EN ISO 5173:2023

Destructive tests on welds in metallic materials - Bend tests (ISO 5173:2023)

This document specifies a method for making transverse root, face and side bend tests on test specimens taken from butt welds, butt welds with cladding (subdivided into welds in clad plates and clad welds) and cladding without butt welds, in order to reveal imperfections on or near the surface of the test specimen which is under tension during bend testing and/or assess ductility. It also gives the dimensions of the test specimen.
In addition, this document specifies methods to be used instead of transverse bend tests with a former for welded joints when base materials, heat affected zones and/or weld metal have a significant difference in their physical and mechanical properties in relation to bending.
This document applies to metallic materials in all forms of product with welded joints made by any welding process.

Zerstörende Prüfungen von Schweißnähten an metallischen Werkstoffen - Biegeprüfungen (ISO 5173:2023)

Dieses Dokument legt ein Verfahren zur Durchführung von wurzelseitigen, decklagenseitigen Quer- und Seitenbiegeprüfungen an Probestücken aus Stumpfnähten, Stumpfnähten mit Plattierung (unterteilt in Schweißungen in Plattierungsblechen und in Plattierungsschweißnähten) und Plattierung ohne Stumpfnähte fest, um Unregelmäßigkeiten an oder nahe der Oberfläche des Probestücks, das während der Biegeprüfung unter Zug steht, aufzuzeigen und/oder die Verformbarkeit zu beurteilen. Es gibt ebenso die Maße des Probestücks an.
Darüber hinaus legt dieses Dokument Verfahren fest, die anstelle von Querbiegeprüfungen mit einem Biegedorn für Schweißverbindungen anzuwenden sind, wenn Grundwerkstoffe, Wärmeeinflusszonen und/oder Schweißgut einen signifikanten Unterschied in ihren physikalischen und mechanischen Eigenschaften hinsichtlich der Biegung aufweisen.
Dieses Dokument ist anwendbar für Metallwerkstoffe jeglicher Produktform mit Schweißverbindungen, die mit jeder Art von Schweißverfahren erzeugt werden.

Essais destructifs des soudures sur matériaux métalliques - Essais de pliage (ISO 5173:2023)

Le présent document spécifie une méthode d’essai de pliage transversal envers, endroit et de côté sur des éprouvettes prélevées dans des soudures bout à bout, des soudures bout à bout avec revêtement (subdivisées en soudures de tôles revêtues et soudures de revêtement) et revêtement sans soudure bout à bout, afin de révéler des défauts sur la surface ou près de la surface de l’éprouvette, mise en extension pendant l’essai de pliage et/ou d’évaluer la ductilité. Elle spécifie également les dimensions de l’éprouvette.
De plus, le présent document spécifie des méthodes à utiliser au lieu des pliages transversaux avec un poinçon pour les assemblages soudés dont les métaux de base, les zones affectées thermiquement et/ou le métal fondu ont des différences notables de propriétés physiques et mécaniques concernant le pliage.
Le présent document est applicable à des assemblages soudés sur matériaux métalliques sous toute forme de livraison quel que soit le procédé de soudage utilisé.

Porušitveno preskušanje zvarnih spojev na kovinskih materialih - Upogibni preskusi (ISO 5173:2023)

Ta dokument določa metodo za izvedbo vzdolžnega upogibnega preskusa prek kolena, vzdolžnega upogibnega preskusa prek temena in vzdolžnega stranskega upogibnega preskusa na preskusnih vzorcih iz soležnih zvarov, soležnih zvarov z oplatenjem (ki jih delimo na zvare z oplatenimi ploščami in oplatene zvare) in oplatenje brez soležnih zvarov za odkrivanje nepravilnosti na površini ali v bližini površine preskusnega vzorca, ki je pod napetostjo pri preskušanju upogiba, in/ali ocenjevanje duktilnosti. Prav tako podaja mere preskusnega vzorca.
Poleg tega ta dokument določa metode, ki se jih uporablja namesto vzdolžnih upogibnih preskusov, za zvarjene spoje, ko se osnovni materiali, območja, na katera vpliva toplota, in/ali zvarna kovina bistveno razlikujejo glede svojih fizikalnih in mehanskih lastnosti v zvezi z upogibanjem.
Ta dokument se uporablja za kovinske materiale v vseh oblikah izdelkov, ki vsebujejo kakršen koli zvarjeni spoj izveden s katerim koli postopkom varjenja.

