General Information
Relations
Standards Content (Sample)
SLOVENSKI STANDARD
SIST EN IEC 61010-2-012:2022/A11:2022
01-julij-2022
Varnostne zahteve za električno opremo za meritve, nadzor in laboratorijsko
uporabo - 2-012. del: Posebne zahteve za opremo za klimatska in okoljska
preskušanja ter drugo opremo za uravnavanje temperature - Dopolnilo A11
Safety requirements for electrical equipment for measurement, control and laboratory
use - Part 2-012: Particular requirements for climatic and environmental testing and other
temperature conditioning equipment
Sicherheitsbestimmungen für elektrische Mess-, Steuer-, Regel- und Laborgeräte - Teil 2
-012: Besondere Anforderungen an Klima- und Umwelttestgeräte und andere
Temperatur-Konditionierungsgeräte
Règles de sécurité pour appareils électriques de mesurage, de régulation et de
laboratoire - Partie 2-012: Exigences particulières pour les appareils d'essais climatiques
et d'environnement, et autres appareils de conditionnement de température
Ta slovenski standard je istoveten z: EN IEC 61010-2-012:2022/A11:2022
ICS:
19.040 Preskušanje v zvezi z Environmental testing
okoljem
19.080 Električno in elektronsko Electrical and electronic
preskušanje testing
71.040.10 Kemijski laboratoriji. Chemical laboratories.
Laboratorijska oprema Laboratory equipment
SIST EN IEC 61010-2-012:2022/A11:2022 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
---------------------- Page: 1 ----------------------
SIST EN IEC 61010-2-012:2022/A11:2022
---------------------- Page: 2 ----------------------
SIST EN IEC 61010-2-012:2022/A11:2022
EUROPEAN STANDARD EN IEC 61010-2-
012:2022/A11
NORME EUROPÉENNE
EUROPÄISCHE NORM
April 2022
ICS 19.080
English Version
Safety requirements for electrical equipment for measurement,
control and laboratory use - Part 2-012: Particular requirements
for climatic and environmental testing and other temperature
conditioning equipment
Règles de sécurité pour appareils électriques de mesurage, Sicherheitsbestimmungen für elektrische Mess-, Steuer-,
de régulation et de laboratoire - Partie 2-012: Exigences Regel- und Laborgeräte - Teil 2-012: Besondere
particulières pour les appareils d'essais climatiques et Anforderungen an Klima- und Umwelttestgeräte und andere
d'environnement, et autres appareils de conditionnement de Temperatur-Konditionierungsgeräte
température
This amendment A11 modifies the European Standard EN IEC 61010-2-012:2022; it was approved by CENELEC on 2022-03-28.
CENELEC members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this
amendment the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This amendment exists in three official versions (English, French, German). A version in any other language made by translation under the
responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the same status as
the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Turkey and the United Kingdom.
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2022 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
Ref. No. EN IEC 61010-2-012:2022/A11:2022 E
---------------------- Page: 3 ----------------------
SIST EN IEC 61010-2-012:2022/A11:2022
EN IEC 61010-2-012:2022/A11:2022 (E)
Contents
European foreword . 3
1 Addition to Clause 2, “Normative references” . 4
2 Modification to 5.4.3, “Equipment installation” . 5
3 Modifications to Clause 11, “Protection against HAZARDS from fluids and solid
foreign objects” . 5
4 Modification to Annex CC, “Safety requirements for components and piping”. 5
5 Addition of Annex ZA, “Normative references to international publications with
their corresponding European publications” . 10
Annex ZA (normative) Normative references to international publications with their
corresponding European publications . 11
6 Addition of Annex ZZ, “Relationship between this European standard and the
safety objectives of Directive 2014/35/EU [2014 OJ L96] aimed to be covered” . 13
Annex ZZ (informative) Relationship between this European standard and the safety
objectives of Directive 2014/35/EU [2014 OJ L96] aimed to be covered . 14
2
---------------------- Page: 4 ----------------------
SIST EN IEC 61010-2-012:2022/A11:2022
EN IEC 61010-2-012:2022/A11:2022 (E)
European foreword
This document (EN IEC 61010-2-012:2022/A11:2022) has been prepared by CLC/TC 66X “Safety of
measuring, control, and laboratory equipment”.
