Safety requirements for cableway installations designed to carry persons - Ropes

This document specifies the safety requirements applicable to:
-   Selection criteria for ropes and their end fixings
-   Safety factors (excluding brake ropes)
-   Discard criteria
-   Storage, handling, transportation and installation (including tensioning, connecting and/or splicing)
-   Long splicing of 6 strand haulage, carrying-hauling rope and carrying-hauling rope (for ski-tow)
-   End fixings
-   Maintenance
and the minimum requirements applicable to:
-   MRT, visual and radiographic equipment and procedures for the examination of steel wire ropes.
This document is not applicable to cableway installations for the transportation of goods nor to lifts.
This document includes requirements relating to the prevention of accidents and the protection of workers irrespective of the application of national regulations.
National regulations of a building or federal/state nature or which serve to protect particular groups of people remain unaffected.

Sicherheitsanforderungen an Seilbahnen für die Personenbeförderung - Seile

Dieses Dokument legt die Sicherheitsanforderungen fest, die für Folgendes gelten:
-   Auswahlkriterien für Seile und ihre Seilendbefestigungen;
-   Sicherheitsfaktoren (mit Ausnahme von Bremsseilen);
-   Ablegekriterien;
-   Lagerung, Handhabung, Transport und Auflegen (einschließlich Spannen, Verbinden und/oder Spleißen);
-   Langspleißen von 6 litzigen Zugseilen, Förderseilen und Förderseilen von Schleppliften;
-   Seilendbefestigungen;
-   Instandhaltung.
Ferner legt es die Mindestanforderungen für Folgendes fest:
-   magnetische Seilprüfung (MRT) sowie Ausrüstung und Verfahren für die Sichtprüfung und die Durch¬strahlungsprüfung zur Untersuchung von Stahldrahtseilen.
Dieses Dokument gilt weder für Seilbahnen für den Güterverkehr noch für Aufzüge.
Dieses Dokument enthält Anforderungen bezüglich der Verhinderung von Arbeitsunfällen und des Arbeitsschutzes, unge¬achtet der Anwendung nationaler Bestimmungen.
Nationale Vorschriften mit bau- oder ordnungsrechtlichem Charakter oder jene, die dem Schutz besonderer Personengruppen dienen, bleiben unberührt.

Prescriptions de sécurité des installations à câbles transportant des personnes - Câbles

Le présent document définit les exigences de sécurité applicables :
-   aux critères de sélection des câbles et de leurs attaches d’extrémité ;
-   aux coefficients de sécurité (à l’exclusion des câbles freins) ;
-   aux critères de dépose ;
-   au stockage, à la manutention, au transport et à la mise en place (y compris la mise en tension, le raccordement et/ou l’épissurage) ;
-   à l’épissurage des câbles tracteurs, des câbles porteurs-tracteurs et des câbles de remorquage à 6 torons ;
-   aux attaches d’extrémité ;
-   à la maintenance ;
et les exigences minimales applicables :
-   aux dispositifs de contrôle magnétique de câble (MRT), visuel et radiographique et aux modes opératoires pour l’examen des câbles en acier.
Le présent document ne s’applique ni aux installations de transport à câbles destinées aux marchandises, ni aux ascenseurs.
Le présent document comporte des exigences concernant la prévention des accidents et la protection des travailleurs, indépendamment de l’application des réglementations nationales.
Les réglementations nationales, fédérales, d’état ou encore régionales, dans le domaine de la construction ou destinées à protéger des groupes de personnes particuliers restent pleinement en vigueur.

