EN 10224:2002

Non-alloy steel tubes and fittings for the conveyance of aqueous liquids including water for human consumption - Technical delivery conditions

1.1 This European standard specifies requirements for the products listed below for the conveyance of aqueous liquids, including water for human consumption: - seamless and welded non-alloy steel tubes; - end preparation of tube ends for butt welding; - fittings fabricated from the tube; - fittings fabricated from plate or strip. 1.2 This European standard covers a range of tube outside diameters from 26,9 mm to 2 743 mm.

Rohre und Fittings aus unlegierten Stählen für den Transport wässriger Flüssigkeiten einschließlich Trinkwasser - Technische Lieferbedingungen

1.1 Diese Europäische Norm legt die Anforderungen an die nachstehend aufgeführten Erzeugnisse für den Transport wässriger Flüssigkeiten einschließlich Trinkwasser fest:
- nahtlose und geschweißte Rohre aus unlegiertem Stahl;
- Rohrendenvorbereitung zum Stumpfschweißen;
- Fittings, gefertigt aus Rohren;
- Fittings, gefertigt aus Blech oder Band.
ANMERKUNG: Diese Europäische Norm enthält informative Anhänge, in denen Hinweise auf die dem jeweiligen Herstell-verfahren entsprechenden Abmessungsbereiche der Rohre, auf die Beziehungen zwischen Nenn-außen-durchmesser (D) und Nennweite (DN), über Verbindungsarten - soweit sie nicht durch Stumpfschweißen erzeugt werden - und zum Korrosionsschutz gegeben werden.
1.2 Diese Europäische Norm gilt für Rohre mit einem Außendurchmesser von 26,9 mm bis 2743 mm.

Tubes et raccords en acier non allié pour le transport de liquides aqueux, incluant l'eau destinée à la consommation - Conditions techniques de livraison

1.1 La présente Norme européenne spécifie les prescriptions pour les produits listés ci-dessous, utilisés pour le transport de liquides aqueux, y compris l'eau destinée à la consommation humaine :
- tubes soudés et sans soudure en acier non allié ;
- préparation des extrémités de tubes pour la soudure par raboutage ;
- raccords réalisés à partir du tube ;
- raccords réalisés à partir de tôle ou bande.
NOTE   La présente Norme européenne comporte des annexes informatives qui donnent des indications sur les dimensions de tube relatives à chaque procédé de fabrication couvert, la relation entre le diamètre extérieur nominal (D) et le diamètre nominal (DN) pour les assemblages autres que la soudure de raboutage, et sur la protection anticorrosion.
1.2 La présente Norme européenne couvre une plage de diamètre extérieur de tube compris entre 26,9 mm et 2 743 mm.

Nelegirane jeklene cevi in fitingi za transport vodnih tekočin vključno s pitno vodo - Tehnični dobavni pogoji

General Information

• Status: Published
• Publication Date: 03-Dec-2002
• Withdrawal Date: 29-Jun-2003
• ICS: 23.040.10 - Iron and steel pipes
• ICS: 23.040.40 - Metal fittings
• Technical Committee: ECISS/TC 110 - Steel tubes, and iron and steel fittings
• Drafting Committee: ECISS/TC 29/SC 5 - tube for the conveyance of aqueous liquids
• Current Stage: 9093 - Decision to confirm - Review Enquiry
• Start Date: 05-Jun-2025
• Completion Date: 23-Sep-2025
• Directive: 305/2011 - Regulation (eu) No 305/2011 of the European Parliament and of the Council of 9 march 2011 laying down harmonised conditions for the marketing of construction products and repealing council directive 89/106/eec
• Directive: 89/106/EEC - Construction products
• Mandate: M/131 - Mandate to CEN/CENELEC concerning the execution of standardization work for harmonized standards on pipes, tanks and ancillaries, not in contact with water intended for human consumption
• Mandate: M/BC/CEN/89/10 - ECISS - 3rd programme
• Ref Project: SIST EN 10224:2003 - Non-alloy steel tubes and fittings for the conveyance of aqueous liquids including water for human consumption - Technical delivery conditions

Relations

• Amended By: EN 10224:2002/A1:2005 - Non-alloy steel tubes and fittings for the conveyance of water and other aqueous liquids - Technical delivery conditions
• Effective Date: 22-Dec-2008

Overview

EN 10224:2002 - published by CEN - specifies the technical delivery conditions for non‑alloy steel tubes and fittings intended for the conveyance of aqueous liquids, including water for human consumption (potable water). The standard covers seamless and welded non‑alloy steel tubes, end preparation for butt welding, fittings fabricated from tube, and fittings fabricated from plate or strip. It applies to tube outside diameters from 26.9 mm to 2 743 mm and includes informative annexes on jointing, coatings/linings and size relationships.

Key topics and requirements

The standard concentrates on manufacturing, quality and documentation requirements needed for safe, durable piping used with aqueous media:

• Product scope: seamless and welded non‑alloy steel tubes; fittings from tube, plate or strip; butt‑weld end preparation.
• Size range: outside diameters from 26.9 mm to 2 743 mm.
• Manufacturing controls: steel and deoxidation processes, production methods for tubes and fittings.
• Chemical and mechanical requirements: specified limits for composition and mechanical properties (as applicable for non‑alloy steels).
• Dimensions and tolerances: dimensional requirements, tolerances for tubes and fittings, and relationship to nominal sizes (DN).
• End preparation: requirements for tube and fitting ends prepared for butt welding.
• Inspection & testing: mandatory inspection documents, sampling frequencies, mechanical tests, and non‑destructive testing (NDT) methods for seams and welds.
• Soundness and leak tightness: tests to verify hydraulic integrity.
• Marking and documentation: inspection certificates and marking requirements for traceability.
• Coatings and linings: guidance on commonly used protective systems and references to relevant coating/lining standards (informative).
• Jointing guidance: annexed guidance on other jointing methods (sleeve, flange, slip‑on, push‑fit) commonly used in aqueous piping systems.

