Overview

oSIST prEN IEC 63409-7:2026 is a draft international standard published by CLC and IEC, detailing testing requirements for grid-connected photovoltaic (PV) power generating systems, specifically focusing on power conversion equipment (PCE). Part 7 of this standard emphasizes the evaluation of remote configuration, control, and monitoring functions, which are essential for modern PV systems integrated into smart grids and distributed energy networks. The document establishes testing environments, procedures, and criteria to ensure reliable and standardized information exchange between PV power conversion equipment and energy management systems.

Key Topics

• Remote Configuration: Defines testing protocols for configuring PV power conversion systems via remote communication, covering adjustments to operational parameters, device settings, and communication links.
• Remote Control: Outlines validation of remote commands for real-time control, such as starting/stopping generation, setting operational limits, and implementing grid support functionalities.
• Remote Monitoring: Specifies requirements for transmitting and verifying monitoring data, including power output, status, event logs, and diagnostics, from PCEs to distributed energy resource management systems (DERMS).
• Communication Standards: Emphasizes the use of the IEC 61850 standard series for communication structures and protocols, ensuring interoperability with energy management systems.
• Test Environment and Procedures: Provides guidelines for the setup of test environments, measurement devices, and reporting practices to ensure accurate and repeatable results.
• Performance Criteria: Specifies metrics and tolerances for evaluating the accuracy and responsiveness of remote functions in PV systems.

Applications

This standard supports a wide range of stakeholders involved in the deployment and operation of grid-connected photovoltaic systems:

• PV System Manufacturers: Ensures that power conversion equipment meets international requirements for remote management, facilitating product acceptance in global markets.
• Grid Operators: Assists in integrating PV systems into the smart grid, enabling real-time control and system stability through standardized remote interaction.
• Testing Laboratories: Provides a reference for conducting standardized, verifiable tests of remote configuration, control, and monitoring features in accordance with IEC guidelines.
• Installers and Integrators: Offers confidence that equipment can be managed and monitored remotely, streamlining maintenance, troubleshooting, and system upgrades.
• Energy Management System Developers: Specifies data models and communication interfaces, ensuring seamless integration between distributed energy resources and control platforms.

Related Standards

oSIST prEN IEC 63409-7:2026 references and complements several important international standards in photovoltaic power systems and grid integration, including:

• IEC TS 62786-1: Distributed energy resources connection with the grid - Part 1: General requirements
• IEC 61850 Series: Communication networks and systems for power utility automation, focusing on logical nodes, data objects, and communication service mapping (including IEC 61850-7-1, IEC 61850-7-4, IEC 61850-7-420, IEC 61850-8-1, and IEC 61850-8-2)
• IEC 62934: Grid integration of renewable energy generation - Terms and definitions
• IEC 62053-23: Particular requirements for static meters for reactive energy
• IEC 63409-6: Testing of power conversion equipment – Part 6: Power control functions and grid support

By adhering to oSIST prEN IEC 63409-7:2026, organizations can ensure that their photovoltaic power systems comply with unified requirements for remote management, supporting efficient integration, enhanced system reliability, and robust communication within the evolving smart grid landscape.

Keywords: photovoltaic power generating systems, grid-connected PV, power conversion equipment, remote configuration, remote control, monitoring, energy management systems, IEC 63409-7, smart grid, distributed energy resources, IEC 61850, PV testing standards.
