SIST-TP CLC/TR 60778:2005

Brush-holders for slip-rings group R - Type RA

Applies to radial brush-holders for slip-rings to be used on medium size asynchronous industrial machines of conventional construction for general applications, having shaft heights between 160 mm and 400 mm in the recommended range (in millimetres): 160, 180, 200, 225, 250, 280, 315, 355, 400. Has the status of a technical report.

Bürstenhalter für Schleifringe Gruppe R - Typ RA

Porte-balais pour bagues groupe R - Exécution RA

S'applique aux porte-balais radiaux de collecteurs à bagues à utiliser dans les machines industrielles asynchrones de grandeur moyenne, de construction classique et d'usage général comprises entre 160 mm et 400 mm de hauteur d'axe selon la gamme recommandée (en millimètres): 160, 180, 200, 225, 250, 280, 315, 335, 400. Cette publication a le statut d'un rapport.

Krtačna držala za drsne obroče skupine R – Tip RA (IEC/TR 60778:1984)

General Information

• Status: Published
• Publication Date: 31-May-2005
• ICS: 29.160.10 - Components for rotating machines
• Technical Committee: ERS - Rotating machinery
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Jun-2005
• Due Date: 01-Jun-2005
• Completion Date: 01-Jun-2005
• Ref Project: CLC/TR 60778:2004 - Brush-holders for slip-rings group R - Type RA

Overview

CLC/TR 60778:2004 - Brush-holders for slip-rings group R - Type RA - is a CLC technical report that gives guidance on radial brush-holders for slip-rings intended for medium-size asynchronous industrial machines of conventional construction. The report applies to machines with shaft heights in the recommended range (mm): 160, 180, 200, 225, 250, 280, 315, 355, 400. The document has the status of a technical report and is published in the CLC family (also issued as SIST-TP CLC/TR 60778:2005 in Slovenia).

Key topics

The technical report focuses on the following core aspects (as defined by its scope and classification):

• Applicability: Defines that it applies to radial brush-holders for slip-rings used on medium-size asynchronous machines (Group R, Type RA).
• Recommended shaft heights: Lists standard shaft heights in millimetres for which the brush-holders are intended: 160–400 mm (specific values provided).
• Classification and designation: Identifies the product group (R) and the specific execution (Type RA).
• Standards status: Clarifies that this document is a CLC technical report rather than a formal standard, useful for guidance and industry practice.

Note: The report is indexed under ICS 29.160.10 (Components for rotating machines).

Applications

CLC/TR 60778:2004 is relevant for professionals involved with slip-ring assemblies and rotating electrical machines:

• Design engineers specifying brush-holders for medium-size asynchronous motors and generators.
• Manufacturers of brush-holders and slip-ring assemblies ensuring compatibility with standard shaft heights and machine classes.
• Procurement and purchasing teams selecting components that conform to CLC technical guidance.
• Maintenance and reliability engineers replacing or upgrading slip-ring brush-holders in industrial equipment.

Practical use cases include retrofit selections, compatibility checks for replacement parts, and procurement specifications referencing Type RA brush-holder guidance.

Related standards

• Indexed under ICS 29.160.10 (components for rotating machines), so it should be used alongside broader CLC/IEC standards covering rotating electrical machines, slip rings, and brushes.
• As a technical report, CLC/TR 60778:2004 provides guidance that complements normative standards and manufacturer datasheets.

Keywords: brush-holders, slip-rings, radial brush-holder, Type RA, CLC/TR 60778:2004, asynchronous industrial machines, shaft heights, rotating machine components, technical report.
