SIST EN ISO 10628-1:2015
INTERNATIONAL STANDARD ISO 10628-1:2014(E)
Diagrams for the chemical and petrochemical industry —
Part 1:
Specification of diagrams
1 Scope
This part of ISO 10628 specifies the classification, content, and representation of flow diagrams. In
addition, it lays down drafting rules for flow diagrams for chemical and petrochemical industry.
This International Standard does not apply to electrical engineering diagrams. This part of ISO 10628 is
a collective application standard of ISO 15519.
2 Normative references
The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any amendments) applies.
ISO 128 (all parts), Technical drawings — General principles of presentation
ISO 7200, Technical product documentation — Data fields in title blocks and document headers
ISO 10209, Technical product documentation — Vocabulary — Terms relating to technical drawings,
product definition and related documentation
ISO 14617 (all parts), Graphical symbols for diagrams
ISO 15519 (all parts), Specification for diagrams for process industry
ISO 80000-1, Quantities and units — Part 1: General
IEC 62424:2008, Representation of process control engineering requests in P&I diagrams and data exchange
between P&ID tools and PCE-CAE tools
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 10209, ISO 14617 (all parts),
ISO 15519 (all parts), and IEC 62424 apply.
4 Classification, information content, and presentation of flow diagrams
4.1 General
Flow diagrams show the structure and function of the process plants and are part of the entire set
of technical documents which are required for planning, assembly, construction, management,
commissioning, operation, maintenance, shutdown, and decommissioning of a plant.
Flow diagrams are a means by which information is exchanged between parties involved in the
construction, assembly, operation, and maintenance of such process plants. General rules and
recommendations for preparation of flow diagrams are given in ISO 15519.
© ISO 2014 – All rights reserved 1
---------------------- Page: 11 ----------------------
SIST EN ISO 10628-1:2015
ISO 10628-1:2014(E)
Depending on the information required, a distinction should be made between block diagrams, process
flow diagrams, and piping and instrumentation diagrams (P&ID).
Each particular type of flow diagram shall take the functional requirements into consideration.
The graphical presentation shall conform to the rules set down in Clause 5. Flow routes and flow
directions shall be indicated by lines and arrows.
All equipment, machinery, flow lines (e.g. pipelines, transport routes), and valves shall be represented
in accordance with ISO 10628-2.
The measuring, control, and regulating tasks shall be represented in accordance with IEC 62424.
Designation of objects in diagrams could be performed using reference designation according to
IEC 81346 series.
4.2 Block diagrams
4.2.1 General representation rules
The block diagram depicts a process or process plant in simplified form by means of rectangular frames
which are interconnected by flow lines (see Figures A.1 and A.2).
The rectangular frames can represent the following:
— processes;
— process steps;
— unit operations;
— process plants or groups of process plants;
— plant sections;
— equipment.
The flow lines can represent streams of materials or energy flows.
4.2.2 Basic information
The block diagram shall contain at least the following information:
a) denomination of frames;
b) denomination of ingoing and
...
SLOVENSKI STANDARD
oSIST prEN ISO 10628-1:2013
01-april-2013
Sheme za kemijsko in petrokemijsko industrijo - 1. del: Opredelitev shem (ISO/DIS
10628-1:2013)
Diagrams for the chemical and petrochemical industry - Part 1: Specification of diagrams
(ISO/DIS 10628-1:2013)
Schémas de procédé pour l'industrie chimique et pétrochimique - Partie 1: Spécification
des schémas de procédé (ISO/DIS 10628-1:2013)
Ta slovenski standard je istoveten z: prEN ISO 10628-1
ICS:
01.080.30 *UDILþQLVLPEROL]DXSRUDERY Graphical symbols for use on
ULVEDKGLDJUDPLKQDþUWLK mechanical engineering and
]HPOMHYLGLKYVWURMQLãWYXLQ construction drawings,
JUDGEHQLãWYXWHUYXVWUH]QL diagrams, plans, maps and in
WHKQLþQLSURL]YRGQL relevant technical product
GRNXPHQWDFLML documentation
71.020 Proizvodnja v kemijski Production in the chemical
industriji industry
oSIST prEN ISO 10628-1:2013 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
---------------------- Page: 1 ----------------------
oSIST prEN ISO 10628-1:2013
---------------------- Page: 2 ----------------------
oSIST prEN ISO 10628-1:2013
EUROPEAN STANDARD
DRAFT
prEN ISO 10628-1 rev
NORME EUROPÉENNE
EUROPÄISCHE NORM
February 2013
ICS Will supersede EN ISO 10628:2000
English Version
Diagrams for the chemical and petrochemical industry - Part 1:
Specification of diagrams (ISO/DIS 10628-1:2013)
Schémas de procédé pour l'industrie chimique et
pétrochimique - Partie 1: Spécification des schémas de
procédé (ISO/DIS 10628-1:2013)
This draft European Standard is submitted to CEN members for parallel enquiry. It has been drawn up by the Technical Committee
CEN/SS F01.