The following dates are fixed:
• latest date by which this document has to be (dop) 2023–03–28
implemented at national level by publication of
an identical national standard or by
endorsement
• latest date by which the national standards (dow) 2025–03–28
conflicting with this document have to be
withdrawn
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CENELEC shall not be held responsible for identifying any or all such patent rights.
This document amends EN IEC 61010-2-012:2022.
This document has been prepared under a Standardization Request given to CENELEC by the
European Commission and the European Free Trade Association, and supports essential requirements
of EU Directive(s) / Regulation(s).
For relationship with EU Directive(s) / Regulation(s), see informative Annex ZZ, which is an integral part
of this document.
Any feedback and questions on this document should be directed to the users’ national committee. A
complete listing of these bodies can be found on the CENELEC website.
3
---------------------- Page: 5 ----------------------
SIST EN IEC 61010-2-012:2022/A11:2022
EN IEC 61010-2-012:2022/A11:2022 (E)
1 Addition to Clause 2, “Normative references”
Add the following normative references to Clause 2:
“
EN 809, Pumps and pump units for liquids - Common safety requirements
EN 837-1, Pressure gauges - Part 1: Bourdon tube pressure gauges - Dimensions, metrology,
requirements and testing
EN 837-2, Pressure gauges - Part 2: Selection and installation recommendations for pressure gauges
EN 837-3, Pressure gauges - Part 3: Diaphragm and capsule pressure gauges - Dimensions, metrology,
requirements and testing
EN 1736, Refrigerating systems and heat pumps - Flexible pipe elements, vibration isolators, expansion
joints and non-metallic tubes - Requirements, design and installation
EN 1779:1999, Non-destructive testing - Leak testing - Criteria for method and technique selection
EN 12178, Refrigerating systems and heat pumps - Liquid level indicating devices - Requirements,
testing and marking
EN 12263, Refrigerating systems and heat pumps - Safety switching devices for limiting the pressure -
Requirements and tests
EN 12284, Refrigerating systems and heat pumps - Valves - Requirements, testing and marking
EN 12693, Refrigerating systems and heat pumps - Safety and environmental requirements - Positive
displacement refrigerant compressors
EN 13136, Refrigerating systems and heat pumps - Pressure relief devices and their associated piping
- Methods for calculation
EN 13445-1, Unfired pressure vessels - Part 1: General
EN 13445-2, Unfired pressure vessels - Part 2: Materials
EN 13445-3, Unfired pressure vessels - Part 3: Design
EN 13445-4, Unfired pressure vessels - Part 4: Fabrication
EN 13445-5, Unfired pressure vessels - Part 5: Inspection and testing
EN 13445-6, Unfired pressure vessels - Part 6: Requirements for the design and fabrication of pressure
vessels and pressure parts constructed from spheroidal graphite cast iron
EN 13445-8, Unfired pressure vessels - Part 8: Additional requirements for pressure vessels of
aluminium and aluminium alloys
EN 13445-10, Unfired pressure vessels - Part 10: Additional requirements for pressure vessels of nickel
and nickel alloys
EN 13480-1, Metallic industrial piping - Part 1: General
EN 13480-2, Metallic industrial piping - Part 2: Materials
EN 13480-3, Metallic industrial piping - Part 3: Design and calculation
4
---------------------- Page: 6 ----------------------
SIST EN IEC 61010-2-012:2022/A11:2022
EN IEC 61010-2-012:2022/A11:2022 (E)
EN 13480-4, Metallic industrial piping - Part 4: Fabrication and installation
