IEC 60317-4:2015

Specifications for particular types of winding wires - Part 4: Solderable polyurethane enamelled round copper wire, class 130

IEC 60317-4:2015 specifies the requirements of solderable enamelled round copper winding wire of class 130 with a sole coating based on polyurethane resin, which may be modified provided it retains the chemical identity of the original resin and meets all specified wire requirements. The range of nominal conductor diameters covered by this standard is:
- Grade 1: 0,018 mm up to and including 2,000 mm;
- Grade 2: 0,020 mm up to and including 2,000 mm. The nominal conductor diameters are specified in Clause 4 of IEC 60317-0-1:2013. This fourth edition cancels and replaces the third edition published in 1990, Amendment 1:1997 and Amendment 2:1999. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
- new 3.2.2 containing general notes on winding wire, formerly a part of the scope;
- new 3.2.3 containing requirements for appearance;
- revision to references to IEC 60317-0-1:2013 to clarify that their application is normative;
- consolidation of 17.1 and 17.2 of the solderability requirements;
- revision to Clause 19, dielectric dissipation factor;
- new Clause 23, pin hole test. Keywords: insulated wires used for windings
This publication is to be read in conjunction with IEC 60317-0-1:2013.

Spécifications pour types particuliers de fils de bobinage - Partie 4: Fil brasable de section circulaire en cuivre émaillé avec polyuréthane, classe 130

L'IEC 60317-4:2015 spécifie les exigences relatives aux fils de bobinage brasables de section circulaire en cuivre émaillé de classe 130 avec un revêtement unique à base de résine polyuréthane, qui peut être modifiée à condition qu'elle conserve l'identité chimique de la résine initiale et réponde à toutes les exigences spécifiées pour le fil. La gamme des diamètres nominaux des conducteurs couverte par la présente norme est:
- Grade 1: 0,018 mm jusques et y compris 2,000 mm;
- Grade 2: 0,020 mm jusques et y compris 2,000 mm. Les diamètres nominaux des conducteurs sont spécifiés à l'Article 4 de l'IEC 60317-0-1:2013. Cette quatrième édition annule et remplace la troisième édition parue en 1990, l'Amendement 1:1997 et l'Amendement 2:1999. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
- un nouveau 3.2.2 contenant des notes générales sur le fil de bobinage intégrées auparavant au domaine d'application;
- un nouveau 3.2.3 comprenant des exigences relatives à l'aspect;
- la révision des références à l'IEC 60317-0-1:2013 pour bien établir que leur application est normative;
- une consolidation du 17.1 et du 17.2 concernant les exigences de brasabilité;
- la révision de l'Article 19, facteur de dissipation diélectrique;
- un nouvel Article 23, détection des microfissures en immersion. Mots clés: des fils isolés utilisés pour les enroulements
Cette publication doit être lue conjointement avec la IEC 60317-0-1:2013.

General Information

• Status: Published
• Publication Date: 03-Jan-2022
• ICS: 01 - GENERALITIES. TERMINOLOGY. STANDARDIZATION. DOCUMENTATION
• ICS: 29.060.10 - Wires
• ICS: 31.180 - Printed circuits and boards
• Technical Committee: TC 55 - Winding wires
• Current Stage: WPUB - Publication withdrawn
• Completion Date: 04-Jan-2022
