Technical Report ISO/TR 20659-1:2024(en)
Rheological test methods — Fundamentals and
interlaboratory comparisons —
Part 1:
Determination of the yield point
1 Scope
This document gives information on an interlaboratory comparison for the determination of the yield point,
using rheological test methods. The yield point is the shear stress τ below which a material does not flow.
This document provides examples of fields of applications, in which important material properties are
characterized with the aid of the yield point. These fields of application include:
— effectiveness of rheological additives;
— shelf life (e.g. with regard to sedimentation, separation and flocculation);
— stability of the structure at rest;
— behaviour when starting to pump;
— use in scraper systems;
— wet-film thickness;
— levelling and sagging behaviour (e.g. without brushmarks or sag formation);
— orientation of effect pigments.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content constitutes
requirements of this document. For dated references, only the edition cited applies. For undated references,
the latest edition of the referenced document (including any amendments) applies.
ISO 3219-1, Rheology — Part 1: Vocabulary and symbols for rotational and oscillatory rheometry
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 3219-1.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
4 Goal of the interlaboratory test
In the interlaboratory test, different possibilities for determining the yield point using the preferred methods
were considered.
ISO/TR 20659-1:2024(en)
The samples used in the comparative testing programme consisted of different waterborne basecoats
with lower yield points and dispersions with distinctly higher yield points. The samples also included the
following limited cases:
— very low yield points (<1 Pa), at which the range of elastic deformation is so low that the material can also
be approximately considered as a liquid at the state of rest;
— materials of which the internal structure is disintegrated only stepwise so that a transition range is
occurring and a yield zone rather than a punctual yield point is determined.
Furthermore, a non-Newtonian reference sample from the the National Metrology Institute of Germany
(PTB) was also included in the comparative testing programme.
Some background information on the original interlaboratory test is given in Annex A.
5 Metrological determination of the yield point
5.1 General
Clause 5 briefly describes all the methods in use at the time of publication. In principle, the yield point
depends on the temperature, the pressure and the thermal and mechanical history of the material. A detailed
specification of the measuring profile is therefore a precondition for reproducible measurements.
5.2 Shear rate-controlled rotational test
The shear rate γ is specified in the form of a ramp, as shown in Figure 1.
Key
shear rate
γ
t time
Figure 1 — Shear rate/time function as a ramp
5.3 Yield point evaluation using flow curve regression models
With a linear representation of the flow curve (usually the shear stress τ as a function of the shear rate γ ),
the yield point is determined as the axis intercept on the τ axis (Figure 2).
ISO/TR 20659-1:2024(en)
Key
τ shear stress
τ Bingham yield point
B
K consistency index according to Bingham
B
shear rate
γ
1 chosen shear rate range
Figure 2 — Flow curve regression according to Bingham
This yield point value depends not only on the specified ramp period, but also on the chosen shear rate range
and the chosen regression model. In industrial laboratories, the models according to Bingham, Casson or
Herschel/Bulkley are widely used.
The mod
...
