EN ISO 28927-9:2009

Hand-held portable power tools - Test methods for evaluation of vibration emission - Part 9: Scaling hammers and needle scalers (ISO 28927-9:2009)

ISO 28927-9:2009 specifies a laboratory method for measuring hand-transmitted vibration emission at the handles of hand-held, power-driven scaling hammers and needle scalers. It is a type-test procedure for establishing the magnitude of vibration in the gripping areas of a machine run under specified test conditions. It is intended that the results be used to compare different models of the same type of machine.
ISO 28927-9:2009 is applicable to engraving pens, scabblers, scaling hammers and needle scalers, driven pneumatically or by other means, intended for paint, rust or scale removal with reciprocating work tools or needles and for all kinds of materials.

Handgehaltene motorbetriebene Maschinen - Messverfahren zur Ermittlung der Schwingungsemission - Teil 9: Abklopfer und Nadelentroster (ISO 28927-9:2009)

Dieser Teil von ISO 28927 legt ein Laborverfahren zur Messung der Hand-Arm-Schwingungen fest, die an den Handgriffen von handgehaltenen motorbetriebenen Abklopfern und Nadelentrostern hervorgerufen werden. Es handelt sich um ein Messverfahren zur Ermittlung der Schwingungskennwerte (Schwingungs-emissionswerte) an den Greifstellen der Maschine, die unter bestimmten Messbedingungen betrieben wird. Der Zweck besteht darin, die Kennwerte zum Vergleich verschiedener Modelle derselben Maschinenart zu verwenden.
Dieser Teil von ISO 28927 gilt für Gravierstifte, Abklopfer, Meißelabklopfer und Nadelentroster (siehe Abschnitt 5) zum Entfernen von Farbe, Rost und Ablagerungen mit hin- und hergehenden Werkzeugen oder Nadeln, die pneumatisch oder auf andere Weise angetrieben werden und zum Einsatz auf allen Arten von Werkstoff vorgesehen sind.
ANMERKUNG   Um eine Verwechslung zu vermeiden, wird in dieser Norm zwischen der (motorbetriebenen) Maschine und dem Werkzeug oder Einsatzwerkzeug strikt unter¬schieden.

Machines à moteur portatives - Méthodes d'essai pour l'évaluation de l'émission de vibrations - Partie 9: Marteaux dérouilleurs et marteaux à aiguilles (ISO 28927-9:2009)

L'ISO 28927-9:2009 spécifie une méthode de mesure en laboratoire des émissions de vibrations transmises aux mains s'exerçant au niveau des poignées des marteaux dérouilleurs et des marteaux à aiguilles tenus à la main. Il s'agit d'une méthode d'essai de type définissant l'amplitude des vibrations aux zones de préhension des machines fonctionnant dans des conditions d'essai spécifiques. Il est prévu d'utiliser les résultats pour comparer différents modèles du même type de machine.
L'ISO 28927-9:2009 s'applique aux outils de gravure, aux machines à smillage, aux marteaux dérouilleurs et aux marteaux à aiguilles, pneumatiques ou entraînés par un autre dispositif, destinés à éliminer la peinture, la rouille et la calamine au moyen d'outils de travail ou d'aiguilles alternatifs sur tous les types de matériaux.

Ročna prenosna električna orodja - Preskusne metode za vrednotenje oddajanja vibracij - 9. del: Kladiva in iglasti odstranjevalniki kamna ali betona (ISO 28927-9:2009)

Ta del ISO 28927 določa laboratorijsko metodo merjenja emisij ročnega oddajanja vibracij na ročajih ročnih električnih kladiv in iglastih odstranjevalnikov kamna ali betona. To je postopek tipskega preskusa za vzpostavljanje razsežnosti vibracij v območju držanja stroja, ko deluje pod določenimi preskusnimi pogoji. Namenjeno je temu, da se rezultati uporabijo za primerjavo različnih modelov strojev istega tipa. Ta del ISO 28927 velja za gravurna peresa, peskalnike, kladiva za odstranjevanje kamna ali betona in igle za odstranjevanje kamna in betona (glej Klavzulo 5), pnevmatično ali kako drugače gnane.

