SLOVENSKI STANDARD
SIST EN IEC 63121:2022
01-februar-2022
Instrumenti za zaščito pred sevanjem - Vozila z vgrajenimi mobilnimi sistemi za
odkrivanje nedovoljene trgovine z radioaktivnimi snovmi (IEC 63121:2020)
Radiation protection instrumentation - Vehicle-mounted mobile systems for the detection
of illicit trafficking of radioactive materials (IEC 63121:2020)
Strahlenschutz-Messgeräte - Fahrzeuggestützte mobile Systeme zum Aufspüren von
unerlaubt transportiertem radioaktivem Material (IEC 63121:2020)
Instrumentation pour la radioprotection - Systèmes mobiles montés sur véhicules pour la
détection du trafic illicite des matières radioactives (IEC 63121:2020)
Ta slovenski standard je istoveten z: EN IEC 63121:2021
ICS:
13.280 Varstvo pred sevanjem Radiation protection
13.310 Varstvo pred kriminalom Protection against crime
SIST EN IEC 63121:2022 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------
SIST EN IEC 63121:2022

---------------------- Page: 2 ----------------------
SIST EN IEC 63121:2022


EUROPEAN STANDARD EN IEC 63121

NORME EUROPÉENNE

EUROPÄISCHE NORM
December 2021
ICS 13.280

English Version
Radiation protection instrumentation - Vehicle-mounted mobile
systems for the detection of illicit trafficking of radioactive
materials
(IEC 63121:2020)
Instrumentation pour la radioprotection - Systèmes mobiles Strahlenschutz-Messgeräte - Fahrzeuggestützte mobile
montés sur véhicules pour la détection du trafic illicite des Systeme zum Aufspüren von unerlaubt transportiertem
matières radioactives radioaktivem Material
(IEC 63121:2020) (IEC 63121:2020)
This European Standard was approved by CENELEC on 2021-12-02. CENELEC members are bound to comply with the CEN/CENELEC
Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation
under the responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the
same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Turkey and the United Kingdom.


European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2021 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
 Ref. No. EN IEC 63121:2021 E

---------------------- Page: 3 ----------------------
SIST EN IEC 63121:2022
EN IEC 63121:2021 (E)
European foreword
This document (EN IEC 63121:2021) consists of the text of IEC 63121:2020 prepared by IEC/SC 45B
“Radiation protection instrumentation” of IEC/TC 45 "Nuclear instrumentation".
The following dates are fixed:
• latest date by which this document has to be (dop) 2022-12-02
implemented at national level by publication of an
identical national standard or by endorsement
• latest date by which the national standards (dow) 2024-12-02
conflicting with this document have to be withdrawn
Attention is drawn to the possibility that some of the elements of this document may be the subject of patent
rights. CENELEC shall not be held responsible for identifying any or all such patent rights.
Any feedback and questions on this document should be directed to the users’ national committee. A
complete listing of these bodies can be found on the CENELEC website.
Endorsement notice
The text of the International Standard IEC 63121:2020 was approved by CENELEC as a European Standard
without any modification.
In the official version, for Bibliography, the following notes have to be added for the standards indicated:
IEC 60068-2-11 NOTE Harmonized as EN IEC 60068-2-11
IEC 60086-1 NOTE Harmonized as EN IEC 60086-1
2

---------------------- Page: 4 ----------------------
SIST EN IEC 63121:2022
EN IEC 63121:2021 (E)
Annex ZA
(normative)

Normative references to international publications
with their corresponding European publications
The following documents are referred to in the text in such a way that some or all of their content constitutes
requirements of this document. For dated references, only the edition cited applies. For undated references,
the latest edition of the referenced document (including any amendments) applies.
NOTE 1  Where an International Publication has been modified by common modifications, indicated by (mod), the
relevant EN/HD applies.
NOTE 2  Up-to-date information on the latest versions of the European Standards listed in this annex is available here:
www.cenelec.eu.
Publication Year Title EN/HD Year
IEC 60050-395 2014 International Electrotechnical Vocabulary - - -
Part 395: Nuclear instrumentation: Physical
phenomena, basic concepts, instruments,
systems, equipment and detectors
IEC 61187 - Electrical and electronic measuring EN 61187 -
equipment - Documentation
IEC 62706 - Radiation protection instrumentation - - -
Environmental, electromagnetic and
mechanical performance requirements
IEC 62755 - Radiation protection instrumentation - Data - -
format for radiation instruments used in the
detection of illicit trafficking of radioactive
materials

