EN ISO 17637:2016
(Main)Non-destructive testing of welds - Visual testing of fusion-welded joints (ISO 17637:2016)
Non-destructive testing of welds - Visual testing of fusion-welded joints (ISO 17637:2016)
ISO 17637:2016 specifies the visual testing of fusion welds in metallic materials. It may also be applied to visual testing of the joint prior to welding.
Zerstörungsfreie Prüfung von Schweißverbindungen - Sichtprüfung von Schmelzschweißverbindungen (ISO 17637:2016)
Dieses Dokument stellt die Sichtprüfung von Schmelzschweißnähten an metallischen Werkstoffen dar. Sie darf auch zur Sichtprüfung der Verbindung vor dem Schweißen angewendet werden.
Contrôle non destructif des assemblages soudés - Contrôle visuel des assemblages soudés par fusion (ISO 17637:2016)
ISO 17637:2016 traite du contrôle visuel des soudures par fusion des matériaux métalliques. Elle peut également s'appliquer au contrôle visuel des assemblages avant soudage.
Neporušitveno preskušanje zvarov - Vizualni pregled zvarnih spojev pri talilnem varjenju (ISO 17637:2016)
Ta dokument določa vizualni pregled talilnih zvarov pri kovinskih materialih. Uporablja se lahko tudi za vizualni pregled spoja pred varjenjem.
General Information
Relations
Standards Content (Sample)
SLOVENSKI STANDARD
01-marec-2017
1DGRPHãþD
SIST EN ISO 17637:2011
Neporušitveno preskušanje zvarov - Vizualni pregled zvarnih spojev pri talilnem
varjenju (ISO 17637:2016)
Non-destructive testing of welds - Visual testing of fusion-welded joints (ISO 17637:2016)
Zerstörungsfreie Prüfung von Schweißverbindungen - Sichtprüfung von
Schmelzschweißverbindungen (ISO 17637:2016)
Contrôle non destructif des assemblages soudés - Contrôle visuel des assemblages
soudés par fusion (ISO 17637:2016)
Ta slovenski standard je istoveten z: EN ISO 17637:2016
ICS:
25.160.40 Varjeni spoji in vari Welded joints and welds
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
EN ISO 17637
EUROPEAN STANDARD
NORME EUROPÉENNE
December 2016
EUROPÄISCHE NORM
ICS 25.160.40 Supersedes EN ISO 17637:2011
English Version
Non-destructive testing of welds - Visual testing of fusion-
welded joints (ISO 17637:2016)
Contrôle non destructif des assemblages soudés - Zerstörungsfreie Prüfung von Schweißverbindungen -
Contrôle visuel des assemblages soudés par fusion (ISO Sichtprüfung von Schmelzschweißverbindungen (ISO
17637:2016) 17637:2016)
This European Standard was approved by CEN on 19 October 2016.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this
European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references
concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN
member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by
translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management
Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania,
Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and
United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre: Avenue Marnix 17, B-1000 Brussels
© 2016 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN ISO 17637:2016 E
worldwide for CEN national Members.
Contents Page
European foreword . 3
European foreword
This document (EN ISO 17637:2016) has been prepared by Technical Committee ISO/TC 44 "Welding
and allied processes" in collaboration with Technical Committee CEN/TC 121 “Welding and allied
processes” the secretariat of which is held by DIN.
This European Standard shall be given the status of a national standard, either by publication of an
identical text or by endorsement, at the latest by June 2017, and conflicting national standards shall be
withdrawn at the latest by June 2017.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CEN [and/or CENELEC] shall not be held responsible for identifying any or all such patent
rights.
This document supersedes EN ISO 17637:2011.
According to the CEN-CENELEC Internal Regulations, the national standards organizations of the
following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria,
Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia,
France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta,
Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Turkey and the United Kingdom.
Endorsement notice
The text of ISO 17637:2016 has been approved by CEN as EN ISO 17637:2016 without any modification.
