SIST EN ISO 9222-2:1998

Technical drawings - Seals of dynamic application - Part 2: Detailed simplified representation (ISO 9222-2:1989)

In contrast to the general simplified representation of part 1, this method shows more details of a seal, for example the configuration of lips. It should also be used when it is not necessary to show the exact shape and details of the seals, for example in assembly drawings. Elements and examples of this representation mode are given in tables and figures.

Technische Zeichnungen - Dichtungen für dynamische Belastung - Teil 2: Detaillierte, vereinfachte Darstellung (ISO 9222-2:1989)

Dieser Teil von ISO 9222 legt Regeln für die detaillierte Darstellung von verschiedenen Dichtungen fest. Diese Darstellung ist anzuwenden, wenn es nicht nötig ist, die genaue Form und die Einzelheiten der Dichtungen zu zeigen, z. B.in Zusammenbau-Zeichnungen.

Dessins techniques - Joints d'étanchéité pour application dynamique - Partie 2: Représentation simplifiée particuliere (ISO 9222-2:1989)

La présente partie de l'ISO 9222 prescrit une représentation simplifiée particulière de divers joints d'étanchéité. Il convient d'utiliser cette représentation lorsqu'il n'est pas nécessaire de montrer la forme exacte et les détails des joints d'étanchéité, par exemple dans des dessins d'assemblage.

Tehnične risbe - Tesnila za dinamično uporabo - 2. del: Poenostavljeno prikazovanje s podrobnostmi

General Information

• Status: Published
• Publication Date: 30-Apr-1998
• ICS: 01.100.20 - Mechanical engineering drawings
• ICS: 21.140 - Seals, glands
• Technical Committee: TRS - Technical drawings, quantities, units, symbols and graphical symbols
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 01-May-1998
• Due Date: 01-May-1998
• Completion Date: 01-May-1998
• Ref Project: EN ISO 9222-2:1994 - Technical drawings - Seals of dynamic application - Part 2: Detailed simplified representation (ISO 9222-2:1989)

Overview

EN ISO 9222-2:1994 / ISO 9222-2:1989 defines a method for the detailed simplified representation of seals used in dynamic applications on technical drawings. Unlike the more general symbol set in Part 1, this part prescribes how to show additional seal details (for example lip configuration) while still avoiding full, exact geometric depiction. The standard is intended for use where precise contour detail is unnecessary - typically in assembly drawings, catalogues and user manuals.

Key topics and requirements

• Scope: Applies to seals for dynamic applications (rotary, reciprocating and translational) where a more detailed but still simplified graphic is appropriate.
• Single representation rule: To avoid confusion, only one kind of simplification - either the general simplified (Part 1) or this detailed simplified method - should be used on any one drawing.
• Elements of representation: The standard defines basic graphic elements (see Table 1), for example:
  • Long continuous lines for static (fixed) elements and generating lines of sealing surfaces.
  • Diagonal or short lines to indicate dynamic sealing lips, dust lips, wipers and sealing direction (optional arrowheads).
  • Symbols for contactless seals (e.g., labyrinth-type T/U symbols).
• Placement convention: Seals are depicted in the drawing space above the axis.
• Illustrative tables and figures: Detailed simplified representations and examples are provided for common seal types (tables 2–4 and figures 1–5), including rotary shaft lip seals, piston rod seals, U‑cups, V‑rings, packing sets and labyrinth seals.

Practical applications and users

Who uses ISO 9222-2:

• Mechanical design engineers and CAD technicians creating assembly and installation drawings.
• Technical illustrators producing equipment catalogues, manuals and prospectuses.
• Seal manufacturers and suppliers for standardized product illustrations.
• Quality, procurement and maintenance teams relying on consistent drawing conventions.

Benefits:

• Consistency across technical documentation and supplier literature.
• Clarity of function (sealing direction, static vs dynamic elements) without over-detailing.
• Time savings compared with full-profile drawings while reducing misinterpretation.

Related standards

• ISO 9222-1 - Technical drawings - Seals for dynamic application - Part 1: General simplified representation
• ISO 6194-1 - Rotary shaft lip seals (referenced types)
• ISO 5597 - Piston rod seals and housings (reciprocating)
• ISO 6547 - Seal housings with bearing rings

Keywords: ISO 9222-2, EN ISO 9222-2, detailed simplified representation, seals for dynamic application, technical drawings, rotary shaft lip seals, labyrinth seals, assembly drawings, seal depiction standard.