If this draft becomes a European Standard, CEN members are bound to comply with the CEN/CENELEC Internal Regulations which
stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
This draft European Standard was established by CEN in three official versions (English, French, German). A version in any other language
made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management
Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania,
Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United
Kingdom.
Recipients of this draft are invited to submit, with their comments, notification of any relevant patent rights of which they are aware and to
provide supporting documentation.
Warning : This document is not a European Standard. It is distributed for review and comments. It is subject to change without notice and
shall not be referred to as a European Standard.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre: Avenue Marnix 17, B-1000 Brussels
© 2013 CEN All rights of exploitation in any form and by any means reserved Ref. No. prEN ISO 10628-1 rev:2013: E
worldwide for CEN national Members.
---------------------- Page: 3 ----------------------
oSIST prEN ISO 10628-1:2013
prEN ISO 10628-1:2013 (E)
Contents Page
Foreword . 3
2
---------------------- Page: 4 ----------------------
oSIST prEN ISO 10628-1:2013
prEN ISO 10628-1:2013 (E)
Foreword
This document (prEN ISO 10628-1:2013) has been prepared by Technical Committee ISO/TC 10 "Technical
product documentation".
This document is currently submitted to the parallel Enquiry.
This document will supersede EN ISO 10628:2000.
Endorsement notice
The text of ISO/DIS 10628-1:2013 has been approved by CEN as prEN ISO 10628-1:2013 without any
modification.
3
---------------------- Page: 5 ----------------------
oSIST prEN ISO 10628-1:2013
---------------------- Page: 6 ----------------------
oSIST prEN ISO 10628-1:2013
DRAFT INTERNATIONAL STANDARD ISO/DIS 10628-1
ISO/TC 10/SC 10 Secretariat: DIN
Voting begins on Voting terminates on
2012-12-13 2013-05-13
INTERNATIONAL ORGANIZATION FOR STANDARDIZATION • МЕЖДУНАРОДНАЯ ОРГАНИЗАЦИЯ ПО СТАНДАРТИЗАЦИИ • ORGANISATION INTERNATIONALE DE NORMALISATION
Diagrams for the chemical and petrochemical industry
Part 1:
Specification of diagrams
Schémas de procédé pour l'industrie chimique et pétrochimique —
Partie 1: Spécification des schémas de procédé
[Revision of first edition (ISO 10628:1997)]
ICS 01.110; 71.020; 75.020
ISO/CEN PARALLEL PROCESSING
This draft has been developed within the International Organization for Standardization (ISO), and
processed under the ISO-lead mode of collaboration as defined in the Vienna Agreement.
This draft is hereby submitted to the ISO member bodies and to the CEN member bodies for a parallel
five-month enquiry.
Should this draft be accepted, a final draft, established on the basis of comments received, will be
submitted to a parallel two-month approval vote in ISO and formal vote in CEN.
To expedite distribution, this document is circulated as received from the committee
secretariat. ISO Central Secretariat work of editing and text composition will be undertaken at
publication stage.
Pour accélérer la distribution, le présent document est distribué tel qu'il est parvenu du
secrétariat du comité. Le travail de rédaction et de composition de texte sera effectué au
Secrétariat central de l'ISO au stade de publication.
THIS DOCUMENT IS A DRAFT CIRCULATED FOR COMMENT AND APPROVAL. IT IS THEREFORE SUBJECT TO CHANGE AND MAY NOT BE
REFERRED TO AS AN INTERNATIONAL STANDARD UNTIL PUBLISHED AS SUCH.
IN ADDITION TO THEIR EVALUATION AS BEING ACCEPTABLE FOR INDUSTRIAL, TECHNOLOGICAL, COMMERCIAL AND USER PURPOSES, DRAFT
INTERNATIONAL STANDARDS MAY ON OCCASION HAVE TO BE CONSIDERED IN THE LIGHT OF THEIR POTENTIAL TO BECOME STANDARDS TO
WHICH REFERENCE MAY BE MADE IN NATIONAL REGULATIONS.
RECIPIENTS OF THIS DRAFT ARE INVITED TO SUBMIT, WITH THEIR COMMENTS, NOTIFICATION OF ANY RELEVANT PATENT RIGHTS OF WHICH
THEY ARE AWARE AND TO PROVIDE SUPPORTING DOCUMENTATION.
© International Organization for Standardization, 2012
---------------------- Page: 7 ----------------------
oSIST prEN ISO 10628-1:2013
ISO/DIS 10628-1
Copyright notice
This ISO document is a Draft International Standard and is copyright-protected by ISO. Except as permitted
under the applicable laws of the user’s country, neither this ISO draft nor any extract from it may be
reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic,
photocopying, recording or otherwise, without prior written permission being secured.
