SIST EN 9300-110:2018
(Main)Aerospace series - LOTAR -LOng Term Archiving and Retrieval of digital technical product documentation such as 3D, CAD and PDM data - Part 110: CAD mechanical 3D Explicit geometry information
Aerospace series - LOTAR -LOng Term Archiving and Retrieval of digital technical product documentation such as 3D, CAD and PDM data - Part 110: CAD mechanical 3D Explicit geometry information
This document defines the requirements on a digital archive to preserve for the long term the 3D
explicit geometry of single CAD parts. The goal is to preserve the 3D information without loss with
respect to the geometry produced by the original CAD system, following the principles laid down in
EN 9300-003 “Fundamentals and Concepts”, including the use of an open data format.
1.2 In scope
The following is in scope of this part of EN 9300:
— business specification for long term archiving and retrieval of CAD 3D explicit geometry
(see Clause 5);
— essential information of CAD 3D explicit geometry (solids, curves, surfaces, and points) to be
preserved (see Clause 6);
— data structures detailing the main fundamentals and concepts of CAD 3D explicit geometry
(see Clause 7);
— verification rules to check CAD 3D explicit geometry for consistency and data quality (see Clause 8);
— validation rules to be stored with the CAD 3D explicit geometry in the archive to check essential
characteristics after retrieval (see Clause 9).
NOTE This includes the geometrical external shape resulting from CAD disciplines 3D entities (e.g., 3D
Structural components, 3D Tubing, 3D electrical harness, 3D composite, etc.).
Luft- und Raumfahrt - LOTAR - Langzeitarchivierung und Bereitstellung digitaler technischer Produktdokumentationen beispielsweise 3D CAD und PDM Daten - Teil 110: Explizite Geometrie
1.1 Einleitung
Dieses Dokument legt die Anforderungen an ein digitales Archiv fest, um langfristig die explizite 3D Geome¬trie einzelner CAD-Teile aufzubewahren. Das Ziel besteht in der verlustfreien Aufbewahrung der 3D Infor¬mationen über die vom ursprünglichen CAD-System erstellte Geometrie nach den in EN 9300 003 "Grund¬lagen und Konzepte" festgelegten Grundsätzen, einschließlich der Verwendung eines offenen Datenformats.
1.2 Im Anwendungsbereich
Folgendes liegt im Anwendungsbereich dieser Norm der Reihe EN 9300:
- betriebliche Spezifikation zur Langzeit-Archivierung und -Bereitstellung von expliziten 3D CAD-Geome¬trien (siehe Abschnitt 5);
- essentielle Informationen expliziter 3D-CAD-Geometrien (Festkörper, Kurven, Flächen und Punkte), die aufzubewahren sind (siehe Abschnitt 6);
- Datenstrukturen, die detailliert die wichtigsten Grundlagen und Konzepte expliziter 3D-CAD-Geome-trien angeben (siehe Abschnitt 7);
- Verifizierungsregeln zur Überprüfung der expliziten 3D-CAD-Geometrie auf Einheitlichkeit und Daten¬qualität (siehe Abschnitt 8);
- Validierungsregeln, die mit der expliziten 3D-CAD-Geometrie im Archiv zu speichern sind, um die wesentlichen Merkmale nach der Bereitstellung zu überprüfen (siehe Abschnitt 9).
ANMERKUNG Dazu gehört die geometrische Außenform, die sich aus 3D-Entitäten der CAD-Disziplinen ergibt (z. B. 3D-Statikbauteile, 3D-Rohrleitungen, 3D-Leitungsbündel, 3D-Verbundwerkstoffe usw.).
1.3 Außerhalb des Anwendungsbereichs
Folgendes liegt außerhalb des Anwendungsbereichs dieser Norm der Reihe EN 9300:
- die formale Definition von Validierungs- und Verifizierungsregeln zur Überprüfung der expliziten 3D Geometrie im Hinblick auf Einheitlichkeit und Datenqualität unter Verwendung einer maschinen-lesbaren Syntax;
- implizite oder parametrische Geometrie;
- Geometrische Dimensionierung und Tolerierung (en: Geometric Dimensioning & Tolerancing, GD&T), Produkt- & Ferti¬gungsinformationen (en: Product & Manufacturing Information, PMI);
- Baugruppenstrukturen;
- Darstellung der expliziten Geometrie.
