Technical drawings - Requirements for microcopying (ISO 6428:1982)

The rules of ISO 128, ISO 3098, ISO 5457 are expanded. The requirements will provide for high quality microforms with which legible enlargement copies can be made, and documents complying with them can also be reproduced by any other reprographic system. It is recommended that all drawing office documents be executed in accordance with this International Standard.

Technische Zeichnungen - Anforderungen für die Mikroverfilmung (ISO 6428:1982)

Die vorliegende internationale Norm legt die Anforderungen fest, die bei der Ausführung von technischen Zeichnungen und anderen von Konstruktionsbüros erstellten Originaldokumenten, welche mikroverfilmt werden sollen, zu beachten sind. Die Einhaltung dieser Anforderungen ergibt Mikrofilme hoher Qualität, von denen gut Rückvergrößerungen hergestellt werden können. Die Anwendung dieser Regeln wirkt sich auch bei anderen Reproduktionsmethoden günstig aus.

Dessins techniques - Conditions requises pour la micrographie (ISO 6428:1982)

Tehnične risbe - Zahteve za kopiranje na mikrofilm (ISO 6428:1982)

General Information

Status
Published
Publication Date
20-Jul-1999
Current Stage
6060 - Definitive text made available (DAV) - Publishing
Due Date
21-Jul-1999
Completion Date
21-Jul-1999

Buy Standard

Standard
EN ISO 6428:2002
English language
6 pages
sale 10% off
Preview
sale 10% off
Preview

e-Library read for
1 day

Standards Content (sample)

SLOVENSKI STANDARD
SIST EN ISO 6428:2002
01-februar-2002
7HKQLþQHULVEH=DKWHYH]DNRSLUDQMHQDPLNURILOP ,62
Technical drawings - Requirements for microcopying (ISO 6428:1982)
Technische Zeichnungen - Anforderungen für die Mikroverfilmung (ISO 6428:1982)
Dessins techniques - Conditions requises pour la micrographie (ISO 6428:1982)
Ta slovenski standard je istoveten z: EN ISO 6428:1999
ICS:
01.100.01 7HKQLþQRULVDQMHQDVSORãQR Technical drawings in
general
37.080 Uporabniške rešitve za Document imaging
predstavitev dokumentov applications
SIST EN ISO 6428:2002 en

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------
SIST EN ISO 6428:2002
---------------------- Page: 2 ----------------------
SIST EN ISO 6428:2002
---------------------- Page: 3 ----------------------
SIST EN ISO 6428:2002
---------------------- Page: 4 ----------------------
SIST EN ISO 6428:2002
---------------------- Page: 5 ----------------------
SIST EN ISO 6428:2002
---------------------- Page: 6 ----------------------
SIST EN ISO 6428:2002
Foreword

ISO (the International Organization for Standardization} is a worldwide federation of

national Standards bodies (ISO member bedies). The wsrk of developing International

Standards is carried out through ISO technical committees. Every member body

interested in a subject for which a technical committee has been authorized has the

right to be represented on that csmmittee. International organizations, governmental

and non-governmental, in liaison with ISO, also take part in the work.

Draft International Standards adopted by the technical committees are circulated ts

the member bodies for approval before their acceptance as International Standards by

the ISO Council.
International Standard ISO 6428 was developed by Technical Committee ISO/TC 10,
Technical drawings, and was circulated to the member bodies in February 1981~
lt has been approved by the member bodies of the following countries :
Austria Hungary Psland
Belgium India Romania
Canada Italy South Africa, Rep. of
China Japan Spain
Czechoslovakia Korea, Rep. of Sweden
Netherlands United Kingdom
Denmark
New Zealand USSR
Egypt, Arab Rep. of
Finland Norway

The member bsdies af the follo wing countries expressed disapprsval of the document

on technical grounds :
Austral ia
France
Switzerland
USA
0 International Organkation for Standardkation, 198%
Printed in Switzerland
---------------------- Page: 7 ----------------------
SIST EN ISO 6428:2002
ISO 6428-1982 (EI
INTERNATIONAL STANDARD
Requirements for microcopying
Technical drawings -
2 References
0 Introduction

Microcopying procedures allow the information contained in ISO 128, Technical drawings - General principles o f presen ta-

tion.
original technical drawings and other drawing Office
documents to be reduced to smaller sizes, thus facilitating

transport, handling and storage. ISO 3098/1, Technical drawings - Lettering - Part 7 : Cur-

rently used characters.
However, it should be noted that the possibility of obtaining

serviceable enlargements from a microform depends above all ISO 3272, Mcroftlming of technical drawings and other

dra wing Office documen ts -
on the good quality of the microform (sec ISO 3272/2) and this
condition tan be realized only if the original document is
Part 7 : Operating procedures. 1)
prepared in accordance with appropriate rules.
Part 2 : Quality criteria and control.
Usually, the original is a drawing or associated document
prepared manually, by a typewriter or other means (Plotter). lt
Part 3 : Unitized 35 mm micro film carriers.
may also be a combination of these methods.

The draughtsman already has at his disposal several lnterna- ISO 5457, Technical drawings - Sizes and layout of drawing

shee ts.
tional Standards (such as ISO 128, ISO 3098, ISO 5457) con-
taining general rules of execution which allow the establish-
ment of documents for good reproduction. Nevertheless, for
microcopying, these rules should be expanded.
3 Requirements of execution
The purpose of this International Standard is to compile in one
document the rules to be observed when executing original
3.1 Drawing sheets
documents allowing for the establishment of microforms
yielding legible enlargement copies.
3.1.1 Blanks or pre-printed sheets for drawings or other
Due to the fact that the instructions of this International Stan-
documents may be transparent, translucid or opaque, but shall

dard are more extensive than those for other methods of preferably be matt on the face used for drafting and/or letter-

reproduction, it follows that documents complying with the re-
ing. Their quality shall be Chosen in view of obtaining the best
quirements for microcopying tan also be reproduced without
possible contrast between background and lines (see 3.2.1).
difficulty by any other reprographic System.
NOTE - Due to its good qualities relating to dimensional stability,
durability, erasability and draftability, polyester drafting film (minimum
thickness 76 vm) is superior to Paper.
1 Scope and field of application
This International Standard specifies the requirements to be
3.1.2 The sizes to be used shall comply with those specified in
observed when executing original technical drawings and other
ISO 5457.
drawing Office documents which are to be microcopied. These
requirements will provide for high quality microforms with
3.1.3 If adhesive overlays are to be used on the original docu-
which legible enlargement copies tan be made.
ment, consideration shall be given to the effects of dust
accumulation and
...
