IEC

IEC 60169-19:1985

(Main)

Radio-frequency connectors. Part 19: R.F. coaxial connectors with inner diameter of outer conductor of 2.08 mm (0.082 in) with snap coupling. Characteristic impedance 50 ohms (Type SSMB)

Radio-frequency connectors. Part 19: R.F. coaxial connectors with inner diameter of outer conductor of 2.08 mm (0.082 in) with snap coupling. Characteristic impedance 50 ohms (Type SSMB)

Provides basic mating and performance information for subminiature coaxial connectors with overlapping polytetrafluoroethylene (PTFE) dielectric interface for use with flexible and semi-rigid r.f. cables. The connectors are usable up to a frequency of 3 GHz. Only the interface dimensions are standardized. Other technical data are supplied for guidance only. The contents of the corrigendum of July 1995 have been included in this copy.

Connecteurs pour fréquences radioélectriques. Dix-neuvième partie: Connecteurs coaxiaux pour fréquences radioélectriques avec diamètre intérieur du conducteur extérieur de 2,08 mm (0,082 in) à verrouillage à encliquetage. Impédance caractéristique 50 ohms (type SSMB)

Fournit les interchangeabilités et les performances de base pour des connecteurs coaxiaux subminiatures mettant en oeuvre une interface à diélectrique PTFE pour utilisation avec des câbles HF souples et semi-rigides. Ces connecteurs sont utiljsables jusqu'à 3 GHz. Seules les dimensions d'interface sont normalisées. Les autres données techniques sont fournies uniquement à litre indicatif. Le contenu du corrigendum de juillet 1995 a été pris en considération dans cet exemplaire.

General Information

Status
Replaced
Publication Date
30-Jun-1995
ICS
33.120.30 - RF connectors
Technical Committee
SC 46F - RF and microwave passive components
Current Stage
WPUB - Publication withdrawn
Completion Date
05-Oct-2010
Ref Project

Relations

Replaced By
IEC 61169-19:2011 - Radio-frequency connectors - Part 19: Sectional specification - Radio frequency coaxial connectors of type SSMB
Effective Date
05-Sep-2023
IEC 60169-19:1985/COR1:1995 - Corrigendum 1 - Radio-frequency connectors. Part 19: R.F. coaxial connectors with inner diameter of outer conductor of 2.08 mm (0.082 in) with snap coupling. Characteristic impedance 50 ohms (Type SSMB) Released:7/1/1995IEC 60169-19:1985/COR1:1995 - Corrigendum 1 - Radio-frequency connectors. Part 19: R.F. coaxial connectors with inner diameter of outer conductor of 2.08 mm (0.082 in) with snap coupling. Characteristic impedance 50 ohms (Type SSMB) Released:7/1/1995
PreviousNext
Standard
IEC 60169-19:1985/COR1:1995 - Corrigendum 1 - Radio-frequency connectors. Part 19: R.F. coaxial connectors with inner diameter of outer conductor of 2.08 mm (0.082 in) with snap coupling. Characteristic impedance 50 ohms (Type SSMB) Released:7/1/1995
English and French language
1 pages
sale 15% off
Preview
sale 15% off
Preview

Standards Content (Sample)


IEC Publication 169-19
Publication 169-19 de la CEI
(First edition - 1985)
(Première édition - 1985)
Radio-frequency connectors
Connecteurs pour fréquences
radioélectriques
Part 19: R.F. coaxial connectors with
inner diameter of outer
Dix-neuvième partie: Connecteurs coaxiaux pour
conductor 2,08 mm (0,082 in) with
fréquences radioélectriques avec diamètre
snap coupling -
intérieur du conducteur extérieur de 2,08 mm
Characteristics impedance
(0,082 in) à verrouillage à encliquetage -
50 ohms (Type SSMB)
Impédance caractéristique 50 ohms (type SSMB)
CORRIGENDUM 1
Pa
...