EN 13480-5, Metallic industrial piping - Part 5: Inspection and testing
EN 13480-6, Metallic industrial piping - Part 6: Additional requirements for buried piping
EN 13480-8, Metallic industrial piping - Part 8: Additional requirements for aluminium and aluminium
alloy piping
EN 14276-1, Pressure equipment for refrigerating systems and heat pumps - Part 1: Vessels - General
requirements
EN 14276-2, Pressure equipment for refrigerating systems and heat pumps - Part 2: Piping - General
requirements
EN 61770, Electric appliances connected to the water mains - Avoidance of backsiphonage and failure
of hose-sets
IEC 60204-1, Safety of machinery - Electrical equipment of machines - Part 1: General requirements
ISO 4126-1, Safety devices for protection against excessive pressure — Part 1: Safety valves
ISO 4126-2, Safety devices for protection against excessive pressure — Part 2: Bursting disc safety
devices
2 Modification to 5.4.3, “Equipment installation”
Add the following item after n):
“o) Instructions on the prevention of back-siphonage into potable water systems (see 11.101)”
3 Modifications to Clause 11, “Protection against HAZARDS from fluids and
solid foreign objects”
In 11.1, “General”, delete the added text after the first conformity statement.
Add the following subclause:
“11.101 Protection of hot and cold water services
Back-siphonage from the equipment to the potable water services shall be prevented by means meeting
the relevant requirements of EN 61770. Attention is drawn to the existence of national and local
regulations. If the means are to be provided by the RESPONSIBLE BODY, this shall be stated in the
manufacturer’s installation instructions.
Conformity is checked by inspection and by examination of the manufacturer’s instructions.”
4 Modification to Annex CC, “Safety requirements for components and
piping”
Replace Annex CC by the following text:
“
5
---------------------- Page: 7 ----------------------
SIST EN IEC 61010-2-012:2022/A11:2022
EN IEC 61010-2-012:2022/A11:2022 (E)
Annex CC
(normative)
Safety requirements for components and piping
The sealed system components can be considered pressure vessels as stated in the Pressure
Equipment Directive (PED) 2014/68/EU according to the classification in Table CC.1 and Table CC.2. If
the components or piping are classified as a Category II or a higher pressure vessel as stated in the
PED, then the requirements of Table CC.3 shall apply including the use of a Notified Body to the PED.
Table CC.1 — Parameters of pressure vessels according to EN 14276-1
PS × V
a
Fluid Nature V (L) Category/Article
PS (bar)
(bar × L)
if and and and and then
Not subjected to PED
≤ 0,5 - -
b
c
≤ 1 -
Art. 4.3
c
≤ 25
Art. 4.3
> 0,5 and ≤ 200
> 25 and ≤ 50 I
> 1
Gas
> 50 and ≤ 200 II
> 200 and ≤ 1 000 ≤ 1 - III
> 200 and
III
≤ 1 000
≤ 1 000 > 1
> 1 000 IV
Group 1
> 1 000 - - IV
Not subjected to PED
≤ 0,5 - -
b
c
≤ 1 -
Art. 4.3
> 0,5 and ≤ 500
c
≤ 200
Art. 4.3
d
Liquid
> 0,5 and ≤ 10 I
> 1 > 200
> 10 and ≤ 500 II
> 500 < 1 - II
> 500 > 1 - III
6
---------------------- Page: 8 ----------------------
SIST EN IEC 61010-2-012:2022/A11:2022
EN IEC 61010-2-012:2022/A11:2022 (E)
Not subjected to
≤ 0,5 - -
b
PED
c
≤ 1 -
Art. 4.3
c
≤ 50
Art. 4.3
> 0,5 and ≤ 1 000
> 50 and ≤ 200 I
> 1
> 200 and
II
Gas
≤ 1 000
≤ 1 - III
> 1 000 and
> 1 000 and
≤ 3 000
III
≤ 3 000
> 0,5 and ≤ 4 > 1 000 III
Group 2
> 1
> 4 > 3 000 IV
> 3 000 - - IV
Not subjected to PED
≤ 0,5 - -
b
c
> 0,5 and ≤ 10 - -
Art. 4.3
c
> 10 and ≤ 1 000 ≤ 10 -
Art. 4.3
d
Liquid
c
> 10 and ≤ 1 000 > 10 ≤ 10 000
Art. 4.3
> 10 and ≤ 500 - > 10 000 I
> 1 000 < 10 - I
> 500 > 10 > 10 000 II
a
1 bar = 0,1 Mpa.