3

---------------------- Page: 5 ----------------------
SIST EN IEC 63121:2022

---------------------- Page: 6 ----------------------
SIST EN IEC 63121:2022




IEC 63121

®


Edition 1.0 2020-01




INTERNATIONAL



STANDARD








colour

inside










Radiation protection instrumentation –

Vehicle-mounted mobile systems for the detection of illicit trafficking of

radioactive materials


























INTERNATIONAL

ELECTROTECHNICAL


COMMISSION





ICS 13.280 ISBN 978-2-8322-7706-5




  Warning! Make sure that you obtained this publication from an authorized distributor.


® Registered trademark of the International Electrotechnical Commission

---------------------- Page: 7 ----------------------
SIST EN IEC 63121:2022
– 2 – IEC 63121:2020 © IEC 2020
CONTENTS
INTRODUCTION . 7
1 Scope . 8
2 Normative references . 8
3 Terms and definitions, abbreviated terms and symbols, quantities and units . 8
3.1 Terms and definitions . 8
3.2 Abbreviated terms and symbols . 10
3.3 Quantities and units . 11
4 General test procedure . 11
4.1 General . 11
4.2 Standard test conditions . 11
4.3 Uncertainties. 12
4.4 Statistical fluctuations . 12
4.5 Background radiation during testing . 12
4.6 Operating parameters and set up . 12
4.7 Setup and test parameters . 12
4.8 Dynamic testing . 13
4.9 Static testing . 13
4.10 Radiation sources . 14
4.11 Special nuclear material (SNM) and depleted uranium (DU) sources . 15
4.12 Functionality test and test acceptance range requirements . 16
4.12.1 General requirements . 16
4.12.2 Pre-test measurements . 17
4.12.3 Intermediate-test measurements . 18
4.12.4 Post-test measurements . 18
4.12.5 Acceptance criteria . 19
5 General requirements . 19
5.1 General characteristics . 19
5.2 Physical configuration . 20
5.3 Data storage and data files . 20
5.3.1 Requirements . 20
5.3.2 Method of test. 21
5.4 Communications protocol . 21
5.4.1 Requirements . 21
5.4.2 Method of test. 21
5.5 Indication and alarm features . 21
5.5.1 Requirements . 21
5.5.2 Method of test. 21
5.6 Markings . 22
5.6.1 Requirements . 22
5.6.2 Method of test. 22
5.7 Power supply . 22
5.7.1 Requirements . 22
5.7.2 Method of test. 22
5.8 User interface . 22
5.8.1 User accessible controls requirements . 22
5.8.2 Supervisory-user accessible indications and functions requirements. 22
5.8.3 User display and visual indicators requirements . 23

---------------------- Page: 8 ----------------------
SIST EN IEC 63121:2022
IEC 63121:2020 © IEC 2020 – 3 –
5.8.4 Warning indicators requirements. 23
5.8.5 Method of test. 23
6 Radiological tests . 24
6.1 False alarm test . 24
6.1.1 Requirements . 24
6.1.2 Method of test. 24
6.2 Gamma radiation alarm . 24
6.2.1 Requirements . 24
6.2.2 Method of test. 25
6.3 Neutron radiation alarm . 25
6.3.1 Requirements . 25
6.3.2 Method of test. 25
6.4 Over-range indication . 25
6.4.1 Requirements . 25
6.4.2 Method of test. 26
6.5 Neutron indication in the presence of photons . 26
6.5.1 Requirements . 26
6.5.2 Method of test. 26
6.6 Slowly approaching source—vehicle-mounted mobile system is stationary
during use . 27
6.6.1 Requirements . 27
6.6.2 Method of test. 27
6.7 Background effects—vehicle-mounted mobile system is mobile during use . 27
6.7.1 Requirements and background information . 27
6.7.2 Method of test. 28
6.8 Radionuclide identification—when provided . 30
6.8.1 Radionuclide categorisation . 30
6.8.2 Single radionuclide identification . 31
6.8.3 Simultaneous radionuclide identification . 32
6.8.4 Radionuclide not in library . 32
7 Climatic requirements . 33
7.1 General . 33
7.2 Ambient temperature. 34
7.2.1 Requirements . 34
7.2.2 Method of test. 34
7.3 Relative humidity . 34
7.3.1 Requirements . 34
7.3.2 Method of test. 34
7.4 Dust and moisture protection . 35
7.4.1 Requirements . 35
7.4.2 Method of test—dust . 35
7.4.3 Method of test—moisture . 35
8 Mechanical requirements . 35
8.1 Microphonics/impact . 35
8.1.1 Requirements . 35
8.1.2 Method of test. 36
8.2 Vibration . 36
8.2.1 Requirements . 36
8.2.2 Method of test. 36