General Information

• Status: Published
• Publication Date: 14-Dec-2009
• Withdrawal Date: 29-Jun-2010
• ICS: 13.160 - Vibration and shock with respect to human beings
• ICS: 17.160 - Vibrations, shock and vibration measurements
• ICS: 25.140.01 - Hand-held tools in general
• ICS: 25.140.10 - Pneumatic tools
• Technical Committee: CEN/TC 231 - Mechanical vibration and shock
• Drafting Committee: CEN/TC 231/WG 2 - Hand-arm vibration
• Current Stage: 6060 - Definitive text made available (DAV) - Publishing
• Start Date: 15-Dec-2009
• Completion Date: 15-Dec-2009
• Directive: 2006/42/EC - Directive 2006/42/EC of the European Parliament and of the Council of 17 May 2006 on machinery, and amending Directive 95/16/EC (recast)
• Directive: 98/37/EC - Machinery
• Mandate: M/079 - Mandate to CEN and CENELEC for standardization in the field of machines
• Mandate: M/396 - Mandate to CEN and Cenelec for standardisation in the field of machinery
• Ref Project: SIST EN ISO 28927-9:2010 - Hand-held portable power tools - Test methods for evaluation of vibration emission - Part 9: Scaling hammers and needle scalers (ISO 28927-9:2009)

Relations

• Replaces: EN ISO 8662-14:1996 - Hand-held portable power tools - Measurement of vibrations at the handle - Part 14: Stone-working tools and needle scalers (ISO 8662-14:1996)
• Effective Date: 08-Jun-2022

Overview

EN ISO 28927-9:2009 - Hand-held portable power tools - Test methods for evaluation of vibration emission - Part 9: Scaling hammers and needle scalers (ISO 28927-9:2009) specifies a laboratory, type-test method for measuring hand-transmitted vibration emission at the handles of scaling hammers, needle scalers, engraving pens and scabblers. The standard defines how to establish the magnitude of vibration at gripping areas under specified test conditions so results can be used to compare different models and support machine conformity assessments.

Keywords: ISO 28927-9:2009, vibration emission, hand-held power tools, scaling hammers, needle scalers, hand-transmitted vibration, test methods.

Key Topics

• Scope and applicability: Applies to pneumatic or other driven tools intended for paint, rust or scale removal with reciprocating work tools or needles, and to engraving pens and scabblers.
• Measurement strategy: Laboratory type-test procedure to characterise vibration at the user’s hand positions; includes measurement in multiple axes and at both hand positions where relevant.
• Instrumentation requirements: Specifies transducers, mounting and fastening methods, frequency-weighting filters, integration time, calibration and auxiliary equipment needed for valid measurements.
• Test conditions and setup:
  • Defined operating conditions for pneumatic, hydraulic and electrical machines.
  • Specified test fixtures, workpiece (e.g., mild steel plate or concrete block) and feed-force guidance.
  • Operator roles and repeatability considerations.
• Data reporting and verification: Procedures for calculating reported vibration values, combining directional components, uncertainty determination and preparing a measurement report suitable for declaration and verification.
• Regulatory linkage: Informative annexes relate the standard to EU Machinery Directives (e.g., 2006/42/EC), providing a presumption of conformity with certain essential requirements within the standard’s scope.

Applications

Who uses EN ISO 28927-9:2009 and why:

• Tool manufacturers - to verify and declare vibration emission values during product development and type-testing, enabling model comparison and design optimization for reduced hand-transmitted vibration.
• Test laboratories - to perform standardized, repeatable laboratory measurements for independent evaluation and certification.
• Occupational health & safety professionals - to assess comparative vibration risks and inform tool-selection, exposure assessment and control measures.
• Regulatory and compliance teams - to support conformity assessment with relevant EU directives and national standards.

Practical benefits: comparable vibration emission data across models, improved user safety through better-informed tool selection, and consistent test methodology for procurement and certification.