Varnostne zahteve za žičniške naprave za prevoz oseb - Vrvi

Ta evropski standard določa varnostne zahteve, ki se uporabljajo za:
– merila za izbiro vrvi in pritrditev njihovih koncev;
– varnostne faktorje (razen za zavorne vrvi);
– izločitvena merila;
– shranjevanje, ravnanje, prevoz in namestitev (vključno z napetostjo, priklopom in/ali spoji);
– dolgi spoj 6-pramenske vlečne transportne vrvi in transportne vrvi (za vlečnice);
– dele za pritrditev koncev vrvi;
– vzdrževanje;
in minimalne zahteve, ki se uporabljajo za:
– magnetno induktivno metodo (MRT) in radiografsko opremo ter postopke za pregled jeklenih vrvi.
Ta standard se ne uporablja za žičniške naprave za prevoz blaga ali dvigala.
Ta standard vključuje zahteve v zvezi s preprečevanjem nesreč in zaščito delavcev ne glede na uporabo nacionalnih predpisov.
Standard ne vpliva na nacionalne predpise, ki urejajo gradbene predpise, predpise na zvezni/državni ravni ali predpise, ki služijo zaščiti določene skupine ljudi.

General Information

Status
Published
Publication Date
14-May-2019
Current Stage
6060 - Definitive text made available (DAV) - Publishing
Due Date
15-May-2019
Completion Date
15-May-2019

RELATIONS

Buy Standard

Standard
EN 12927:2019
English language
65 pages
sale 10% off
Preview
sale 10% off
Preview

e-Library read for
1 day

Standards Content (sample)

SLOVENSKI STANDARD
SIST EN 12927:2019
01-julij-2019
Nadomešča:
SIST EN 12927-1:2005
SIST EN 12927-2:2005
SIST EN 12927-3:2005
SIST EN 12927-4:2005
SIST EN 12927-5:2005
SIST EN 12927-6:2005
SIST EN 12927-7:2005
SIST EN 12927-8:2005
Varnostne zahteve za žičniške naprave za prevoz oseb - Vrvi
Safety requirements for cableway installations designed to carry persons - Ropes
Sicherheitsanforderungen an Seilbahnen für den Personenverkehr - Seile

Prescriptions de sécurité des installations à câbles transportant des personnes - Câbles

Ta slovenski standard je istoveten z: EN 12927:2019
ICS:
45.100 Oprema za žičnice Cableway equipment
SIST EN 12927:2019 en,fr,de

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------
SIST EN 12927:2019
---------------------- Page: 2 ----------------------
SIST EN 12927:2019
EN 12927
EUROPEAN STANDARD
NORME EUROPÉENNE
May 2019
EUROPÄISCHE NORM
ICS 45.100 Supersedes EN 12927-1:2004, EN 12927-2:2004, EN
12927-3:2004, EN 12927-4:2004, EN 12927-5:2004,
EN 12927-6:2004, EN 12927-7:2004, EN 12927-
8:2004
English Version
Safety requirements for cableway installations designed to
carry persons - Ropes

Prescriptions de sécurité des installations à câbles Sicherheitsanforderungen an Seilbahnen für die

transportant des personnes - Câbles Personenbeförderung - Seile
This European Standard was approved by CEN on 11 February 2019.

CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this

European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references

concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN

member.

This European Standard exists in three official versions (English, French, German). A version in any other language made by

translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management

Centre has the same status as the official versions.

CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,

Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania,

Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,

Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels

© 2019 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN 12927:2019 E

worldwide for CEN national Members.
---------------------- Page: 3 ----------------------
SIST EN 12927:2019
EN 12927:2019 (E)
Contents Page

European foreword ....................................................................................................................................................... 5

1 Scope .................................................................................................................................................................... 7

2 Normative references .................................................................................................................................... 7

3 Terms and definitions ................................................................................................................................... 9

4 Symbols and abbreviated terms ............................................................................................................. 12

5 Requirements ................................................................................................................................................ 13

6 Safety principles ........................................................................................................................................... 13

6.1 General ............................................................................................................................................................. 13

6.2 Hazard scenarios .......................................................................................................................................... 13

6.3 Safety measures ............................................................................................................................................ 15

7 Selection criteria for ropes and their end fixing ............................................................................... 16

7.1 Ropes ................................................................................................................................................................ 16

7.2 Fibre ropes...................................................................................................................................................... 18

