Effective Date: 01-Jun-2009
• Corrected By: SIST EN 10244-1:2009/AC:2011 - Steel wire and wire products - Non-ferrous metallic coatings on steel wire - Part 1: General principles
• Effective Date: 04-Jun-2011

Overview - EN 10244-1:2009 (CEN)

EN 10244-1:2009 defines the general principles for non‑ferrous metallic coatings on steel wire and wire products (circular or other cross‑section). Published by CEN, this part specifies how to state coating type/grade, measure coating mass, assess appearance and adherence, and perform routine tests. It applies where no specific requirements are given in Parts 2–6 and is used together with product‑specific standards when deviations are needed.

Key topics and technical requirements

• Scope and declaration: The coating metal/alloy type, quality and grade must be declared at enquiry and order.
• Coating mass: Preferably expressed as mass per unit bare wire surface (g/m2). Thickness (µm) may be used and can be converted to mass using the coating density (EN 10244-1 includes conversion factors, e.g., Al ≈ 2.69 g/m2 per µm, Cu ≈ 8.96 g/m2 per µm).
• Appearance: Coating shall be reasonably smooth and as evenly distributed as industrially practicable; no unacceptable bare patches or dross contamination.
• Special finishes: Additional requirements (wax, lubrication, special inspection) must be agreed at enquiry/order.
• Adherence: Assessed by a wrapping test (wire ≤ 7.5 mm) or by a bending test (wire > 7.5 mm). Wrapping: at least six tight turns around a mandrel; mandrel diameter relationship: <4 mm wire → 4× wire diameter; ≥4 mm wire → 5× wire diameter. Coating must not crack or allow slivers to be removed by simple rubbing.
• Test methods and sampling:
  • Gravimetric method is the reference for coating mass: dissolve coating chemically, weigh before/after, calculate g/m2.
  • Other validated methods may be used for convenience, but gravimetric is the reference in disputes.
  • Sampling, sample length and avoidance of damaged areas are defined; retesting follows EN 10021 procedures.

Applications and practical value

EN 10244-1:2009 is a foundational standard for specifying and verifying non‑ferrous coatings on steel wire. It is used to:

• Ensure consistent corrosion protection, solderability or electrical/thermal properties provided by non‑ferrous coatings.
• Provide objective acceptance criteria between manufacturers and purchasers.
• Define laboratory test procedures for quality control and contract verification.

Who uses this standard

• Steel wire and wire‑product manufacturers and coaters
• Quality and testing laboratories
• Purchasers, specifiers and procurement engineers for wire products
• Product standards writers who build on Part 1 with specific coating requirements

Related standards

• EN 10244-2 to EN 10244-6 (specific coatings: zinc, aluminium, tin, nickel, copper/bronze/brass)
• EN 10218-1 (steel wire test methods)
• EN 10021 (general technical delivery conditions for steel products)
• CEN/CENELEC internal regulations (adoption and national implementation)

Keywords: EN 10244-1:2009, non‑ferrous metallic coatings, steel wire, coating mass (g/m2), gravimetric method, adherence test, CEN.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Stahldraht und Drahterzeugnisse - Überzüge aus Nichteisenmetall auf Stahldraht - Teil 1: Allgemeine RegelnFils et produits tréfilés en acier - Revêtements métalliques non ferreux sur fils d'acier - Partie 1: Principes générauxSteel wire and wire products - Non-ferrous metallic coatings on steel wire - Part 1: General principles77.140.65Jeklene žice, jeklene vrvi in verigeSteel wire, wire ropes and link chains25.220.40Kovinske prevlekeMetallic coatingsICS:Ta slovenski standard je istoveten z:EN 10244-1:2009SIST EN 10244-1:2009en,de01-junij-2009SIST EN 10244-1:2009SLOVENSKI
STANDARDSIST EN 10244-1:20021DGRPHãþD

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 10244-1April 2009ICS 25.220.40; 77.140.65Supersedes EN 10244-1:2001
English VersionSteel wire and wire products - Non-ferrous metallic coatings onsteel wire - Part 1: General principlesFils et produits tréfilés en acier - Revêtements métalliquesnon ferreux sur fils d'acier - Partie 1 : Principes générauxStahldraht und Drahterzeugnisse - Überzüge ausNichteisenmetall auf Stahldraht - Teil 1: Allgemeine RegelnThis European Standard was approved by CEN on 13 December 2008.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre:
Avenue Marnix 17,
B-1000 Brussels© 2009 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 10244-1:2009: ESIST EN 10244-1:2009

 Part 3: Aluminium coatings
 Part 4: Tin coatings
 Part 5: Nickel coatings  Part 6: Copper, bronze or brass coatings According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and the United Kingdom.
...