Related Standards

EN ISO 28927 is a multi-part series covering vibration test methods for many hand-held power tools (e.g., Parts 1–11 covering grinders, drills, rammers, saws, percussive drills, stone hammers). Consult other parts of ISO 28927 for test methods specific to different tool families.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Handgehaltene motorbetriebene Maschinen - Messverfahren zur Ermittlung der Schwingungsemission - Teil 9: Abklopfer und Nadelentroster (ISO 28927-9:2009)Machines à moteur portatives - Méthodes d'essai pour l'évaluation de l'émission de vibrations - Partie 9: Marteaux dérouilleurs et marteaux à aiguilles (ISO 28927-9:2009)Hand-held portable power tools - Test methods for evaluation of vibration emission - Part 9: Scaling hammers and needle scalers (ISO 28927-9:2009)25.140.01Hand-held tools in general13.160Vpliv vibracij in udarcev na ljudiVibration and shock with respect to human beingsICS:Ta slovenski standard je istoveten z:EN ISO 28927-9:2009SIST EN ISO 28927-9:2010en,fr01-februar-2010SIST EN ISO 28927-9:2010SLOVENSKI
STANDARDSIST EN ISO 8662-14:20001DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN ISO 28927-9
December 2009 ICS 13.160; 25.140.10 Supersedes EN ISO 8662-14:1996English Version
Hand-held portable power tools - Test methods for evaluation of vibration emission - Part 9: Scaling hammers and needle scalers (ISO 28927-9:2009)
Machines à moteur portatives - Méthodes d'essai pour l'évaluation de l'émission de vibrations - Partie 9: Marteaux dérouilleurs et marteaux à aiguilles (ISO 28927-9:2009)
Handgehaltene motorbetriebene Maschinen - Messverfahren zur Ermittlung der Schwingungsemission - Teil 9: Abklopfer und Nadelentroster (ISO 28927-9:2009) This European Standard was approved by CEN on 14 December 2009.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2009 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN ISO 28927-9:2009: ESIST EN ISO 28927-9:2010

Relationship between this European Standard and the Essential Requirements of EU Directive 98/37/EC, amended by Directive 98/79/EC .4Annex ZB (informative)
Relationship between this
European
Standard and the Essential Requirements
of EU Directive 2006/42/EC .5 SIST EN ISO 28927-9:2010

Relationship between this European Standard and the Essential Requirements of EU Directive 98/37/EC, amended by Directive 98/79/EC This European Standard has been prepared under a mandate given to CEN by the European Commission and the European Free Trade Association to provide a means of conforming to Essential Requirements of the New Approach Directive 98/37/EC, Machinery, amended by Directive 98/79/EC. Once this standard is cited in the Official Journal of the European Union under that Directive and has been implemented as a national standard in at least one Member State, compliance with the normative clauses of this standard confers, within the limits of the scope of this standard, a presumption of conformity with the corresponding Essential Requirements of that Directive, except ER 1.7.4 d) and 2.2, and associated EFTA regulations. WARNING — Other requirements and other EU Directives may be applicable to the products falling within the scope of this standard.
Relationship between this
European
Standard and the Essential Requirements
of EU Directive 2006/42/EC This European Standard has been prepared under a mandate given to CEN by the European Commission and the European Free Trade Association to provide one means of conforming to Essential Requirements of the New Approach Directive 2006/42/EC on machinery. Once this standard is cited in the Official Journal of the European Union under that Directive and has been implemented as a national standard in at least one Member State, compliance with the normative clauses of this standard confers, within the limits of the scope of this standard, a presumption of conformity with the corresponding Essential Requirement of that Directive, except ER 2.2.1.1, and associated EFTA regulations. WARNING — Other requirements and other EU Directives may be applicable to the product(s) falling within the scope of this standard.
Reference numberISO 28927-9:2009(E)© ISO 2009
INTERNATIONAL STANDARD ISO28927-9First edition2009-12-15Hand-held portable power tools — Test methods for evaluation of vibration emission — Part 9: Scaling hammers and needle scalers Machines à moteur portatives — Méthodes d'essai pour l'évaluation de l'émission de vibrations — Partie 9: Marteaux dérouilleurs et marteaux à aiguilles
ISO 28927-9:2009(E) PDF disclaimer This PDF file may contain embedded typefaces. In accordance with Adobe's licensing policy, this file may be printed or viewed but shall not be edited unless the typefaces which are embedded are licensed to and installed on the computer performing the editing. In downloading this file, parties accept therein the responsibility of not infringing Adobe's licensing policy. The ISO Central Secretariat accepts no liability in this area. Adobe is a trademark of Adobe Systems Incorporated. Details of the software products used to create this PDF file can be found in the General Info relative to the file; the PDF-creation parameters were optimized for printing. Every care has been taken to ensure that the file is suitable for use by ISO member bodies. In the unlikely event that a problem relating to it is found, please inform the Central Secretariat at the address given below.
©
ISO 2009 All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from either ISO at the address below or ISO's member body in the country of the requester. ISO copyright office Case postale 56 • CH-1211 Geneva 20 Tel.
+ 41 22 749 01 11 Fax
+ 41 22 749 09 47 E-mail
[e-mail] Web
www.iso.org Published in Switzerland
ii © ISO 2009 – All rights reserved
ISO 28927-9:2009(E) © ISO 2009 – All rights reserved iii Contents Page Foreword.iv Introduction.vi 1 Scope.1 2 Normative references.1 3 Terms, definitions and symbols.2 3.1 Terms and definitions.2 3.2 Symbols.2§ 4 Basic standards and vibration test codes.3 5 Description of the family of machines.3 6 Characterization of vibration.5 6.1 Direction of measurement.5 6.2 Location of measurements.5 6.3 Magnitude of vibration.7 6.4 Combination of vibration directions.7 7 Instrumentation requirements.8 7.1 General.8 7.2 Mounting of transducers.8 7.2.1 Specification of transducer.8 7.2.2 Fastening of transducers.8 7.3 Frequency weighting filter.8 7.4 Integration time.8 7.5 Auxiliary equipment.9 7.6 Calibration.9 8 Testing and operating conditions of the machinery.9 8.1 General.9 8.2 Operating conditions.9 8.2.1 Pneumatic machines.9 8.2.2 Hydraulic machines.10 8.2.3 Electrical machines.10 8.3 Other quantities to be specified.10 8.4 Attached equipment, work piece and task.10 8.4.1 Test set-up and procedure.10 8.4.2 Feed force.11 8.5 Operators.11 9 Measurement procedure and validity.11 9.1 Reported vibration values.11 9.2 Declaration and verification of the vibration emission value.12 10 Measurement report.12 Annex A (informative)
Model test report for vibration emission at handles of scaling hammers and needle scalers.13 Annex B (normative)
Determination of uncertainty.15 Bibliography.17 SIST EN ISO 28927-9:2010

