Electrical accessories - Cable reels for household and similar purposes

This International Standard applies to cable reels for a.c. only, provided with a
non-detachable flexible cable with a rated voltage above 50 V and not exceeding 250 V for
single-phase cable reels and above 50 V and not exceeding 440 V for all other cable
reels, and a rated current not exceeding 16 A. They are intended for household,
commercial and light industrial and similar purposes, either indoors or outdoors, with
particular reference to safety in normal use.
Cable reeling devices incorporated in appliances are under consideration.
Cable reels complying with this standard are suitable for use at ambient temperatures not
normally exceeding 25 °C, but occasionally reaching 35 °C. In locations where special
conditions prevail, special construction may be required.
NOTE - This standard does not apply to cable reels with a detachable flexible cable.

Elektrisches Installationsmaterial - Leitungsroller für den Hausgebrauch und ähnliche Zwecke

Petit appareillage électrique - Cordons prolongateurs enroulés sur tambour pour usages domestiques

S'applique aux cordons prolongateurs enroulés sur tambour (enrouleurs dans la suite du texte) pour courant alternatif seulement, munis d'un câble souple non détachable, de tension assignée supérieure à 50 V et ne dépassant pas 250 V pour les enrouleurs monophasés, et supérieure à 50 V et ne dépassant pas 440 V pour tous les autres enrouleurs de courant assigné ne dépassant pas 16 A.

Electrical accesories - Cable reels for household and similar purposes (IEC 1242:1995, modified)

Ta mednarodni standard velja za kabelske kolute samo za izmenični tok, opremljene z neločljivim gibljivim kablom z nazivno napetostjo nad 50 V in ne večjo od 250 V za enofazne kabelske kolute in nad 50 V in ne več kot 440 V za vse druge kabelske kolute ter naznačenim tokom, ki ne presega 16 A. Namenjene so za gospodinjske, komercialne in lahke industrijske ter podobne namene bodisi v zaprtih prostorih bodisi na prostem s posebnim poudarkom na varnosti pri običajni uporabi.
V obravnavi so naprave za navijanje kablov, ki so vgrajene v aparate. Kabelski koluti, ki so skladni s tem standardom, so primerni za uporabo pri temperaturah okolice, ki običajno ne presegajo 25 °C, vendar občasno dosežejo 35 °C. Na območjih, kjer prevladujejo posebne razmere, je lahko zahtevana posebna konstrukcija.
OPOMBA - Ta standard ne velja za kabelske kolute s snemljivim gibljivim kablom.