---------------------- Page: 9 ----------------------
SIST EN IEC 63121:2022
– 4 – IEC 63121:2020 © IEC 2020
9 Electrical and electromagnetic requirements . 36
9.1 Electrostatic discharge (ESD) . 36
9.1.1 Requirements . 36
9.1.2 Method of test. 36
9.2 Radio frequency (RF) . 37
9.2.1 Requirements . 37
9.2.2 Method of test. 37
9.3 Radiated emissions . 37
9.3.1 Requirements . 37
9.3.2 Method of test. 37
9.4 Battery lifetime . 37
9.4.1 Requirements . 37
9.4.2 Method of test. 37
10 Documentation . 38
10.1 Report. 38
10.2 Operation and maintenance manual . 38
Annex A (informative) Uranium/plutonium detection and identification guidance . 39
Bibliography . 40

Figure 1 – Reference point diagram for a two-sided vehicle-mounted mobile system
(top down view) . 14
Figure 2 – Increasing background with source . 29
Figure 3 – Decreasing background with source . 29

Table 1 – . 11
Standard test conditions
Table 2 – Setup and test parameters . 13
a
Table 3 – Test radionuclides and materials used for Clause 6 of this document . 15
Table 4 – SNM fluence rates . 16
Table 5 – Test results analysis . 19
Table 6 – Radionuclide library . 30
Table 7 – Radionuclide decay products and impurities . 30

---------------------- Page: 10 ----------------------
SIST EN IEC 63121:2022
IEC 63121:2020 © IEC 2020 – 5 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________

RADIATION PROTECTION INSTRUMENTATION –
VEHICLE-MOUNTED MOBILE SYSTEMS FOR THE DETECTION
OF ILLICIT TRAFFICKING OF RADIOACTIVE MATERIALS

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with an IEC Publication.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 63121 has been prepared by subcommittee 45B: Radiation
protection instrumentation, of IEC technical committee 45: Nuclear instrumentation.
The text of this standard is based on the following documents:
FDIS Report on voting
45B/946/FDIS 45B/955/RVD

Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.

---------------------- Page: 11 ----------------------
SIST EN IEC 63121:2022
– 6 – IEC 63121:2020 © IEC 2020
The committee has decided that the contents of this publication will remain unchanged until
the stability date indicated on the IEC website under "http://webstore.iec.ch" in the data
related to the specific publication. At this date, the publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
A bilingual version of this publication may be issued at a later date.

IMPORTANT – The 'colour inside' logo on the cover page of this publication indicates
that it contains colours which are considered to be useful for the correct
understanding of its contents. Users should therefore print this document using a
colour printer.