b
PED = Pressure Equipment Directive.
c
Art. 4.3 = reference to Article 4.3 of the Pressure Equipment Directive.
d
Liquids are considered to be fluids having a vapour pressure of not more than 0,5 bar above the normal
atmospheric pressure (1 013 mbar).
7
---------------------- Page: 9 ----------------------
SIST EN IEC 61010-2-012:2022/A11:2022
EN IEC 61010-2-012:2022/A11:2022 (E)
Table CC.2 — Parameters of piping according to EN 14276-2
PS × DN (bar)
a
Fluid Nature DN Category/Article
PS (bar)
a
if and and And and then
Not subjected to PED
≤ 0,5 - -
b
c
≤ 25 -
Art. 4.3
Gas
> 25 and ≤ 100 ≤ 1 000 I
> 0,5
> 1 000 and
> 100 and ≤ 350 II
≤ 3 500
> 350 > 3 500 III
Group 1
Not subjected to PED
≤ 0,5 - -
b
c
≤ 25 -
Art. 4.3
> 0,5
c
d - ≤ 2 000
Art. 4.3
Liquid
> 0,5 and ≤ 10 - I
> 2 000
> 10 and ≤ 500 II
> 25
> 500 - III
Not subjected to PED
≤ 0,5 - -
b
c
≤ 32 -
Art. 4.3
c
- ≤ 1 000
Art. 4.3
Gas
> 1 000 and
> 32 and ≤ 100 I
> 0,5
≤ 3 500
> 3 500 and
> 100 and ≤ 250 II
≤ 5 000
Group 2
> 250 > 5 000 III
Not subjected to PED
≤ 0,5 - -
b
c
> 0,5 and ≤ 10 - -
Art. 4.3
c
- - ≤ 5 000
d Art. 4.3
Liquid
c
- ≤ 200 -
Art. 4.3
> 10 and ≤ 500 > 5 000 I
> 200
> 500 - II
a
1 bar = 0,1 Mpa.
b
PED = Pressure
...
SLOVENSKI STANDARD
SIST FprEN IEC 61010-2-
012:2019/oprAA:2020
01-november-2020
Varnostne zahteve za električno opremo za meritve, nadzor in laboratorijsko
uporabo - 2-012. del: Posebne zahteve za opremo za klimatska in okoljska
preskušanja ter drugo opremo za uravnavanje temperature
Safety requirements for electrical equipment for measurement, control and laboratory
use - Part 2-012: Particular requirements for climatic and environmental testing and other
temperature conditioning equipment
Sicherheitsbestimmungen für elektrische Mess-, Steuer-, Regel- und Laborgeräte - Teil 2
-012: Besondere Anforderungen an Klima- und Umwelttestgeräte und andere
Temperatur-Konditionierungsgeräte
Règles de sécurité pour appareils électriques de mesurage, de régulation et de
laboratoire - Partie 2-012: Exigences particulières pour les appareils d'essais climatiques
et d'environnement, et autres appareils de conditionnement de température
Ta slovenski standard je istoveten z: FprEN IEC 61010-2-012:2019/prAA
ICS:
