SIST EN 60139:2002

Preparation of outline drawings for cathode-ray tubes, their components, connections and gauges

Gives guidance on the preparation of outline drawings of cathode ray tubes with the object of encouraging the same practice when publications are prepared in different countries.

Anfertigung von Umrisszeichnungen für Kathodenstrahlröhren, deren Bauteile, Anschlüsse und Lehrenmaße

Préparation des dessins d'encombrement des tubes à rayons cathodiques, de leurs composants, de leurs connexions et de leurs calibres

Contient des règles pour la préparation des dessins d'encombrement des tubes à rayons cathodiques, ayant pour but d'encourager la présentation uniforme des publications dans les divers pays. Des exemples de dessins types sont donnés dans cette publication.

Preparation of outline drawings for cathode-ray tubes, their components, connections and gauges (IEC 60139:2000)

General Information

• Status: Published
• Publication Date: 31-Aug-2002
• ICS: 01.100.25 - Electrical and electronics engineering drawings
• ICS: 31.100 - Electronic tubes
• Technical Committee: SS EIT - Technical Board for the electrotechnical, information technology and telecommunications fields
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-Sep-2002
• Due Date: 01-Sep-2002
• Completion Date: 01-Sep-2002
• Ref Project: EN 60139:2001 - Preparation of outline drawings for cathode-ray tubes, their components, connections and gauges

Overview

EN 60139:2001 (IEC 60139:2000) - prepared by CLC - gives guidance on the preparation of outline drawings for cathode-ray tubes (CRTs), their components, electrical connections and gauges. The standard’s objective is to encourage consistent practice when publications and technical drawings are prepared in different countries, improving clarity, interchangeability and cross-border communication for CRT documentation. EN 60139 is also published as SIST EN 60139:2002 in Slovenia.

Key topics

The standard focuses on standardizing how CRTs and related parts are represented in technical documentation. While it does not prescribe product performance, it provides guidance on presentation and content of outline drawings. Key topics typically addressed include:

• Outline representation of cathode-ray tubes and subassemblies to ensure consistent shape and scale in engineering drawings.
• Component identification and labelling to make parts and subcomponents easily recognisable across documents.
• Connection and pin layouts for electrical and mechanical interfaces so that wiring and mounting schemes are clear.
• Gauge and datum references for critical dimensions used in mating and inspection.
• Drawing annotations and identification (titles, reference numbers, revision status) to support document control and international exchange. (Note: EN 60139 provides guidance on drawing practice rather than prescribing specific dimensions or manufacturing tolerances.)

Applications

EN 60139 is practical for organizations and professionals involved in CRT documentation, such as:

• Manufacturers and suppliers of CRTs and related components producing outline drawings for product catalogues and assembly guides.
• Design and engineering teams preparing mechanical and electrical interface drawings for integration into larger systems.
• Technical illustrators and documentation specialists who produce standardised engineering drawings and datasheets.
• Standards bodies and regulators aligning national publications with international practice.
• Maintenance and repair services that rely on clear outline drawings for replacement parts and service procedures.

Related standards

• IEC 60139:2000 - original international version (EN 60139 is its European adoption).
• Other relevant engineering drawing standards and electrical component documentation standards may be used alongside EN 60139 for full technical detail and dimensioning practices.

EN 60139 is primarily a documentation and representation standard to promote uniform CRT outline drawings and facilitate international interoperability of technical publications. Keywords: EN 60139, IEC 60139, CRT outline drawings, cathode-ray tube drawings, engineering drawings, CLC.