---------------------- Page: 12 ----------------------
SIST EN IEC 63121:2022
IEC 63121:2020 © IEC 2020 – 7 –
INTRODUCTION
Illicit and inadvertent movement of radioactive materials in the form of radiation sources and
contaminated metallurgical scrap has become a problem of increasing importance.
Radioactive sources out of regulatory control, so-called “orphan sources”, have frequently
caused serious radiation exposures and widespread contamination. Although illicit trafficking
of nuclear and other radioactive materials is not a new problem, concern about a nuclear
“black market” has increased, particularly in view of its terrorist potential.
In response to the technical policy of the International Atomic Energy Agency (IAEA), the
World Customs Organization (WCO), and the International Criminal Police Organization
(Interpol) related to the detection and identification of special nuclear materials and security
trends, radiation instrumentation companies have developed and manufactured instruments to
assist in the detection of illicit movement of radioactive and special nuclear materials. This
type of instrumentation is widely used for security purposes at nuclear facilities, border control
checkpoints, and international seaports and airports.
To ensure that measurement results made at different locations are consistent, it is imperative
that radiation instrumentation be designed to rigorous specifications based upon agreed
performance requirements stated in this document. IEC standards have also been developed
to address personal radiation detectors, radiation portal monitors, highly sensitive gamma and
neutron detection systems, spectrometric personal radiation detectors, and backpack-based
radiation detection and identification systems. Those standards are listed below.
Type of IEC
Title of the standard
instrumentation number
Radiation protection instrumentation – Alarming Personal Radiation Devices
62401
(PRDs) for the detection of illicit trafficking of radioactive material
Radiation protection instrumentation – Spectroscopy-Based Alarming Personal
Body-worn 62618 Radiation Devices (SPRD) for the detection of illicit trafficking of radioactive
material
Radiation protection instrumentation – Backpack-type radiation detector (BRD) for
62694
the detection of illicit trafficking of radioactive material
Radiation protection instrumentation – Hand-held instruments for the detection and
62327 identification of radionuclides and for the estimation of ambient dose equivalent
rate from photon radiation
Portable or
Radiation protection instrumentation – Highly sensitive hand-held instruments for
62533
hand-held
photon detection of radioactive material
Radiation protection instrumentation – Highly sensitive hand-held instruments for
62534
neutron detection of radioactive material
Radiation protection instrumentation – Installed radiation portal monitors (RPMs)
62244
for the detection of illicit trafficking of radioactive and nuclear materials
Portal
Radiation protection instrumentation – Spectroscopy-based portal monitors used
62484
for the detection and identific
...

SLOVENSKI STANDARD
oSIST prEN IEC 63121:2021
01-september-2021
Instrumenti za zaščito pred sevanjem - Vozila z vgrajenimi mobilnimi sistemi za
odkrivanje nedovoljene trgovine z radioaktivnimi snovmi
Radiation protection instrumentation - Vehicle-mounted mobile systems for the detection
of illicit trafficking of radioactive materials
Strahlenschutz-Messgeräte - Fahrzeuggestützte mobile Systeme zum Aufspüren von
unerlaubt transportiertem radioaktivem Material
Instrumentation pour la radioprotection - Systèmes mobiles montés sur véhicules pour la
détection du trafic illicite des matières radioactives
Ta slovenski standard je istoveten z: prEN IEC 63121
ICS:
13.280 Varstvo pred sevanjem Radiation protection
oSIST prEN IEC 63121:2021 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------
oSIST prEN IEC 63121:2021

---------------------- Page: 2 ----------------------
oSIST prEN IEC 63121:2021


EUROPEAN STANDARD DRAFT
prEN IEC 63121
NORME EUROPÉENNE

EUROPÄISCHE NORM

June 2021
ICS 13.280

English Version
Radiation protection instrumentation - Vehicle-mounted mobile
systems for the detection of illicit trafficking of radioactive
materials
(IEC 63121:2020)
Instrumentation pour la radioprotection - Systèmes mobiles Strahlenschutz-Messgeräte - Fahrzeuggestützte mobile
montés sur véhicules pour la détection du trafic illicite des Systeme zum Aufspüren von unerlaubt transportiertem
matières radioactives radioaktivem Material
(IEC 63121:2020) (IEC 63121:2020)
This draft European Standard is submitted to CENELEC members for enquiry.
Deadline for CENELEC: 2021-09-17.

The text of this draft consists of the text of IEC 63121:2020.

If this draft becomes a European Standard, CENELEC members are bound to comply with the CEN/CENELEC Internal Regulations which
stipulate the conditions for giving this European Standard the status of a national standard without any alteration.

This draft European Standard was established by CENELEC in three official versions (English, French, German).
A version in any other language made by translation under the responsibility of a CENELEC member into its own language and notified to
the CEN-CENELEC Management Centre has the same status as the official versions.

CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Turkey and the United Kingdom.

Recipients of this draft are invited to submit, with their comments, notification of any relevant patent rights of which they are aware and to
provide supporting documentation.

Warning : This document is not a European Standard. It is distributed for review and comments. It is subject to change without notice and
shall not be referred to as a European Standard.


European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2021 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
Project: 73958 Ref. No. prEN IEC 63121 E

---------------------- Page: 3 ----------------------
oSIST prEN IEC 63121:2021
prEN IEC 63121:2021 (E)
European foreword
This document (prEN IEC 63121:2021) consists of the text of IEC 63121:2020 prepared by IEC/SC 45B
“Radiation protection instrumentation” of IEC/TC 45 "Nuclear instrumentation".
This document is currently submitted to the Enquiry.
The following dates are proposed:
• latest date by which the existence of this document (doa) dor + 6 months
has to be announced at national level
• latest date by which this document has to be (dop) dor + 12 months
implemented at national level by publication of an
identical national standard or by endorsement
• latest date by which the national standards (dow) dor + 36 months
conflicting with this document have to be withdrawn (to be confirmed or
modified when voting)
2

---------------------- Page: 4 ----------------------
oSIST prEN IEC 63121:2021
prEN IEC 63121:2021 (E)
Annex ZA
(normative)

Normative references to international publications
with their corresponding European publications
The following documents are referred to in the text in such a way that some or all of their content constitutes
requirements of this document. For dated references, only the edition cited applies. For undated references,
the latest edition of the referenced document (including any amendments) applies.
NOTE 1  Where an International Publication has been modified by common modifications, indicated by (mod), the
relevant EN/HD applies.
NOTE 2  Up-to-date information on the latest versions of the European Standards listed in this annex is available here:
www.cenelec.eu.
Publication Year Title EN/HD Year
IEC 60050-395 2014 International Electrotechnical Vocabulary - - -
Part 395: Nuclear instrumentation: Physical
phenomena, basic concepts, instruments,
systems, equipment and detectors
IEC 61187 - Electrical and electronic measuring EN 61187 -
equipment - Documentation
IEC 62706 - Radiation protection instrumentation - - -
Environmental, electromagnetic and
mechanical performance requirements
IEC 62755 - Radiation protection instrumentation - Data - -
format for radiation instruments used in the
detection of illicit trafficking of radioactive
materials

3

---------------------- Page: 5 ----------------------
oSIST prEN IEC 63121:2021

---------------------- Page: 6 ----------------------
oSIST prEN IEC 63121:2021




IEC 63121

®


Edition 1.0 2020-01




INTERNATIONAL



STANDARD








colour

inside










Radiation protection instrumentation –

Vehicle-mounted mobile systems for the detection of illicit trafficking of

radioactive materials


























INTERNATIONAL

ELECTROTECHNICAL


COMMISSION





ICS 13.280 ISBN 978-2-8322-7706-5




  Warning! Make sure that you obtained this publication from an authorized distributor.


® Registered trademark of the International Electrotechnical Commission

---------------------- Page: 7 ----------------------
oSIST prEN IEC 63121:2021
– 2 – IEC 63121:2020 © IEC 2020
CONTENTS
INTRODUCTION . 7
1 Scope . 8
2 Normative references . 8
3 Terms and definitions, abbreviated terms and symbols, quantities and units . 8
3.1 Terms and definitions . 8
3.2 Abbreviated terms and symbols . 10
3.3 Quantities and units . 11
4 General test procedure . 11
4.1 General . 11
4.2 Standard test conditions . 11
4.3 Uncertainties. 12
4.4 Statistical fluctuations . 12
4.5 Background radiation during testing . 12
4.6 Operating parameters and set up . 12
4.7 Setup and test parameters . 12
4.8 Dynamic testing . 13
4.9 Static testing . 13
4.10 Radiation sources . 14
4.11 Special nuclear material (SNM) and depleted uranium (DU) sources . 15
4.12 Functionality test and test acceptance range requirements . 16
4.12.1 General requirements . 16
4.12.2 Pre-test measurements . 17
4.12.3 Intermediate-test measurements . 18
4.12.4 Post-test measurements . 18
4.12.5 Acceptance criteria . 19
5 General requirements . 19
5.1 General characteristics . 19
5.2 Physical configuration . 20
5.3 Data storage and data files . 20
5.3.1 Requirements . 20
5.3.2 Method of test. 21
5.4 Communications protocol . 21
5.4.1 Requirements . 21
5.4.2 Method of test. 21
5.5 Indication and alarm features . 21
5.5.1 Requirements . 21
5.5.2 Method of test. 21
5.6 Markings . 22
5.6.1 Requirements . 22
5.6.2 Method of test. 22
5.7 Power supply . 22
5.7.1 Requirements . 22
5.7.2 Method of test. 22
5.8 User interface . 22
5.8.1 User accessible controls requirements . 22
5.8.2 Supervisory-user accessible indications and functions requirements. 22
5.8.3 User display and visual indicators requirements . 23