Requests for permission to reproduce should be addressed to either ISO at the address below or ISO’s
member body in the country of the requester.
ISO copyright office
Case postale 56 • CH-1211 Geneva 20
Tel. + 41 22 749 01 11
Fax + 41 22 749 09 47
E-mail copyright@iso.org
Web www.iso.org
Reproduction may be subject to royalty payments or a licensing agreement.
Violators may be prosecuted.
ii © ISO 2012 – All rights reserved
---------------------- Page: 8 ----------------------
oSIST prEN ISO 10628-1:2013
ISO/DIS 10628-1
Contents Page
Foreword . iv
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 1
4 Classification, information content and presentation of flow diagrams . 1
4.1 General . 1
4.2 Block diagrams . 2
4.2.1 General representation rules . 2
4.2.2 Basic information . 2
4.2.3 The block diagram shall contain at least the following information: . 2
4.2.4 Additional information . 2
4.3 Process flow diagrams . 3
4.3.1 General . 3
4.3.2 Basic information . 3
4.3.3 Additional information . 3
4.4 Piping and instrumentation diagrams (P&ID) . 4
4.4.1 General . 4
4.4.2 Basic information . 4
4.4.3 Additional information . 4
5 Drafting rules . 5
5.1 General . 5
5.1.1 Sheet sizes . 5
5.1.2 Title block . 5
5.2 Layout of flow diagrams . 5
5.3 Connecting lines . 5
5.3.1 Line widths . 5
5.3.2 Minimum space of parallel lines . 6
5.3.3 Flow direction . 6
5.3.4 Connections . 6
5.3.5 Connections of auxiliary system lines . 7
5.4 Inscription . 7
5.4.1 Type of lettering . 7
5.4.2 Height of lettering . 7
5.4.3 Lettering arrangement . 7
5.5 Scale . 8
5.6 Limits . 8
Annex A (informative) Examples of flow diagrams for process plants . 9
© ISO 2012 – All rights reserved iii
---------------------- Page: 9 ----------------------
oSIST prEN ISO 10628-1:2013
ISO/DIS 10628-1
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards bodies
(ISO member bodies). The work of preparing International Standards is normally carried out through ISO
technical committees. Each member body interested in a subject for which a technical committee has been
established has the right to be represented on that committee. International organizations, governmental and
non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the
International Electrotechnical Commission (IEC) on all matters of electrotechnical standardization.
International Standards are drafted in accordance with the rules given in the ISO/IEC Directives, Part 2.
The main task of technical committees is to prepare International Standards. Draft International Standards
adopted by the technical committees are circulated to the member bodies for voting. Publication as an
International Standard requires approval by at least 75 % of the member bodies casting a vote.
Attention is drawn to the possibility that some of the elements of this document may be the subject of patent
rights. ISO shall not be held responsible for identifying any or all such patent rights.
ISO 10628-1 was prepared by Technical Committee ISO/TC 10, Technical product documentation,
Subcommittee SC 10, Process plant documentation.
This second/third/. edition cancels and replaces the first/second/. edition (), [clause(s) / subclause(s) /
table(s) / figure(s) / annex(es)] of which [has / have] been technically revised.
ISO 10628 consists of the following parts, under the general title Diagrams for chemical and petrochemical
industry:
Part 1: Specifications of diagrams
Part 2: Graphical symbols
iv © ISO 2012 – All rights reserved
---------------------- Page: 10 ----------------------
oSIST prEN ISO 10628-1:2013
ISO/DIS 10628-1
Diagrams for chemical and petrochemical industry — Part 1:
Specifications of diagrams
1 Scope
This standard specifies the classification, content and representation of flow diagrams. In addition, it lays
down rules for drafting flow diagrams for chemical and petrochemical industry.
This standard does not apply to electrical engineering flow diagrams. This standard is a collective application
standard of ISO 15519
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
ISO 128 (all parts), Technical drawings - General principles of presentation
ISO 3098-2:2000-11, Technical product documentation - Lettering - Part 2: Latin alphabet, numerals and
marks
ISO 5457:1999-02, Technical product documentation - Sizes and layout of drawing sheets
ISO 7200:2004-02, Technical product documentation – Data fields in title blocks and document headers
ISO 10209 (all parts), Technical product documentation; vocabulary
ISO 14617 (all parts), Graphical symbols for diagrams
ISO 15519 (all parts), Specification for diagrams for process industry
ISO 80000 (all parts), Quantities and units
ISO 80416-2:2001-07, Basic principles for graphical symbols for use on equipment - Part 2: Form and use of
arrows
IEC 62424:2008-08, Representation of process
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