19.040 Preskušanje v zvezi z Environmental testing
okoljem
19.080 Električno in elektronsko Electrical and electronic
preskušanje testing
71.040.10 Kemijski laboratoriji. Chemical laboratories.
Laboratorijska oprema Laboratory equipment
SIST FprEN IEC 61010-2- en,fr,de
012:2019/oprAA:2020
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
---------------------- Page: 1 ----------------------
SIST FprEN IEC 61010-2-012:2019/oprAA:2020
---------------------- Page: 2 ----------------------
SIST FprEN IEC 61010-2-012:2019/oprAA:2020
EUROPEAN STANDARD DRAFT
FprEN IEC 61010-2-
NORME EUROPÉENNE
012:2019
EUROPÄISCHE NORM
prAA
September 2020
ICS
English Version
Safety requirements for electrical equipment for measurement,
control and laboratory use - Part 2-012: Particular requirements
for climatic and environmental testing and other temperature
conditioning equipment
Règles de sécurité pour appareils électriques de mesurage, Sicherheitsbestimmungen für elektrische Mess-, Steuer-,
de régulation et de laboratoire - Partie 2-012: Exigences Regel- und Laborgeräte - Teil 2-012: Besondere
particulières pour les appareils d'essais climatiques et Anforderungen an Klima- und Umwelttestgeräte und andere
d'environnement, et autres appareils de conditionnement de Temperatur-Konditionierungsgeräte
température
This draft amendment prAA, if approved, will modify the European Standard FprEN IEC 61010-2-012:2019; it is submitted to CENELEC
members for enquiry.
Deadline for CENELEC: 2020-11-27.
It has been drawn up by CLC/TC 66X.
If this draft becomes an amendment, CENELEC members are bound to comply with the CEN/CENELEC Internal Regulations which
stipulate the conditions for giving this amendment the status of a national standard without any alteration.
This draft amendment was established by CENELEC in three official versions (English, French, German).
A version in any other language made by translation under the responsibility of a CENELEC member into its own language and notified to
the CEN-CENELEC Management Centre has the same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Turkey and the United Kingdom.
Recipients of this draft are invited to submit, with their comments, notification of any relevant patent rights of which they are aware and to
provide supporting documentation.
Warning : This document is not a European Standard. It is distributed for review and comments. It is subject to change without notice and
shall not be referred to as a European Standard.
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2020 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
---------------------- Page: 3 ----------------------
SIST FprEN IEC 61010-2-012:2019/oprAA:2020
EN IEC 61010-2-012:2019/prAA:2020 (E)
European foreword
This document (FprEN 61010-2-012:2019/prAA:2020) has been prepared by CLC/TC 66X “Safety of
measuring, control, and laboratory equipment”.
This document is currently submitted to the Enquiry.
The following dates are proposed:
• latest date by which the existence of this (doa) dor + 6 months
document has to be announced at national
level
• latest date by which this document has to be (dop) dor + 12 months
implemented at national level by publication of
an identical national standard or by
endorsement
• latest date by which the national standards (dow) dor + 36 months
conflicting with this document have to be (to be confirmed or
withdrawn modified when voting)
This document amends FprEN 61010-2-012:2019.
This document has been prepared under a mandate given to CENELEC by the European Commission
and the European Free Trade Association, and supports essential requirements of EU Directive(s).
For the relationship with EU Directive(s) see informative Annex ZZ, which is an integral part of this
document.