7.2.1 General ............................................................................................................................................................. 18

7.2.2 Fibre ropes for carrying-hauling ropes (for ski-tows) ................................................................... 18

7.2.3 Fibre ropes for towing cord ...................................................................................................................... 18

7.3 Rope re-use ..................................................................................................................................................... 18

7.4 End fixings (excluding long splice) ........................................................................................................ 19

8 Safety factors.................................................................................................................................................. 19

8.1 General ............................................................................................................................................................. 19

8.2 Tensile safety ................................................................................................................................................. 19

8.3 Diameter ratio ............................................................................................................................................... 21

8.4 Transverse force ratio ................................................................................................................................ 22

8.4.1 Roller transverse force ratio .................................................................................................................... 22

8.4.2 Carrier transverse force ratio.................................................................................................................. 22

9 Discard criteria ............................................................................................................................................. 23

9.1 General ............................................................................................................................................................. 23

9.2 Main body of the rope and long splice .................................................................................................. 23

9.2.1 Ropes examined by magnetic rope testing (MRT) ........................................................................... 23

9.2.2 Ropes examined by visual inspection (VI) .......................................................................................... 23

9.3 Tension ropes ................................................................................................................................................ 24

9.4 Local deterioration ...................................................................................................................................... 24

9.4.1 General ............................................................................................................................................................. 24

9.4.2 Main body of the rope ................................................................................................................................. 24

9.4.3 Splice ................................................................................................................................................................. 25

9.5 Rope at end fixing ......................................................................................................................................... 25

9.5.1 Filled socket ................................................................................................................................................... 25

9.5.2 Other end fixing ............................................................................................................................................ 26

10 Storage, handling, transportation and installation (including tensioning, connecting and/

or splicing) ...................................................................................................................................................... 26

10.1 General ............................................................................................................................................................. 26

10.2 Storage ............................................................................................................................................................. 26

10.3 Handling and transportation ................................................................................................................... 26

---------------------- Page: 4 ----------------------
SIST EN 12927:2019
EN 12927:2019 (E)

10.4 Installation (including tensioning, connecting and/or splicing) ................................................ 27

10.4.1 General ............................................................................................................................................................. 27

10.4.2 Measurements, adjustments and records ............................................................................................ 28

11 Splicing of 6 stranded steel wire ropes ................................................................................................. 28

11.1 General ............................................................................................................................................................. 28

11.2 Splice geometry ............................................................................................................................................. 28

11.2.1 General ............................................................................................................................................................. 28

11.2.2 Splice dimensions ......................................................................................................................................... 29

11.2.3 Documentation .............................................................................................................................................. 29

12 End fixing ......................................................................................................................................................... 29

12.1 General ............................................................................................................................................................. 29

12.2 Design................................................................................................................................................................ 29

12.3 Execution and conformity .......................................................................................................................... 30

12.4 Filled socket .................................................................................................................................................... 30

12.4.1 General ............................................................................................................................................................. 30

12.4.2 Design................................................................................................................................................................ 31

12.4.3 Manufacture .................................................................................................................................................... 31

12.4.4 Socketing execution ..................................................................................................................................... 31

12.5 Clamp socket................................................................................................................................................... 32

12.5.1 General ............................................................................................................................................................. 32

12.5.2 Design................................................................................................................................................................ 33

12.5.3 Manufacture .................................................................................................................................................... 33

12.5.4 Execution ......................................................................................................................................................... 33

12.6 Drum (Fixing drum and anchor drum) ................................................................................................. 34

12.7 Bolted clamp ................................................................................................................................................... 34

12.7.1 Design................................................................................................................................................................ 34

12.7.2 Manufacture .................................................................................................................................................... 35

12.7.3 Execution and maintenance ...................................................................................................................... 35

12.8 Wedge socket ................................................................................................................................................. 36

12.8.1 Symmetrical .................................................................................................................................................... 36

12.8.2 Asymmetrical ................................................................................................................................................. 36