---------------------- Page: 8 ----------------------
oSIST prEN IEC 63121:2021
IEC 63121:2020 © IEC 2020 – 3 –
5.8.4 Warning indicators requirements. 23
5.8.5 Method of test. 23
6 Radiological tests . 24
6.1 False alarm test . 24
6.1.1 Requirements . 24
6.1.2 Method of test. 24
6.2 Gamma radiation alarm . 24
6.2.1 Requirements . 24
6.2.2 Method of test. 25
6.3 Neutron radiation alarm . 25
6.3.1 Requirements . 25
6.3.2 Method of test. 25
6.4 Over-range indication . 25
6.4.1 Requirements . 25
6.4.2 Method of test. 26
6.5 Neutron indication in the presence of photons . 26
6.5.1 Requirements . 26
6.5.2 Method of test. 26
6.6 Slowly approaching source—vehicle-mounted mobile system is stationary
during use . 27
6.6.1 Requirements . 27
6.6.2 Method of test. 27
6.7 Background effects—vehicle-mounted mobile system is mobile during use . 27
6.7.1 Requirements and background information . 27
6.7.2 Method of test. 28
6.8 Radionuclide identification—when provided . 30
6.8.1 Radionuclide categorisation . 30
6.8.2 Single radionuclide identification . 31
6.8.3 Simultaneous radionuclide identification . 32
6.8.4 Radionuclide not in library . 32
7 Climatic requirements . 33
7.1 General . 33
7.2 Ambient temperature. 34
7.2.1 Requirements . 34
7.2.2 Method of test. 34
7.3 Relative humidity . 34
7.3.1 Requirements . 34
7.3.2 Method of test. 34
7.4 Dust and moisture protection . 35
7.4.1 Requirements . 35
7.4.2 Method of test—dust . 35
7.4.3 Method of test—moisture . 35
8 Mechanical requirements . 35
8.1 Microphonics/impact . 35
8.1.1 Requirements . 35
8.1.2 Method of test. 36
8.2 Vibration . 36
8.2.1 Requirements . 36
8.2.2 Method of test. 36

---------------------- Page: 9 ----------------------
oSIST prEN IEC 63121:2021
– 4 – IEC 63121:2020 © IEC 2020
9 Electrical and electromagnetic requirements . 36
9.1 Electrostatic discharge (ESD) . 36
9.1.1 Requirements . 36
9.1.2 Method of test. 36
9.2 Radio frequency (RF) . 37
9.2.1 Requirements . 37
9.2.2 Method of test. 37
9.3 Radiated emissions . 37
9.3.1 Requirements . 37
9.3.2 Method of test. 37
9.4 Battery lifetime . 37
9.4.1 Requirements . 37
9.4.2 Method of test. 37
10 Documentation . 38
10.1 Report. 38
10.2 Operation and maintenance manual . 38
Annex A (informative) Uranium/plutonium detection and identification guidance . 39
Bibliography . 40

Figure 1 – Reference point diagram for a two-sided vehicle-mounted mobile system
(top down view) . 14
Figure 2 – Increasing background with source . 29
Figure 3 – Decreasing background with source . 29

