SIST ISO 9177-2:2024

Mechanical pencils for technical drawings - Part 2: Black leads - Classification and dimensions

This document specifies a classification and dimensions for black leads used for mechanical pencils for technical drawings.
Two types of black leads are available:
— polymer leads (designated by the letter “P”);
— ceramic leads (designated by the letter “C”).

Porte-mines pour le dessin technique — Partie 2: Mines graphite — Classification et dimensions

La présente partie de l'ISO 9177 spécifie une classification et les dimensions des mines graphite utilisées dans les porte-mine à dessin. Deux types de mines graphite sont disponibles :
les mines polymère (désignées par la lettre «P»)
les mines céramique (désignées par la lettre «C»)

Tehnični svinčniki za tehnično risanje - 2. del: Grafitni vložki - Razdelitev in mere

Ta dokument določa klasifikacijo in mere za grafitne vložke, ki se uporabljajo v tehničnih svinčnikih za tehnično risanje.
Na voljo sta dve vrsti grafitnega vložka:
– polimerni vložek (označen s črko »P«);
– keramičen vložek (označen s črko »C«).

General Information

• Status: Published
• Publication Date: 31-Jan-2024
• ICS: 01.100.40 - Drawing equipment
• ICS: 97.180 - Miscellaneous domestic and commercial equipment
• Technical Committee: TRS - Technical drawings, quantities, units, symbols and graphical symbols
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 24-Jan-2024
• Due Date: 30-Mar-2024
• Completion Date: 01-Feb-2024
• Ref Project: ISO 9177-2:2022 - Mechanical pencils for technical drawings - Part 2: Black leads - Classification and dimensions

Relations

• Replaces: SIST ISO 9177-2:1995 - Mechanical pencils -- Part 2: Black leads -- Classification and dimensions
• Effective Date: 01-Mar-2024

Overview

ISO 9177-2:2022 - Mechanical pencils for technical drawings - Part 2: Black leads - Classification and dimensions specifies the classification, nominal diameters and standard lengths for black leads used exclusively in mechanical pencils intended for technical drawing. The standard defines two lead types: polymer leads (P) and ceramic leads (C), and sets requirements that support consistent line quality, interchangeability and clear product designation.

Key topics

• Types of black leads: Polymer (designated “P”) and ceramic (designated “C”).
• Hardness degree: Standardized hardness scale runs from soft (6B) to hard (9H), with HB as the median. Hardness availability varies with nominal diameter (smaller diameters cover a narrower hardness range).
• Nominal diameters: Standard diameters include 0.25 mm, 0.35 mm, 0.5 mm, 0.7 mm, 1 mm, (1.4 mm noted) and 2 mm. Note: common market labels like 0.3 and 0.9 correspond to 0.35 and 1 mm respectively.
• Standard lengths: Typical standardized lead lengths include 60 mm, 90 mm, 100 mm, 30 mm, 45 mm, 25 mm, and 130 mm; actual length depends on the pencil mechanism and nominal diameter.
• Designation format: Packaging and product marking should follow the prescribed format:
  • Example polymer: Black lead ISO 9177-2-P-0,5-60
  • Example ceramic: Black lead ISO 9177-2-C-2-130
• Normative references: Cross-references include ISO 128-2 (line conventions) and ISO 9177-1 (classification, dimensions, performance and testing for mechanical pencils).

Applications

• Ensures interchangeability of leads across mechanical pencils used for technical drawings in architecture, engineering and drafting.
• Helps manufacturers and suppliers define product specifications, labeling and quality control for black leads.
• Assists specifiers, procurement teams and design studios in selecting leads by diameter, hardness and type for predictable line thickness and erasability.
• Useful for standards compliance, product development and technical documentation where consistent drawing materials are required.

Related standards

• ISO 9177-1 - Mechanical pencils for technical drawings: classification, dimensions, performance requirements and testing.
• ISO 128-2 - Technical product documentation: basic conventions for lines.
• ISO 20318 series - Mechanical pencils and leads for general use (classification, dimensions, quality and test methods).

Keywords: ISO 9177-2, mechanical pencils for technical drawings, black leads, polymer leads, ceramic leads, lead diameters, lead lengths, hardness degree, lead designation.