Applications and practical value

EN 10224:2002 is intended for organizations that design, manufacture, specify or approve steel piping systems conveying aqueous liquids, including potable water. Typical applications include:

• Municipal water mains and distribution networks
• Industrial water systems, process water lines and cooling circuits
• Treatment plant piping and large‑diameter conveyance systems
• Fabrication of welded or seamless steel fittings used in potable and non‑potable water installations

Using EN 10224 helps ensure product uniformity, traceability, and compatibility with European procurement and construction practices. It also provides a baseline for specifying coatings/linings appropriate for corrosion protection in water service.

Who should use this standard

• Pipe and fitting manufacturers
• Specification writers and procurement engineers
• Water utility engineers and infrastructure owners
• Welding and NDT specialists
• Compliance and quality managers in construction and manufacturing

Related standards

EN 10224 references and aligns with other product, testing and NDT standards (for example EN 10020 series, EN 10246 series, EN 10204 inspection documents). Refer to the standard’s normative references and informative annexes for specific cross‑references when writing specifications or carrying out conformity assessment.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Non-alloy steel tubes and fittings for the conveyance of aqueous liquids including water for human consumption - Technical delivery conditionsTubes et raccords en acier non allié pour le transport de liquides aqueux, incluant l'eau destinée a la consommation - Conditions techniques de livraisonRohre und Fittings aus unlegierten Stählen für den Transport wässriger Flüssigkeiten einschließlich Trinkwasser - Technische LieferbedingungenTa slovenski standard je istoveten z:EN 10224:2002SIST EN 10224:2003en23.040.4023.040.10ICS:SLOVENSKI
STANDARDSIST EN 10224:200301-april-2003

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 10224December 2002ICS 23.040.10; 23.040.40English versionNon-alloy steel tubes and fittings for the conveyance of aqueousliquids including water for human consumption - Technicaldelivery conditionsTubes et raccords en acier non allié pour le transport deliquides aqueux, incluant l'eau destinée à la consommation- Conditions techniques de livraisonRohre und Fittings aus unlegierten Stählen für denTransport wässriger Flüssigkeiten einschließlichTrinkwasser - Technische LieferbedingungenThis European Standard was approved by CEN on 19 August 2002.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Management Centre has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece,Iceland, Ireland, Italy, Luxembourg, Malta, Netherlands, Norway, Portugal, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2002 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 10224:2002 E

Size range of tube manufacturing processes.39Annex B (informative)
Relationship between outside diameter and nominal size (DN).40Annex C (informative)
Jointing.41C.1General.41C.2Sleeve joints for welding.41C.3Flange joints.42C.4Slip-on type couplings.42C.5Push fit and gasket type couplings.47C.6Special joints.48Annex D (informative)
Coatings and linings.49D.1General.49D.2Coatings.49D.3Linings.49D.4Relevant European Standards, published or under development.50Annex ZA (informative) Clauses of this European Standard addressing the provisions ofthe EU Construction Products Directive.51Bibliography.58

The employer may be either the tube orfitting manufacturer or a third party organization providing non-destructive testing (NDT) services4 Classification and designation4.1 ClassificationAll steels covered by this European Standard are classified as non-alloy steels in accordance withEN 10020.4.2 Designation4.2.1For products covered by this European Standard the steel designation consists of the numberof this European Standard (EN 10224) and either the steel name in accordance with EN 10027-1 andCR 10260 or the steel number in accordance with EN 10027-2 (see Table 1).
1)In preparation; until this document is published as a European Standard the corresponding national standardshould be agreed at the time of enquiry and order.

2 1 N/mm2 = 1 MPa
810L355500 to 65035534521194T
8a Re shall be ReH, or if a yield phenomenon is not present, Rp0,2 or Rt 0,5. See 10.2.1.b l – longitudinal
t – transversec Applicable only to tubes of diameter less than or equal to 150 mm and thicknesses less than or equal to 10 mm.d d = D-2T

Outside diameter and thicknessThe outside diameters and thicknesses of tubes appropriate to this European Standard are givenin Table 4. With the exception of tubes of 2 642 mm and 2 743 mm diameter, they are inaccordance with ENV 10220.NOTEOther diameters and/or thicknesses may be available by agreement with the manufacturer.

1 % of the diameter with a minimum of 0,5 mm.7.7.2.2 Electric welded and butt welded tubeThe tolerance on outside diameter shall not exceed the values given in Table 6.

Dimensions F, G, E and H should be rounded to the nearest 10 mm.NOTE 2
The effective length of the barrel of tees with sleeve joint for welding equals 2 F.NOTE 3
Any barrel may have a branch of equal or smaller diameter attached to it.NOTE 4
Reinforcement may be required to prevent overstressing.D1GDFFFigure 6 — Plain end tee for butt-welded joint
...