Table 1 – . 11
Standard test conditions
Table 2 – Setup and test parameters . 13
a
Table 3 – Test radionuclides and materials used for Clause 6 of this document . 15
Table 4 – SNM fluence rates . 16
Table 5 – Test results analysis . 19
Table 6 – Radionuclide library . 30
Table 7 – Radionuclide decay products and impurities . 30

---------------------- Page: 10 ----------------------
oSIST prEN IEC 63121:2021
IEC 63121:2020 © IEC 2020 – 5 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________

RADIATION PROTECTION INSTRUMENTATION –
VEHICLE-MOUNTED MOBILE SYSTEMS FOR THE DETECTION
OF ILLICIT TRAFFICKING OF RADIOACTIVE MATERIALS

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with an IEC Publication.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 63121 has been prepared by subcommittee 45B: Radiation
protection instrumentation, of IEC technical committee 45: Nuclear instrumentation.
The text of this standard is based on the following documents:
FDIS Report on voting
45B/946/FDIS 45B/955/RVD

Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.

---------------------- Page: 11 ----------------------
oSIST prEN IEC 63121:2021
– 6 – IEC 63121:2020 © IEC 2020
The committee has decided that the contents of this publication will remain unchanged until
the stability date indicated on the IEC website under "http://webstore.iec.ch" in the data
related to the specific publication. At this date, the publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
A bilingual version of this publication may be issued at a later date.

IMPORTANT – The 'colour inside' logo on the cover page of this publication indicates
that it contains colours which are considered to be useful for the correct
understanding of its contents. Users should therefore print this document using a
colour printer.

---------------------- Page: 12 ----------------------
oSIST prEN IEC 63121:2021
IEC 63121:2020 © IEC 2020 – 7 –
INTRODUCTION
Illicit and inadvertent movement of radioactive materials in the form of radiation sources and
contaminated metallurgical scrap has become a problem of increasing importance.
Radioactive sources out of regulatory control, so-called “orphan sources”, have frequently
caused serious radiation exposures and widespread contamination. Although illicit trafficking
of nuclear and other radioactive materials is not a new problem, concern about a nuclear
“black market” has increased, particularly in view of its terrorist potential.
In response to the technical policy of the International Atomic Energy Agency (IAEA), the
World Customs Organization (WCO), and the International Criminal Police Organization
(Interpol) related to the detection and identification of special nuclear materials and security
trends, radiation instrumentation companies have developed and manufactured instruments to
assist in the detection of illicit movement of radioactive and special nuclear materials. This
type of instrumentation is widely used for security purposes at nuclear facilities, border control
checkpoints, and international seaports and airports.
To ensure that measurement results made at different locations are consistent, it is imperative
that radiation instrumentation be designed to rigorous specifications based upon agreed
performance requirements stated in this document. IEC standards have also been developed
to address personal radiation detectors, radiation portal monitors, highly sensitive gamma and
neutron detection systems, spectrometric personal radiation detectors, and backpack-based
radiation detection and identification systems. Those standards are listed below.
Type of IEC
Title of the standard
instrumentation number
Radiation protection instrumentation – Alarming Personal Radiation Devices
62401
(PRDs) for the detection of illicit trafficking of radioactive material
Radiation protection instrumentation – Spectroscopy-Based Alarming Personal
Body-worn 62618 Radiation Devices (SPRD) for the detection of illicit trafficking of radioactive
material
Radiation protection instrumentation – Backpack-type radiation detector (BRD) for
62694
the detection of illicit trafficking of radioactive material
Radiation protection instrumentation – Hand-held instruments for the detection and
62327 identification of radionuclides and for the estimation of ambient dose equivalent
rate from photon radiation
Portable or
Radiation protection instrumentation – Highly sensitive hand-held instruments for
62533
hand-held
photon detection of radioactive material
Radiation protection instrumentation – Highly sensitive hand-held instruments for
62534
neutron detection of radioactive material
Radiation protection instrumentation – Installed radiation portal monitors (RPMs)
62244
for the detection of illicit trafficking of radioactive and nuclear materials
Portal
Radiation protection instrumentation – Spectroscopy-based portal monitors used
62484
for the detection and identification of illicit trafficking of radioactive material
Radiation protection instrumentation – Vehicle-mounted mobile systems for the
Mobile system 63121
detection of illicit trafficking of
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
