SIST EN 15010:2007

Aerosol containers - Aluminium containers - Tolerances of the fundamental dimensions in connection with the clinch

This European Standard defines the critical dimensions of the location of the 25,4 mm aperture relative to the base of aerosol cans for clinching with valve cups.
The specification of the fundamental dimensions in this standard, relates to all 25,4 mm aperture aluminium and aluminium alloy cans, irrespective of size, shape and mode of manufacture; whose dimensions and tolerances fall within the dimensional scope of EN 15008.

Aerosolpackungen - Aluminiumbehälter - Toleranzen der Grundmaße im Zusammenhang mit dem Clinch

Diese Europäische Norm legt die kritischen Maße hinsichtlich der Lage der 25,4 mm weiten Öffnung in Bezug
auf den Boden von Aerosoldosen fest, die für das Aufclinchen von Ventilträgern geeignet sind.
Die in dieser Norm festgelegten Grundmaße beziehen sich ohne Berücksichtigung von Größe, Form und
Herstellungsverfahren auf alle Behälter aus Aluminium und Aluminiumlegierungen mit 25,4 mm weiten
Öffnungen, deren Maße und Toleranzen in den Abmessungsbereich von prEN 15008 fallen.

Récipients pour aérosols - Récipients en aluminium - Tolérances des dimensions de base en rapport avec le dudgeonnage

Embalaža za aerosole – Posode iz aluminija – Dovoljena odstopanja osnovnih mer v povezavi z objemko (clinch)

General Information

• Status: Published
• Publication Date: 31-Mar-2007
• ICS: 55.130 - Aerosol containers
• ICS: 77.150.10 - Aluminium products
• Technical Committee: EPO - Packaging - sales and grouped
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Apr-2007
• Due Date: 01-Apr-2007
• Completion Date: 01-Apr-2007
• Ref Project: EN 15010:2006 - Aerosol containers - Aluminium containers - Tolerances of the fundamental dimensions in connection with the clinch

Overview

EN 15010:2006 is a CEN European Standard that defines the critical fundamental dimensions for aluminium aerosol containers with a 25,4 mm (nominal) aperture when clinched with valve cups. It specifies the dimensional tolerances that affect closure efficiency and interchangeability between cans and valve cups. The standard applies to all 25,4 mm aperture aluminium and aluminium-alloy aerosol cans whose sizes and tolerances fall within the dimensional scope of EN 15008.

Key topics and requirements

• Scope and applicability: Covers aluminium and aluminium-alloy aerosol containers with a 25,4 mm aperture, irrespective of size, shape or manufacturing method provided they fall within EN 15008 dimensional limits.
• Critical dimensions: Focuses on the location of the 25,4 mm aperture relative to the base of the can - the features that are most important for reliable clinching with valve cups.
• Tolerances specified: The standard sets tolerances for:
  • Eccentricity (aperture offset) - maximum allowed eccentricity is specified and is independent of can height.
  • Parallelism (of the aperture plane relative to the base) - measured from the upper surface of the bead; alternative, tighter tolerances apply if flowed-in gaskets are used.
  • Height (distance from base to aperture) - the standard provides height tolerances; for example, the document shows height tolerances of approximately ±0.4 mm for H ≤ 260 mm and ±0.5 mm for H > 260 mm (as given in the standard figure).
• Dimensional datum: Measurement methods reference the bead and base surfaces to ensure consistent inspection and process control.
• Purpose: Dimensions are intended as good practice for can manufacturers and as acceptance criteria for fillers and valve cup suppliers.

Applications and who uses it

• Can manufacturers use EN 15010 for process control, tooling setup and production tolerances to ensure consistent clinching performance.
• Aerosol fillers and packers rely on the tolerances for incoming goods inspection and to set swage (valve setting) parameters.
• Valve cup and closure suppliers use the defined dimensions to design compatible valve components and gasket arrangements.
• Quality engineers and test laboratories apply the standard when verifying closure integrity, interchangeability and compliance with customer specifications.
• Procurement and specification writers reference EN 15010 in supplier contracts to ensure component compatibility.

Related standards

• EN 15008 - Aluminium containers: dimensions of one-piece cans with 25,4 mm aperture
• EN 15006 - Metal aerosol containers: aluminium containers - dimensions of the 25,4 mm aperture
• EN 14848 - Metal containers with 25,4 mm aperture - dimensions of valve cups
• EN 14850 - Measurement of contact height
  (EN 15010 is part of a series of aerosol packaging standards covering apertures, valve components and testing.)

Keywords: EN 15010, aerosol containers, aluminium cans, 25.4 mm aperture, clinch, tolerances, eccentricity, parallelism, valve cups, can manufacturer, filler, swage setting.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Embalaža za aerosole – Posode iz aluminija – Dovoljena odstopanja osnovnih mer v povezavi z objemko (clinch)Aerosolpackungen - Aluminiumbehälter - Toleranzen der Grundmaße im Zusammenhang mit dem ClinchRécipients pour aérosols - Récipients en aluminium - Tolérances des dimensions de base en rapport avec le dudgeonnageAerosol containers - Aluminium containers - Tolerances of the fundamental dimensions in connection with the clinch77.150.10Aluminijski izdelkiAluminium products55.130Aerosol containersICS:Ta slovenski standard je istoveten z:EN 15010:2006SIST EN 15010:2007en,fr,de01-april-2007SIST EN 15010:2007SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 15010October 2006ICS 55.130 English VersionAerosol containers - Aluminium containers - Tolerances of thefundamental dimensions in connection with the clinchRécipients pour aérosols - Récipients en aluminium -Tolérances des dimensions de base en rapport avec ledudgeonnageAerosolpackungen - Aluminiumbehälter - Toleranzen derGrundmaße im Zusammenhang mit dem ClinchThis European Standard was approved by CEN on 6 August 2006.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania,Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2006 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 15010:2006: ESIST EN 15010:2007
...