2
---------------------- Page: 4 ----------------------
SIST FprEN IEC 61010-2-012:2019/oprAA:2020
EN IEC 61010-2-012:2019/prAA:2020 (E)
1 Addition to Clause 2, “Normative references”
Add the following normative references to Clause 2:
"EN 809, Pumps and pump units for liquids - Common safety requirements
EN 837-1, Pressure gauges - Part 1: Bourdon tube pressure gauges - Dimensions, metrology,
requirements and testing
EN 837-2, Pressure gauges - Part 2: Selection and installation recommendations for pressure gauges
EN 837-3, Pressure gauges - Part 3: Diaphragm and capsule pressure gauges - Dimensions,
metrology, requirements and testing
EN 1736, Refrigerating systems and heat pumps - Flexible pipe elements, vibration isolators,
expansion joints and non-metallic tubes - Requirements, design and installation
EN 1779:1999, Non-destructive testing - Leak testing - Criteria for method and technique selection
EN 12178, Refrigerating systems and heat pumps - Liquid level indicating devices - Requirements,
testing and marking
EN 12263, Refrigerating systems and heat pumps - Safety switching devices for limiting the pressure -
Requirements and tests
EN 12284, Refrigerating systems and heat pumps - Valves - Requirements, testing and marking
EN 12693, Refrigerating systems and heat pumps - Safety and environmental requirements - Positive
displacement refrigerant compressors
EN 13136, Refrigerating systems and heat pumps - Pressure relief devices and their associated piping
- Methods for calculation
EN 13445 (series), Unfired pressure vessels
EN 13480 (series), Metallic industrial piping
EN 14276-1, Pressure equipment for refrigerating systems and heat pumps - Part 1: Vessels -
General requirements
EN 14276-2, Pressure equipment for refrigerating systems and heat pumps - Part 2: Piping - General
requirements
EN 61770, Electric appliances connected to the water mains - Avoidance of backsiphonage and failure
of hose-sets
IEC 60204-1, Safety of machinery - Electrical equipment of machines - Part 1: General requirements
ISO 4126-1, Safety devices for protection against excessive pressure — Part 1: Safety valves
ISO 4126-2, Safety devices for protection against excessive pressure — Part 2: Bursting disc safety
devices"
2 Modification to 5.4.3, “Equipment installation”
Add the following item after n):
“o) Instructions on the prevention of back-siphonage into potable water systems (see 11.101)”
3
---------------------- Page: 5 ----------------------
SIST FprEN IEC 61010-2-012:2019/oprAA:2020
EN IEC 61010-2-012:2019/prAA:2020 (E)
3 Modification to 6.8.3.1, “The a.c. voltage test”
Replace the first sentence by the following sentence:
“The voltage tester shall be capable of maintaining the test voltage throughout the test within ± 5 % of
the specified value.”
4 Modifications to Clause 11, “Protection against HAZARDS from fluids and
solid foreign objects”
In 11.1, “General”, delete the added text after the first conformity statement.
Add the following subclause:
“11.101 Protection of hot and cold water services
Back-siphonage from the equipment to the potable water services shall be prevented by means
meeting the relevant requirements of EN 61770. Attention is drawn to the existence of national and
local regulations. If the means are to be provided by the RESPONSIBLE BODY, this shall be stated in the
manufacturer’s installation instructions.
Conformity is checked by inspection and by examination of the manufacturer’s instructions.”
5 Modification to Annex CC, “Safety requirements for components and
piping”
Replace Annex CC by the following text:
"Annex CC
(normative)
Safety requirements for components and piping
The sealed system components can be considered pressure vessels as stated in the Pressure
Equipment Directive (PED) 2014/68/EU according to the classification in Table CC.1 and Table CC.2.
If the components or piping are classified as a Category II or a higher pressure vessel as stated in the
PED, then the requirements of Table CC.3 shall apply including the use of a Notified Body to the PED.