ISO 28927-9:2009(E) iv © ISO 2009 – All rights reserved Foreword ISO (the International Organization for Standardization) is a worldwide federation of national standards bodies (ISO member bodies). The work of preparing International Standards is normally carried out through ISO technical committees. Each member body interested in a subject for which a technical committee has been established has the right to be represented on that committee. International organizations, governmental and non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization. International Standards are drafted in accordance with the rules given in the ISO/IEC Directives, Part 2. The main task of technical committees is to prepare International Standards. Draft International Standards adopted by the technical committees are circulated to the member bodies for voting. Publication as an International Standard requires approval by at least 75 % of the member bodies casting a vote. Attention is drawn to the possibility that some of the elements of this document may be the subject of patent rights. ISO shall not be held responsible for identifying any or all such patent rights. ISO 28927-9 was prepared by Technical Committee ISO/TC 118, Compressors and pneumatic tools, machines and equipment, Subcommittee SC 3, Pneumatic tools and machines. This first edition of ISO 29827-9, together with ISO 29827-11, cancels and replaces ISO 8662-14:1996, of which it constitutes a technical revision. The most important changes are ⎯ vibration measurement in three axes and at both hand positions, ⎯ new transducer positions, ⎯ stone working tools become stone hammers and the subject of a separate Part 11, and ⎯ reference to energy absorbers deleted and all tools now tested on a mild steel plate or concrete block. ISO 28927 consists of the following parts, under the general title Hand-held portable power tools — Test methods for evaluation of vibration emission: ⎯ Part 1: Angle and vertical grinders1) ⎯ Part 2: Wrenches, nutrunners and screwdrivers2) ⎯ Part 3: Polishers and rotary, orbital and random orbital sanders3) ⎯ Part 4: Straight grinders4)
1) Together with Part 4, replaces ISO 8662-4, Hand-held portable power tools — Measurement of vibrations at the handle — Part 4: Grinders. 2) Replaces ISO 8662-7, Hand-held portable power tools — Measurement of vibrations at the handle — Part 7: Wrenches, screwdrivers nut runners with impact, impulse and ratcheting action. All screwdrivers and nutrunners except for one-shot tools now covered. 3) Replaces ISO 8662-8, Hand-held portable power tools — Measurement of vibrations at the handle — Part 8: Polishers and rotary, orbital and random orbital sanders. 4) Together with Part 1, replaces ISO 8662-4, Hand-held portable power tools — Measurement of vibrations at the handle — Part 4: Grinders. SIST EN ISO 28927-9:2010