12.9 Spliced eye ....................................................................................................................................................... 36

12.10 Gripped eye ..................................................................................................................................................... 36

12.11 Ferrule secured eye ..................................................................................................................................... 36

12.12 Lever winch ..................................................................................................................................................... 36

13 Maintenance ................................................................................................................................................... 36

13.1 General ............................................................................................................................................................. 36

13.2 Servicing ........................................................................................................................................................... 44

13.2.1 General ............................................................................................................................................................. 44

13.2.2 Rope cleaning and lubrication ................................................................................................................. 44

13.2.3 Relocation of carrying ropes, fixed grips on monocable aerial ropeways and signal

ropes .................................................................................................................................................................. 44

13.2.4 Relocation of signal ropes ......................................................................................................................... 45

13.2.5 End fixing ......................................................................................................................................................... 45

13.2.6 Shortening of rope loops ............................................................................................................................ 45

13.2.7 End fixing of towing cords ......................................................................................................................... 45

13.3 Inspection ........................................................................................................................................................ 45

13.3.1 General ............................................................................................................................................................. 45

13.3.2 Personnel requirements ............................................................................................................................ 46

13.3.3 Initial inspection ........................................................................................................................................... 46

13.3.4 Periodical inspection ................................................................................................................................... 46

13.3.5 Extraordinary inspection ........................................................................................................................... 46

---------------------- Page: 5 ----------------------
SIST EN 12927:2019
EN 12927:2019 (E)

13.3.6 Visual inspection (VI) ................................................................................................................................. 46

13.3.7 Inspection types ............................................................................................................................................ 47

13.3.8 Optical inspection devices (OID) ............................................................................................................ 47

13.3.9 Measurements ............................................................................................................................................... 47

13.3.10 Magnetic rope testing ................................................................................................................................ 49

13.3.11 Radiographic testing ................................................................................................................................. 49

13.3.12 Report ............................................................................................................................................................. 49

13.3.13 Rope indicators ........................................................................................................................................... 49

13.4 Repair ............................................................................................................................................................... 50

13.4.1 General ............................................................................................................................................................. 50

13.4.2 Stranded rope ................................................................................................................................................ 50

13.4.3 Locked coil rope ............................................................................................................................................ 50

13.4.4 Anchor drum repair .................................................................................................................................... 51

14 Magnetic rope testing (MRT) ................................................................................................................... 51

14.1 General ............................................................................................................................................................. 51

14.2 Instrumentation ........................................................................................................................................... 51

14.2.1 Function and operational principles of magnetic flux leakage instruments.......................... 51

14.2.2 Test head ......................................................................................................................................................... 52

14.2.3 Visual display unit and permanent recording instrument ........................................................... 52

14.3 Test procedure .............................................................................................................................................. 52

14.3.1 Personnel ........................................................................................................................................................ 52

14.3.2 Setting up ........................................................................................................................................................ 52

14.3.3 Test execution ............................................................................................................................................... 53

14.3.4 Interpretation of results ............................................................................................................................ 53

14.3.5 Instrument verification .............................................................................................................................. 54

15 Fire protection and fire fighting ............................................................................................................. 55

Annex A (informative) Guidelines for executing visual inspection type “A”.......................................... 56

Annex B (informative) Magnetic flux density .................................................................................................... 57

Annex C (informative) Magnetic rope testing - Personnel qualifications levels .................................. 58

Annex D (informative) Bolted clamp - Calculation of slipping force ........................................................ 60

Annex E (informative) Determination of intervals related to visual inspections ................................ 61

E.1 General ............................................................................................................................................................. 61

E.2 Operational conditions .............................................................................................................................. 61

E.2.1 Bendings of stranded ropes ...................................................................................................................... 61

E.2.2 Number of passages of rollers per year for locked coil ropes...................................................... 61

E.3 Operating personnel ................................................................................................................................... 62

E.4 Carriers related conditions ...................................................................................................................... 62

E.5 Cableway configuration ............................................................................................................................. 63

