Calibration and accuracy of non-catching precipitation measurement instruments

Non-catching type gauges are the emerging class of in situ precipitation measurement instruments. For these instruments, rigorous testing and calibration are more challenging than for traditional gauges. Hydrometeors’ characteristics like particle size, shape, fall velocity and density need to be reproduced in a controlled environment to provide the reference precipitation, instead of the equivalent water flow used for catching-type gauges. They are generally calibrated by the manufacturers using internal procedures developed for the specific technology employed. No agreed methodology exists, and the adopted procedures are rarely traceable to internationally recognized standards. This document describes calibration and accuracy issues of non-catching instruments used for liquid/solid atmospheric precipitation measurement. An overview of the existing models of non-catching type instruments is included, together with an overview and a description of their working principles and the adopted calibration procedures. The literature and technical manuals disclosed by manufacturers are summarized and discussed, while current limitations and metrological requirements are identified.

Kalibrierung und Genauigkeit von nicht auffangenden Niederschlagsmessgeräten

Étalonnage et précision des pluviomètres sans captage

Kalibracija in točnost instrumentov za merjenje padavin brez njihovega zajemanja

Merilniki brez funkcije zajemanja so nov razred instrumentov za merjenje padavin na mestu uporabe. Strogo preskušanje in kalibracija sta pri teh instrumentih zahtevnejša kot pri tradicionalnih merilnikih. Značilnosti hidrometeorjev, kot so velikost delcev, oblika, hitrost padca in gostota, je namesto enakovrednega pretoka vode, ki se uporablja za merilnike s funkcijo zajemanja, treba reproducirati v nadzorovanem okolju, da se zagotovijo referenčne padavine. Običajno jih kalibrirajo proizvajalci z notranjimi postopki, ki so razviti za specifično uporabljeno tehnologijo. Dogovorjena metodologija ne obstaja, sprejeti postopki pa so redko sledljivi do mednarodno priznanih standardov. Ta dokument opisuje težave v zvezi s kalibracijo in točnostjo instrumentov brez funkcije zajemanja, ki se uporabljajo za merjenje atmosferskih padavin v tekočem/trdnem stanju. Vključuje pregled obstoječih modelov instrumentov brez funkcije zajemanja ter pregled in opis načinov njihovega delovanja ter sprejetih postopkov kalibracije. V dokumentu so povzeti in obravnavani literatura in tehnični priročniki, ki so jih navedli proizvajalci, ter opredelitve trenutnih omejitev in meroslovne zahteve.