ISO 28927-9:2009(E) © ISO 2009 – All rights reserved v ⎯ Part 5: Drills and impact drills5) ⎯ Part 6: Rammers6) ⎯ Part 7: Nibblers and shears7) ⎯ Part 8: Saws, polishing and filing machines with reciprocating action and small saws with oscillating or rotating action8) ⎯ Part 9: Scaling hammers and needle scalers ⎯ Part 10: Percussive drills, hammers and breakers9) ⎯ Part 11: Stone hammers10)
5) Replaces ISO 8662-6, Hand-held portable power tools — Measurement of vibrations at the handle — Part 6: Impact drills. Non-impacting drills now covered. 6) Replaces ISO 8662-9, Hand-held portable power tools — Measurement of vibrations at the handle — Part 9: Rammers. 7) Replaces ISO 8662-10, Hand-held portable power tools — Measurement of vibrations at the handle — Part 10: Nibblers and shears. 8) Replaces ISO 8662-12, Hand-held portable power tools — Measurement of vibrations at the handle — Part 12: Saws and files with reciprocating action and saws with oscillating or rotating action. 9) Replaces ISO 8662-2, Hand-held portable power tools — Measurement of vibrations at the handle — Part 2: Chipping hammers and riveting hammers, ISO 8662-3, Hand-held portable power tools — Measurement of vibrations at the handle — Part 3: Rock drills and rotary hammers, and ISO 8662-5, Hand-held portable power tools — Measurement of vibrations at the handle — Part 5: Pavement breakers and hammers for construction work. Chipping and riveting hammers, rock drills and rotary hammers all covered. 10) Together with Part 9, replaces ISO 8662-14, Hand-held portable power tools — Measurement of vibrations at the handle — Part 14: Stone-working tools and needle scalers. SIST EN ISO 28927-9:2010

ISO 28927-9:2009(E) vi © ISO 2009 – All rights reserved Introduction This document is a type-C standard as stated in ISO 12100. When requirements of this type-C standard are different from those which are stated in type-A or -B standards, the requirements of this type-C standard take precedence over the requirements of the other standards for machines that have been designed and built according to the requirements of this type-C standard. The vibration test codes for portable hand-held machines given in ISO 28927 are based on ISO 20643, which gives general specifications for the measurement of the vibration emission of hand-held and hand-guided machinery. ISO 28927 specifies the operation of the machines under type-test conditions and other requirements for the performance of type tests. The structure/numbering of its clauses follows that of ISO 20643. The basic principle for transducer positioning first introduced in the EN 60745 series of European standards is followed, representing a deviation from ISO 20643 for reasons of consistency. The transducers are primarily positioned next to the hand in the area between the thumb and the index finger, where they give the least disturbance to the operator gripping the machine. It has been found that vibrations generated by scaling hammers and needle scalers vary considerably in typical use. The percussive action is the prime source of vibration, and the variation is largely due to variations in the handling of the machine and the characteristics of the material being worked on. Differences in the support of the material also cause differences in vibration. This part of ISO 28927 uses a working process where the machine is used to work on a steel or concrete surface. In order to achieve good reproducibility, it is important that the material have good support and that the inserted tools used be in good condition. The procedures of ISO 5349 are required whenever exposure at the workplace is to be assessed. The values obtained are type-test values intended to be representative of the average of the upper quartile of typical vibration magnitudes in real-world use of the machines. However, the actual magnitudes will vary considerably from time to time and depend on many factors, including the operator, the task and the inserted tool or consumable. The state of maintenance of the machine itself might also be of importance. Under real working conditions, the influences of the operator and process can be particularly important at low magnitudes. It is therefore not recommended that emission values below 2,5 m/s2 be used for estimating the vibration magnitude under real working conditions. In such cases, 2,5 m/s2 is the recommended vibration magnitude for estimating the machine vibration. If accurate values for a specific work place are required, then measurements (according to ISO 5349) in that work situation could be necessary. Vibration values measured in real working conditions can be either higher or lower than the values obtained using this part of ISO 28927. The vibration test codes given in ISO 28927 supersede those given in ISO 8662, whose parts have been replaced by the corresponding parts of ISO 28927 (see Foreword). NOTE ISO 8662-11, Hand-held portable power tools — Measurement of vibrations at the handle — Part 11: Fastener driving tools, and ISO 8662-13, Hand-held portable power tools — Measurement of vibrations at the handle — Part 13: Die grinders, could be replaced by future parts of ISO 28927.
INTERNATIONAL STANDARD ISO 28927-9:2009(E) © ISO 2009 – All rights reserved 1 Hand-held portable power tools — Test methods for evaluation of vibration emission — Part 9: Scaling hammers and needle scalers 1 Scope This part of ISO 28927 specifies a laboratory method for measuring hand-transmitted vibration emission at the handles of hand-held, power-driven scaling hammers and needle scalers. It is a type-test procedure for establishing the magnitude of vibrat
...