E.6 Environmental conditions ........................................................................................................................ 63

E.7 Final evaluation and result ....................................................................................................................... 63

Annex ZA (informative) Relationship between this European Standard and the Essential

Requirements of Regulation (EU) 2016/424 on “Cableway installations” aimed to be

covered............................................................................................................................................................. 65

---------------------- Page: 6 ----------------------
SIST EN 12927:2019
EN 12927:2019 (E)
European foreword

This document (EN 12927:2019) has been prepared by Technical Committee CEN/TC 242 “Safety

requirements for passenger transportation by rope”, the secretariat of which is held by AFNOR.

This European Standard shall be given the status of a national standard, either by publication of an identical

text or by endorsement, at the latest by November 2019, and conflicting national standards shall be withdrawn

at the latest by November 2019.

Attention is drawn to the possibility that some of the elements of this document may be the subject of patent

rights. CEN shall not be held responsible for identifying any or all such patent rights.

This document has been prepared under a mandate given to CEN by the European Commission and the

European Free Trade Association, and supports essential requirements of Regulation (EU) 2016/424.

For relationship with Regulation (EU) 2016/424, see informative Annex ZA, which is an integral part of this

document.
This document replaces:

— EN 12927-1:2004: Safety requirements for cableway installations designed to carry persons - Ropes - Part

1: Selection criteria for ropes and their end fixings”

— EN 12927-2:2004: Safety requirements for cableway installations designed to carry persons - Ropes – Part

2: Safety factors

— EN 12927-3:2004: Safety requirements for cableway installations designed to carry persons - Ropes – Part

3: Long splicing of 6 strand hauling, carrying hauling and towing ropes

— EN 12927-4:2004: Safety requirements for cableway installations designed to carry persons - Ropes – Part

4: End fixings

— EN 12927-5:2004: Safety requirements for cableway installations designed to carry persons - Ropes – Part

5: Storage, transportation, installation and tensioning

— EN 12927-6:2004: Safety requirements for cableway installations designed to carry persons - Ropes – Part

6: Discard criteria

— EN 12927-7:2004: Safety requirements for cableway installations designed to carry persons - Ropes – Part

7: Inspection, repair and maintenance

— EN 12927-8:2004: Safety requirements for cableway installations designed to carry persons - Ropes – Part

8: Magnetic rope testing (MRT)

During the systematic review regarding the EN 12927 Part 1 to Part 8, it was decided to merge the 8 parts into

one single document.

In comparison to EN 12927, parts 1:2004 to 8:2004, the following major changes have been applied:

— the former parts 1 to 8 have been merged to a single document in order to simplify orientation in working

with the standard. Following this principle, the former paragraph-references had to be changed in total.

---------------------- Page: 7 ----------------------
SIST EN 12927:2019
EN 12927:2019 (E)

Therefore, especially general chapters like “normative references”, “terms and definitions”, “safety

principles” and so on, now have been compacted for a better overview;

— ambiguous or unclear details of the former versions have been generally rewritten and improved;

— technical developments since the last versions have been adopted to the actual state of the art, e.g.

inclusion of optical inspection devices;

— requirements and descriptions in the scope of inspection methods have been improved and extended to

details, especially for visual inspection;

— requirements and descriptions for storage, handling and transportation have been improved and extended

to details.

According to the CEN-CENELEC Internal Regulations, the national standards organisations of the following

countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech

Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece,

Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,

Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United Kingdom.

---------------------- Page: 8 ----------------------
SIST EN 12927:2019
EN 12927:2019 (E)
1 Scope
This document specifies the safety requirements applicable to:
— Selection criteria for ropes and their end fixings
— Safety factors (excluding brake ropes)
— Discard criteria

— Storage, handling, transportation and installation (including tensioning, connecting and/or splicing)

— Long splicing of 6 strand haulage, carrying-hauling rope and carrying-hauling rope (for ski-tow)

— End fixings
— Maintenance
and the mi
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