Standards Content (Sample)

SLOVENSKI STANDARD
01-maj-1998
7HKQLþQHULVEH7HVQLOD]DGLQDPLþQRXSRUDERGHO3RHQRVWDYOMHQR
SULND]RYDQMHVSRGUREQRVWPL
Technical drawings - Seals of dynamic application - Part 2: Detailed simplified
representation (ISO 9222-2:1989)
Technische Zeichnungen - Dichtungen für dynamische Belastung - Teil 2: Detaillierte,
vereinfachte Darstellung (ISO 9222-2:1989)
Dessins techniques - Joints d'étanchéité pour application dynamique - Partie 2:
Représentation simplifiée particuliere (ISO 9222-2:1989)
Ta slovenski standard je istoveten z: EN ISO 9222-2:1994
ICS:
01.100.20 Konstrukcijske risbe Mechanical engineering
drawings
21.140 Tesnilke, mašilke Seals, glands
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

INTERNATIONAL
IS0
STANDARD 9222-2
First edition
1989-07-15
Technical drawings - Seals for dynamic
application -
Part 2 :
Detailed simplified representation
Dessins techniques - Joints d ‘6 tanchbite pour application d ynamique -
Partie 2 : Rep&en ta tion simplifihe particulikre
Reference number
IS0 9222-Z : 1989 (El
- ---
ISO 9733-2 : 1989 (El
Foreword
IS0 (the International Organization for Standardization) is a worldwide federation of
national standards bodies (IS0 member bodies). The work of preparing International
Standards is normally carried out through IS0 technical committees. Each member
body interested in a subject for which a technical committee has been established has
the right to be represented on that committee. International organizations, govern-
mental and non-governmental, in liaison with ISO, also take part in the work. IS0
collaborates closely with the International Electrotechnical Commission (IEC) on all
matters of electrotechnical standardization.
Draft International Standards adopted by the technical committees are circulated to
the member bodies for approval before their acceptance as International Standards by
the IS0 Council. They are approved in accordance with IS0 procedures requiring at
least 75 % approval by the member bodies voting.
International Standard IS0 9333-2 was prepared by Technical Committee lSO/TC 10,
Technical drawings.
IS0 9222 consists of the following parts, under the general title Technical drawings -
Seals for dynamic application :
-
Part I : General simplified representation
- Part 2 : Detailed simplified representation
@ IS0 1989
All rights reserved. No part of this publication may be reproduced or utilized in any form or by any
means, electronic or mechanical, including photocopying and microfilm, without permission in
writing from the publisher.
International Organization for Standardization
Case postale 56 l CH-1211 Geneve 20 l Switzerland
Printed in Switzerland
ii
is0 9333-2 : 1989 (E)
Introduction
IS0 9222 provides rules for the simplified representation of seals.
The principle of drawing practice is to depict the object to scale using lines. In
simplified representations, only essential features are shown, preferably in outline (in
order to save time and effort).
The degree of simplification depends on the kind of object represented, the scale of the
drawing and the purpose of the documentation. This means that either a general
simplified representation or a detailed one may be used. A detailed representation
shows more details of a seal, for example the configuration of lips.
In order to avo id misunde rstandings, only one kind of simplification, either general
the
or the detailed si mplif ied representation, shou Id be used on a drawing.
. . .
III
This page intentionally left blank

INTERNATIONAL STANDARD IS0 9222-2 : 1989 (E)
Technical drawings - Seals for dynamic application -
Part 2:
Detailed simplified representation
IS0 6194- 1 : 1982, Rotary shaft lip seals - Part 7 : Nominal
1 Scope
dimensions and tolerances.
This part of IS0 9222 specifies a detailed simplified represen-
IS0 6547 : 1981, Hydraulic fluid power - Cylinders - Piston
tation for various seals. This representation should be used in
seal housings incorporating bearing rings - Dimensions and
cases where it is not necessary to show the exact shape and
tolerances.
details of the seals, for example in assembly drawings.
IS0 9222-l : 1989, Technical drawings - Seals for dynamic
application - Part I : General simplified representation.
2 Normative references
The following standards contain provisions which, through 3 Method of representation
reference in this text, constitute provisions of this part of
IS0 9222. At the time of publication, the editions indicated
3.1 General rules
were valid. All standards are subject to revision, and parties to
agreements based on this part of IS0 9333 are encouraged to
See IS0 9333-l.
investigate the possibility of applying the most recent editions
of the standards indicated below. Members of IEC and IS0
maintain registers of current
...