INTERNATIONAL ISO
STANDARD 17637
Second edition
2016-12-01
Non-destructive testing of welds —
Visual testing of fusion-welded joints
Contrôle non destructif des assemblages soudés — Contrôle visuel des
assemblages soudés par fusion
Reference number
ISO 17637:2016(E)
©
ISO 2016
ISO 17637:2016(E)
© ISO 2016, Published in Switzerland
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized otherwise in any form
or by any means, electronic or mechanical, including photocopying, or posting on the internet or an intranet, without prior
written permission. Permission can be requested from either ISO at the address below or ISO’s member body in the country of
the requester.
ISO copyright office
Ch. de Blandonnet 8 • CP 401
CH-1214 Vernier, Geneva, Switzerland
Tel. +41 22 749 01 11
Fax +41 22 749 09 47
copyright@iso.org
www.iso.org
ii © ISO 2016 – All rights reserved
ISO 17637:2016(E)
Contents Page
Foreword .iv
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 1
4 Test conditions and equipment . 1
5 Personnel qualification . 2
6 Visual testing . 2
6.1 General . 2
6.2 Visual testing of joint preparation . 2
6.3 Visual testing during welding . 2
6.4 Visual testing of the finished weld . 3
6.4.1 General. 3
6.4.2 Cleaning and dressing . 3
6.4.3 Profile and dimensions . 3
6.4.4 Weld root and surfaces . 3
6.4.5 Post-weld heat treatment . 4
6.5 Visual testing of repaired welds . 4
6.5.1 General. 4
6.5.2 Partially removed weld . 4
6.5.3 Completely removed weld . 4
7 Test records. 4
Annex A (informative) Examples of test equipment . 6
Bibliography .10
ISO 17637:2016(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www.iso.org/directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www.iso.org/patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation on the meaning of ISO specific terms and expressions related to conformity assessment,
as well as information about ISO’s adherence to the World Trade Organization (WTO) principles in the
Technical Barriers to Trade (TBT) see the following URL: www.iso.org/iso/foreword.html.
The committee responsible for this document is ISO/TC 44, Welding and allied processes, Subcommittee
SC 5, Testing and inspection of welds.
This second edition cancels and replaces the first edition (ISO 17637:2003), which has been technically
revised.
Requests for official interpretations of any aspect of this International Standard should be directed to
the Secretariat of ISO/TC 44/SC 5 via your national standards body. A complete listing of these bodies
can be found at www.iso.org.
iv © ISO 2016 – All rights reserved
INTERNATIONAL STANDARD ISO 17637:2016(E)
Non-destructive testing of welds — Visual testing of fusion-
welded joints
1 Scope
This document specifies the visual testing of fusion welds in metallic materials. It may also be applied
to visual testing of the joint prior to welding.
2 Normative references
There are no normative references in this document.
3 Terms and definitions
No terms and definitions are listed in this document.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at http://www.electropedia.org/
— ISO Online browsing platform: available at http://www.iso.org/obp
4 Test conditions and equipment
The illuminance at the surface with white light shall be a minimum of 350 lx; wearing of tinted goggles
(e.g. protective sunglasses) increases the minimum illuminance. However, 500 lx is recommended.
For direct inspection, the access shall be sufficient to place the eye within 600 mm of the surface to be
examined and at an angle not less than 30° (see Figure 1).
a
Range.
Figure 1 — Access for testing
Remote inspection using mirrors, boroscopes, fibre optic cables or cameras shall be considered when
the access for testing in accordance with Figure 1 is not possible or when specified by an application
standard.
An additional light source can be used to increase the contrast and relief between imperfections and
the background.
ISO 17637:2016(E)
Where the result of visual testing is inconclusive, the visual test should be supplemented by other non-
destructive testing methods for surface inspections.
Examples of equipment used for visual testing are given in Annex A.
5 Personnel q
...
