SIST EN IEC 60332-3-10:2018/A11:2021

Tests on electric and optical fibre cables under fire conditions - Part 3-10: Test for vertical flame spread of vertically-mounted bunched wires or cables - Apparatus

EN 60332-3-10:2018 details the apparatus and its arrangement and calibration for methods of test for the assessment of vertical flame spread of vertically mounted bunched wires or cables, electrical or optical, under defined conditions.

Prüfungen an Kabeln, isolierten Leitungen und Glasfaserkabeln im Brandfall - Teil 3-10: Prüfung der vertikalen Flammenausbreitung von vertikal angeordneten Bündeln von Kabeln und isolierten Leitungen - Prüfvorrichtung

Essais des câbles électriques et des câbles à fibres optiques soumis au feu - Partie 3-10: Essai de propagation verticale de la flamme des fils ou câbles montés en nappes en position verticale - Appareillage

Preskusi na električnih kablih in kablih iz optičnih vlaken v požarnih razmerah - 3-10. del: Preskus navpičnega širjenja ognja po navpično pritrjenih snopih žic ali kablov - Preskuševalna naprava - Dopolnilo A11

General Information

• Status: Published
• Publication Date: 16-Nov-2020
• ICS: 13.220.40 - Ignitability and burning behaviour of materials and products
• ICS: 29.020 - Electrical engineering in general
• ICS: 29.060.20 - Cables
• Technical Committee: IEKA - Electric cables
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 13-Nov-2020
• Due Date: 18-Jan-2021
• Completion Date: 17-Nov-2020
• Ref Project: EN IEC 60332-3-10:2018/A11:2020 - Tests on electric and optical fibre cables under fire conditions - Part 3-10: Test for vertical flame spread of vertically-mounted bunched wires or cables - Apparatus

Overview

EN IEC 60332-3-10:2018/A11:2020 specifies the apparatus, arrangement and calibration required for tests that assess vertical flame spread of vertically-mounted bunched wires or cables, including both electrical and optical fibre cables, under defined fire conditions. This amendment (A11) updates positioning and apparatus details used when performing the Part 3-10 vertical flame spread test within the EN IEC 60332 series. The standard is published by CLC/CENELEC and applies across member countries.

Key topics and technical requirements

• Scope: Apparatus and its calibration for the vertical flame-spread test of bunched (multi‑cable) vertical samples.
• Burner positioning (updated by A11):
  • Burner arranged horizontally at (75 ± 5) mm from the front surface of the cable sample.
  • Burner centreline located (600 ± 5) mm above the test chamber floor.
  • Burner symmetrical with the ladder axis and the flame applied between two rungs of the ladder.
• Apparatus layout: Specifies ladder support, rungs, wire ties and optional leg extensions for consistent sample mounting (Figure references updated).
• Calibration & arrangement: Defines repeatable set‑up and calibration routines for the burner and test chamber to ensure comparable, reproducible results across test laboratories.
• Standards management: Amendment details, implementation dates and CENELEC adoption obligations are included to support national standardization.

Applications and practical value

• Provides a repeatable laboratory method to characterize vertical flame spread behaviour of cable bundles, supporting:
  • Product development and material selection (insulation/jacket formulations).
  • Regulatory compliance and safety assessments for buildings, transport and industrial installations.
  • Comparison of cable designs and flame-retardant treatments under standardized conditions.
• Helps manufacturers and test laboratories generate defensible, comparable data used in safety reports, procurement specifications, and certification processes.

Who uses this standard

• Cable manufacturers (electrical and optical fibre)
• Independent fire test laboratories and certification bodies
• Product safety and compliance engineers
• Specifiers, architects and procurement teams requiring verified fire-performance data
• Regulators and standards bodies implementing national adoption of CENELEC documents

Related standards

• Other parts of the EN/IEC 60332 series (tests for flame propagation on single cables and other configurations)
• National fire test methods and building codes that reference EN IEC methods

Keywords: EN IEC 60332-3-10:2018/A11:2020, vertical flame spread, bunched wires, cable fire test apparatus, burner positioning, cable fire testing, optical fibre cable fire performance.

Standards Content (Sample)

SLOVENSKI STANDARD
01-januar-2021
Preskusi na električnih kablih in kablih iz optičnih vlaken v požarnih razmerah - 3-
10. del: Preskus navpičnega širjenja ognja po navpično pritrjenih snopih žic ali
kablov - Preskuševalna naprava - Dopolnilo A11
Tests on electric and optical fibre cables under fire conditions - Part 3-10: Test for
vertical flame spread of vertically-mounted bunched wires or cables - Apparatus
Prüfungen an Kabeln, isolierten Leitungen und Glasfaserkabeln im Brandfall - Teil 3-10:
Prüfung der vertikalen Flammenausbreitung von vertikal angeordneten Bündeln von
Kabeln und isolierten Leitungen - Prüfvorrichtung
Essais des câbles électriques et des câbles à fibres optiques soumis au feu - Partie 3-
10: Essai de propagation verticale de la flamme des fils ou câbles montés en nappes en
position verticale - Appareillage
Ta slovenski standard je istoveten z: EN IEC 60332-3-10:2018/A11:2020
ICS:
13.220.40 Sposobnost vžiga in Ignitability and burning
obnašanje materialov in behaviour of materials and
proizvodov pri gorenju products
29.060.20 Kabli Cables
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

EUROPEAN STANDARD EN IEC 60332-3-10:2018/A11

NORME EUROPÉENNE
EUROPÄISCHE NORM
October 2020
ICS 13.220.40; 29.020; 29.060.20

English Version
Tests on electric and optical fibre cables under fire conditions -
Part 3-10: Test for vertical flame spread of vertically-mounted
bunched wires or cables - Apparatus
Essais des câbles électriques et des câbles à fibres Prüfungen an Kabeln, isolierten Leitungen und
optiques soumis au feu - Partie 3-10: Essai de propagation Glasfaserkabeln im Brandfall - Teil 3-10: Prüfung der
verticale de la flamme des fils ou câbles montés en nappes vertikalen Flammenausbreitung von vertikal angeordneten
en position verticale - Appareillage Bündeln von Kabeln und isolierten Leitungen -
Prüfvorrichtung
This amendment A11 modifies the European Standard EN IEC 60332-3-10:2018; it was approved by CENELEC on 2020-09-16. CENELEC
members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this amendment the
status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This amendment exists in three official versions (English, Frenc
...