General Information

• Status: Published
• Publication Date: 24-Jan-2023
• ICS: 25.160.40 - Welded joints and welds
• Technical Committee: CEN/TC 121 - Welding
• Drafting Committee: CEN/TC 121/WG 21 - Testing of welds
• Current Stage: 6060 - Definitive text made available (DAV) - Publishing
• Start Date: 25-Jan-2023
• Completion Date: 25-Jan-2023
• Ref Project: SIST EN ISO 5173:2023 - Destructive tests on welds in metallic materials - Bend tests (ISO 5173:2023)

Relations

• Replaces: EN ISO 5173:2010/A1:2011 - Destructive tests on welds in metallic materials - Bend tests - Amendment 1 (ISO 5173:2009/Amd 1:2011)
• Effective Date: 18-Jan-2023
• Replaces: EN ISO 5173:2010 - Destructive tests on welds in metallic materials - Bend tests (ISO 5173:2009)
• Effective Date: 23-Dec-2020

Overview

EN ISO 5173:2023 - Destructive tests on welds in metallic materials: Bend tests defines standardized procedures for performing bend tests on welded metallic assemblies. Published by CEN/ISO, this fourth edition replaces earlier versions and covers transverse (root, face, side) and longitudinal bend tests for butt welds, welded cladding and cladding without butt welds. The standard specifies specimen preparation, test methods, dimensions and reporting to reveal surface or near-surface imperfections and to assess ductility.

Key topics and technical requirements

• Scope and applicability: Applies to metallic materials in any product form and to welded joints made by any welding process (butt welds, clad welds and cladding).
• Types of bend tests: Transverse face (TFBB), transverse root (TRBB), transverse side (TSBB) and longitudinal face/root bend tests, plus cladding-specific face and side tests.
• Specimen preparation: Guidance on location, marking, heat treatment/ageing, extraction, surface preparation and etching prior to testing.
• Specimen dimensions: Standardized dimensions and edge radii for each specimen type are provided to ensure repeatable results.
• Test methods: Includes testing with a former (guided bend), testing with rollers (guided transverse bend) and bend testing with backing plates - with alternatives for heterogeneous assemblies where materials differ in mechanical properties.
• Test conditions and parameters: Specifies selection criteria for former/roller diameters, roller spacing, bending angle and bending elongation; also addresses surface etching and test temperature considerations (testing temperature clause updated).
• Results and reporting: Defines acceptance criteria for revealing imperfections, documenting ductility, and preparing a test report (Annex A gives an example report).

Practical applications

EN ISO 5173:2023 is used to:

• Qualify weld procedures and welders by demonstrating acceptable weld ductility and absence of surface-breaking defects.
• Support quality control in fabrication, pressure-vessel manufacturing, pipeline construction and shipbuilding.
• Provide a repeatable, auditable destructive test for materials selection, supplier qualification and non-conformance investigation.
• Complement non‑destructive examination (NDE) by physically exposing near-surface defects that NDE may miss.

Who should use this standard

• Welding engineers and welding inspectors
• Metallurgical and mechanical test laboratories
• Quality managers in fabrication and heavy industry
• Certification bodies and regulatory authorities
• Designers and R&D teams validating welded joint performance

Related standards

EN ISO 5173:2023 sits within ISO/CEN welding test literature and is commonly used together with standards for visual, radiographic, ultrasonic and tensile testing of welds and materials (refer to national bodies for up-to-date normative references).

Keywords: EN ISO 5173:2023, bend tests, destructive tests on welds, transverse bend test, longitudinal bend test, butt weld, cladding, weld inspection, weld testing standard.
