EN ISO 3098-1:2015

Technical product documentation - Lettering - Part 1: General requirements (ISO 3098-1:2015)

ISO 3098-1:2015 specifies the general requirements for lettering, in accordance with the other parts of ISO 3098, to be used in technical product documentation (in particular on technical drawings). It includes basic conventions as well as rules for the application of lettering using the following techniques: free-hand lettering (by means of an underlaid "grid"); templates and manual lettering instruments; dry transfer systems; numerically controlled lettering and draughting systems.

Technische Produktdokumentation - Schriften - Teil 1: Grundregeln (ISO 3098-1:2015)

Documentation technique de produits - Écriture - Partie 1: Exigences générales (ISO 3098-1:2015)

L'ISO 3098-1:2015 fixe, en conformité avec les autres parties de l'ISO 3098, les exigences générales d'écriture devant être appliquées dans le domaine de la documentation technique de produits (en particulier aux dessins techniques). Elle comprend des principes conventionnels de base, ainsi que des règles relatives à l'écriture mettant en oeuvre les techniques suivantes: écriture à main levée (au moyen d'un quadrillage «caché en arrière-plan» - sorte de grille typomatique); gabarits de dessin et instruments pour écriture à la main; décalcomanies à sec; systèmes d'écriture et de dessin à commande numérique.

Tehnična dokumentacija izdelkov - Pisava - 1. del: Splošne zahteve (ISO 3098-1:2015)

Ta del standarda ISO 3098 določa splošne zahteve za pisavo, v skladu z drugimi deli standarda ISO 3098, ki se uporablja v tehnični dokumentaciji izdelkov (zlasti na tehničnih risbah). Vključuje osnovne konvencije in pravila za pisavo pri uporabi naslednjih tehnik:
a) prostoročno pisanje (s podlago iz »mreže«);
b) predloge in ročni instrumenti za pisanje;
c) suhi sistemi za prenos;
d) numerično krmiljeno pisanje in skicirni sistemi.

General Information

• Status: Published
• Publication Date: 03-Mar-2015
• Withdrawal Date: 29-Sep-2015
• ICS: 01.100.01 - Technical drawings in general
• ICS: 01.110 - Technical product documentation
• ICS: 01.140.10 - Writing and transliteration
• Technical Committee: CEN/SS F01 - Technical drawings
• Drafting Committee: CEN/SS F01 - Technical drawings
• Current Stage: 6060 - Definitive text made available (DAV) - Publishing
• Start Date: 04-Mar-2015
• Completion Date: 04-Mar-2015
• Ref Project: SIST EN ISO 3098-1:2015 - Technical product documentation - Lettering - Part 1: General requirements (ISO 3098-1:2015)

Relations

• Replaces: EN ISO 3098-0:1997 - Technical product documentation - Lettering - Part 0: General requirements (ISO 3098-0:1997)
• Effective Date: 11-Mar-2015

Overview

EN ISO 3098-1:2015 - Technical product documentation - Lettering - Part 1: General requirements (ISO 3098-1:2015) is the CEN-endorsed European version of the ISO standard that defines the general rules for lettering used in technical product documentation, particularly technical drawings. It replaces EN ISO 3098-0:1997 and establishes conventions applicable to manual and machine-based lettering methods, including CAD/numerically controlled systems.

Key topics and technical requirements

• Scope and purpose: General requirements for lettering consistent with other parts of ISO 3098 (alphabets, diacritics, CAD application).
• Lettering techniques covered:
  • Free-hand lettering (with an underlaid grid)
  • Templates and manual lettering instruments
  • Dry transfer systems
  • Numerically controlled lettering and draughting (CAD) systems
• Legibility rules: Minimum character spacing of twice the line width; may be reduced to one line width for specific character pairs for visual effect (examples: LA, TV, Tr).
• Dimensions and nominal sizes: Letter height (h) defines nominal size. Standard nominal sizes: 1.8, 2.5, 3.5, 5, 7, 10, 14, 20 mm. Line widths and sizing rules reference ISO 128-20.
• Central line and layout: Central (imaginary) line is the datum for character construction and tooling; nominal size and spacing determine central line location.
• Lettering angle: Vertical (upright) or sloped to 75° from horizontal (right inclination).
• Lettering types: Defined types A, B and CAD-oriented CA/CB (vertical and sloped variants) with dimensional tables for x-height, tails, stems, spacing, line width.
• Additional rules: Suitability for common copying processes (diazo, microfilm, fax) and recommendation to interrupt underlining/overlining where letters have tails.

Applications and who uses this standard

EN ISO 3098-1 is essential for professionals involved in:

• Technical drafters and mechanical designers preparing engineering drawings
• CAD users and automation engineers implementing numerically controlled lettering
• Document control and quality assurance teams ensuring drawing consistency
• Technical illustrators, product documentation teams, and manufacturing engineers who rely on legible, standardized text on drawings and instruction sheets

Practical uses include setting up default CAD text styles, specifying drawing text sizes for manufacturing drawings, and ensuring legibility across copying and reproduction processes.

Related standards

• ISO 3098 series (other parts):
  • Part 2: Latin alphabet, numerals and marks
  • Part 3: Greek alphabet
  • Part 4: Diacritical and particular marks for Latin alphabet
  • Part 5: CAD lettering of Latin alphabet, numerals and marks
  • Part 6: Cyrillic alphabet
• ISO 128-20: Technical drawings - General principles of presentation - Basic conventions for lines

Keywords: technical product documentation, ISO 3098-1, lettering standard, CAD lettering, drawing text, lettering dimensions, line width, nominal size, technical drawings, drafting standards.