Série aérospatiale - LOTAR - Archivage long terme et récupération des données techniques produits numériques telles que CAD 3D et PDM - Partie 110 : Archivage long terme et récupération des informations CAO
1.1 Introduction
Le présent document définit les exigences s'appliquant sur une archive numérique pour la conservation à long terme de la géométrie 3D explicite de pièces uniques en CAO. L'objectif étant de conserver les informations 3D sans perte par rapport à la modélisation créée par le système de CAO d'origine, en suivant les principes énoncés dans l'EN 9300-003 « Fondamentaux et concepts », y compris l'utilisation d'un format de données ouvert.
1.2 Champ d'application
L'EN 9300 traite des points suivants :
- les spécifications commerciales pour l'archivage long terme et la récupération de la géométrie 3D explicite en CAO (voir l’Article 5) ;
- les informations essentielles de la géométrie 3D explicite en CAO (solides, courbes, surfaces et points) à conserver (voir l’Article 6) ;
- les structures de données détaillant les fondamentaux et concepts principaux de la géométrie 3D explicite en CAO (voir l’Article 7) ;
- les règles de vérification de la géométrie 3D explicite en CAO, pour contrôle de cohérence et de qualité des données (voir l’Article 8);
- les règles de validation à stocker avec la géométrie 3D explicite en CAO dans l'archive, afin de vérifier les caractéristiques essentielles après récupération (voir l’Article 9).
NOTE Cela inclut la forme géométrique externe résultant des entités 3D des disciplines de CAO (par exemple, composants structurels 3D, tubage 3D, faisceau électrique 3D, composite 3D, etc.).
1.3 Hors champ d’application
L'EN 9300 ne traite pas des points suivants :
- la définition formelle des règles de validation et de vérification, afin de vérifier la cohérence et la qualité des données de la géométrie 3D explicite à l'aide d'une syntaxe lisible par machine ;
- la géométrie implicite ou paramétrique ;
- le Dimensionnement et Tolérancement Géométrique (GD & T), les Données de fabrication des produits (PMI) ;
- les structures d'assemblage ;
- la présentation de la géométrie explicite.
Aeronavtika - LOTAR - Dolgotrajno arhiviranje in iskanje digitalne tehnične dokumentacije o izdelkih, kot so podatki o 3D, CAD in PDM - 110. del: CAD mehanske 3D eksplicitne informacije o geometriji
Ta dokument določa zahteve digitalnega arhiva za dolgotrajno shranjevanje 3D eksplicitne geometrije posameznih delov CAD. Cilj je ohraniti 3D informacije brez izgub podatkov glede na geometrijo, ki jo proizvede prvotni sistem CAD, v skladu z načeli, določenimi v standardu EN 9300-003 »Osnove in pojmi«, vključno z uporabo odprte oblike zapisa podatkov.
Na področje uporabe tega dela standarda EN 9300 sodi naslednje:
– poslovna specifikacija za dolgotrajno arhiviranje in iskanje CAD 3D eksplicitne geometrije (glejte točko 5);
– osnovne informacije CAD 3D eksplicitne geometrije (liki, krivulje, površine in točke) za arhiviranje (glejte točko 6);
– podatkovne strukture za podroben opis glavnih osnov in pojmov CAD 3D eksplicitne geometrije (glej točko 7);
– preverjanje pravil za preverjanje CAD 3D eksplicitne geometrije glede doslednosti in kakovosti podatkov (glejte točko 8);
– pravila ocenjevanja, ki bodo shranjena v arhivu skupaj s CAD 3D eksplicitno geometrijo za preverjanje osnovnih značilnosti po iskanju (glejte točko 9).
OPOMBA To vključuje geometrijsko zunanjo obliko, ki je posledica 3D entitet na področjih CAD (npr. 3D strukturne komponente, 3D ocevje, 3D električna napeljava, 3D kompozit itd.).