Table CC.1 — Parameters of pressure vessels according to EN 14276-1
PS × V
a
Fluid Nature V (L) Category/Article
PS (bar)
(bar × L)
if and and and and then
Not subjected to
≤ 0,5 - -
b
PED
c
≤ 1 -
Art. 4.3
c
≤ 25
Art. 4.3
> 0,5 and ≤ 200
> 25 and ≤ 50 I
> 1
Group 1 Gas
> 50 and ≤ 200 II
> 200 and ≤ 1
≤ 1 - III
000
> 200 and
III
≤ 1 000
≤ 1 000 > 1
> 1 000 IV
4
---------------------- Page: 6 ----------------------
SIST FprEN IEC 61010-2-012:2019/oprAA:2020
EN IEC 61010-2-012:2019/prAA:2020 (E)
PS × V
a
Fluid Nature V (L) Category/Article
PS (bar)
(bar × L)
if and and and and then
> 1 000 - - IV
Not subjected to
≤ 0,5 - -
b
PED
c
≤ 1 -
Art. 4.3
> 0,5 and ≤ 500
c
≤ 200
Art. 4.3
d
Liquid
> 0,5 and ≤ 10 I
> 1 > 200
> 10 and ≤ 500 II
> 500 < 1 - II
> 500 > 1 - III
Not subjected to
≤ 0,5 - -
b
PED
c
≤ 1 -
Art. 4.3
c
≤ 50
Art. 4.3
> 0,5 and ≤ 1 000
> 50 and ≤ 200 I
> 1
> 200 and
II
Gas
≤ 1 000
≤ 1 - III
> 1 000 and
> 1 000 and
≤ 3 000
III
≤ 3 000
> 0,5 and ≤ 4 > 1 000 III
Group 2
> 1
> 4 > 3 000 IV
> 3 000 - - IV
Not subjected to
≤ 0,5 - -
b
PED
c
> 0,5 and ≤ 10 - -
Art. 4.3
c
> 10 and ≤ 1 000 ≤ 10 -
Art. 4.3
d
Liquid
c
> 10 and ≤ 1 000 > 10 ≤ 10 000
Art. 4.3
> 10 and ≤ 500 - > 10 000 I
> 1 000 < 10 - I
> 500 > 10 > 10 000 II
a
1 bar = 0,1 Mpa.
b
PED = Pressure Equipment Directive
c
Art. 4.3 = reference to Article 4.3 of the Pressure Equipment Directive
d
Liquids are considered to be fluids having a vapour pressure of not more than 0,5 bar above the normal
atmospheric pressure (1 013 mbar)
5
---------------------- Page: 7 ----------------------
SIST FprEN IEC 61010-2-012:2019/oprAA:2020
EN IEC 61010-2-012:2019/prAA:2020 (E)
Table CC.2 — Parameters of piping according to EN 14276-2
PS × DN (bar)
a
Fluid Nature DN Category/Article
PS (bar)
a
if and and And and then
Not subjected to
≤ 0,5 - -
b
PED
c
≤ 25 -
Art. 4.3
Gas
> 25 and ≤ 100 ≤ 1 000 I
> 0,5
> 1 000 and
> 100 and ≤ 350 II
≤ 3 500
> 350 > 3 500 III
Group 1
Not subjected to
≤ 0,5 - -
b
PED
c
≤ 25 -
Art. 4.3
> 0,5
d c
- ≤ 2 000
Liquid Art. 4.3
> 0,5 and ≤ 10 - I
> 2 000
> 10 and ≤ 500 II
> 25
> 500 - III
Not subjected to
≤ 0,5 - -
b
PED
c
≤ 32 -
Art. 4.3
c
- ≤ 1 000
Art. 4.3
Gas
> 1 000 and
> 32 and ≤ 100 I
> 0,5
≤ 3 500
> 3 500 and
> 100 and ≤ 250 II
≤ 5 000
Group 2
> 250 > 5 000 III
Not subjected to
≤ 0,5 - -
b
PED
c
> 0,5 and ≤ 10 - -
Art. 4.3
c
d - - ≤ 5 000
Art. 4.3
Liquid
c
- ≤ 200 -
Art. 4.3
> 10 and ≤ 500 > 5 000 I
> 200
> 500 - II
a
1 bar = 0,1 Mpa.
b
PED = Pressure Equipment Directive.
c
Art. 4.3 = reference to Article 4.3 of the Pressure Equipment Directive.
d
Liquids are considered to be fluids having a vapour pressure of not more than 0,5 bar above the normal
atmospheric pressure (1 013 mbar).
6
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
