Data Link Services (DLS) System - Community Specification for application under the Single European Sky Interoperability Regulation EC 552/2004 requirements for ground constituents and system testing
Data link technology improves the efficiency of communications between controllers and pilots through supplementing voice communications with air-ground data link communications. On 30 September 2008 the Single Sky Committee has given a favourable opinion on the Implementing Rule on Data Link Services (DLS) in which the coordinated introduction of data link based on air-ground point-to-point data communications is described from 2011 onwards. The deployment of data link will also be the first major achievement that contributes to the first implementation package (IP1) of the European Air Traffic Management Master Plan (the ATM Master Plan). The Implementing Rule on Data Link Services (DLS) is requiring the following services that should be operated over an ATN (Aeronautical Communication Network( and VDL (Very High Frequency Digital Link) Mode 2 infrastructure: 1. DLIC - Data Link Initiation Capability (log on and contact) 2. ACM - Air Traffic Control (ATC) Communications Management 3. ACL - Air Traffic Control (ATC) Clearances 4. AMC - Air Traffic Control (ATC) Microphone Check The related European standards will be developed in accordance with the implementing rule on data link services and in line with the EUROCONTROL Specification on Data Link Services.
Sistem storitev podatkovnih povezav (DLS) - Specifikacija Skupnosti za izvajanje zahtev Uredbe o medobratovalnosti na enotnem evropskem nebu EC 552/2004 za zemeljske sestavne dele in preskušanje sistema
Tehnologija podatkovnih povezav izboljšuje učinkovitost komunikacij med nadzorniki in piloti skozi dopolnjene glasovne komunikacije s komunikacijami podatkovnih povezav zrak-tla. Odbor za enotno evropsko nebo je 30 septembra 2008 podal ugodno mnenje glede Izvedbenega pravila o storitvah podatkovnih povezav (DLS), v katerih je usklajena predstavitev podatkovne povezave pri podatkovnih komunikacijah zrak-tla točka-točka, opisana od leta 2011 naprej. Namestitev podatkovne povezave je prav tako prvi velik dosežek, ki pripomore k prvemu paketu vpeljave (IP1) glavnega načrta nadzora evropskega zračnega prometa (ATM glavni načrt). Pravilo vpeljave v storitve podatkovnih povezav (DLS) zahteva naslednje storitve, ki bi morale delovati prek infrastrukture načina 2 ATN (aeronavtično komunikacijsko omrežje) in VDL (zelo visoko frekvenčne podatkovne povezave): 1. DLIC - zmogljivost zagona podatkovnih povezav (prijava in kontakt) 2. ACM – upravljanje komunikacije kontrole zračnega prometa (ATC) 3. ACL – dovoljenja kontrole zračnega prometa (ATC) 4. AMC – preskus mikrofona kontrole zračnega prometa (ATC). Ustrezen Evropski standard bo razvit v skladu s pravili vpeljave storitve podatkovnih povezav in vzporedno s specifikacijo EUROCONTROL na storitvah podatkovnih povezav.
