Tanks for the transport of dangerous goods - Metallic pressure tanks - Design and construction

This document specifies the minimum requirements for the design and construction of metallic pressure tanks having a maximum working pressure exceeding 50 kPa (0,5 bar), for the transport of dangerous goods by road and rail and sea. This document includes requirements for openings, closures and structural equipment; it does not cover requirements of service equipment. For tanks for the transport of cryogenic liquids, EN 13530 1 and EN 13530 2 apply.
Design and construction of pressure tanks according to the Scope of this document are primarily subject to the requirements of RID/ADR, Subsections 6.8.2.1, 6.8.3.1 and 6.8.5, as relevant. In addition, the relevant requirements of RID/ADR, Table A, columns 12 and 13, to Chapters 3.2, 4.3 and Subsection 6.8.2.4 apply. For the structural equipment RID/ADR, Subsections 6.8.2.2 and 6.8.3.2 apply, as relevant. The definitions of RID/ADR, Subsection 1.2.1, are referred to. For portable tanks see also RID/ADR, Chapter 4.2 and Sections 6.7.2 and 6.7.2. In addition, the relevant requirements of RID/ADR, Table A, Columns 10 and 11 to Chapters 3.2, 4.2, and Sections 6.7.2 and 6.7.3 apply. The paragraph numbers above relate to the 2017 issue of RID/ADR which are subject to regular revisions. This can lead to temporary non-compliances with EN 14025.
This document is applicable to liquefied gases including LPG; however for a dedicated LPG standard see EN 12493.
If not otherwise specified, provisions which take up the whole width of the page apply to all kind of tanks. Provisions contained in a single column apply only to:
tanks according to RID/ADR Chapter 6.8 (left-hand column);   portable tanks according to RID/ADR Chapter 6.7 (right-hand column).

Tanks für die Beförderung gefährlicher Güter - Metallische Drucktanks - Auslegung und Bau

Dieses Dokument legt die Mindestanforderungen für Auslegung und Bau von metallischen Drucktanks mit einem höchsten Betriebsdruck von mehr als 50 kPa (0,5 bar) für die Beförderung gefährlicher Güter auf der Straße, mit der Eisenbahn und mit Seeschiffen fest. Dieses Dokument enthält Anforderungen an Öffnungen, Verschlüsse und die bauliche Ausrüstung; Anforderungen an die Bedienungsausrüstung werden nicht behandelt. Für Tanks für die Beförderung von tiefkalten Flüssigkeiten gelten EN 13530-1 und EN 13530-2.
Auslegung und Bau von Drucktanks entsprechend dem Anwendungsbereich dieses Dokuments unterliegen im Wesentlichen den zutreffenden Vorschriften in RID/ADR, Unterabschnitte 6.8.2.1, 6.8.3.1 und 6.8.5. Zusätzlich gelten außerdem die zutreffenden Anforderungen nach RID/ADR, Tabelle A, Spalten 12 und 13, Kapitel 3.2, Kapitel 4.3 und Unterabschnitt 6.8.2.4. Für die bauliche Ausrüstung gelten RID/ADR, Unterabschnitt 6.8.2.2 bzw. Unterabschnitt 6.8.3.2. Auf die in RID/ADR, Unterabschnitt 1.2.1, enthaltenen Begriffsbestimmungen wird verwiesen. Zu ortsbeweglichen Tanks siehe auch RID/ADR, Kapitel 4.2, sowie Unterabschnitte 6.7.2 und 6.7.2. Darüber hinaus gelten die maßgeblichen Anforderungen von RID/ADR, Tabelle A, Spalten 10 und 11, Kapitel 3.2, Kapitel 4.2, sowie Unterabschnitte 6.7.2 und 6.7.3. Die oben angegebene Nummerierung der Abschnitte bezieht sich die Ausgaben der RID/des ADR von 2017, die regelmäßig überarbeitet werden. Daher kann es zu vorübergehenden Nichtübereinstimmungen mit EN 14025 kommen.
Dieses Dokument gilt auch für verflüssigte Gase einschließlich Flüssiggas (LPG); für eine dezidierte LPG-Norm siehe jedoch EN 12493.
Sofern nicht anders festgelegt, gelten die Festlegungen, die die gesamte Breite der Seite einnehmen, für alle Arten von Tanks. Festlegungen, die in nur einer Spalte enthalten sind, gelten ausschließlich für:
Tanks nach RID/ADR, Kapitel 6.8 (linke Spalte)   ortsbewegliche Tanks nach RID/ADR, Kapitel 6.7 (rechte Spalte)

Citernes pour le transport de matières dangereuses - Citernes métalliques sous pression - Conception et fabrication

Le présent document spécifie les prescriptions minimales pour la conception et la construction des citernes métalliques sous pression ayant une pression maximale de service supérieure à 50 kPa (0,5 bar) et utilisées pour le transport de marchandises dangereuses par route, par chemin de fer et par mer. Le présent document inclut les exigences relatives aux ouvertures, fermetures et équipements de structure ; il ne couvre pas les exigences relatives aux équipements de service. Pour les citernes destinées au transport de liquides cryogéniques, les normes EN 13530-1 et EN 13530-2 s’appliquent.
La conception et la construction des citernes sous pression conformes au domaine d’application du présent document sont principalement soumises aux exigences des sous-sections 6.8.2.1, 6.8.3.1 et 6.8.5 du RID/ADR, selon le cas. En outre, les prescriptions pertinentes en colonnes 12 et 13 du tableau A du chapitre 3.2, au chapitre 4.3 et à la sous-section 6.8.2.4 du RID/ADR s’appliquent. Pour les équipements de structure RID/ADR, les sous-sections 6.8.2.2 et 6.8.3.2 s’appliquent, selon le cas. Les définitions de la sous-section 1.2.1 du RID/ADR s’appliquent. Pour les citernes mobiles, voir également le chapitre 4.2 et les sections 6.7.2 et 6.7.2 du RID/ADR. En outre, les prescriptions pertinentes en colonnes 10 et 11 du tableau A du chapitre 3.2, au chapitre 4.2 et aux sections 6.7.2 et 6.7.3 du RID/ADR s’appliquent. Les numéros de paragraphe donnés ci-dessus se rapportent aux versions 2017 du RID/ADR, qui font régulièrement l’objet de révisions. Cela peut conduire à une non-conformité temporaire à l’EN 14025.
Le présent document s’applique aux gaz liquéfiés, dont le GPL. Pour une norme dédiée au GPL, se reporter toutefois à l’EN 12493.
Sauf indication contraire, les dispositions qui occupent toute la largeur de la page s’appliquent à tous les types de citernes. Les dispositions qui n’occupent qu’une colonne s’appliquent uniquement aux :
citernes conformément au chapitre 6.8 du RID/ADR (colonne de gauche) ;   citernes mobiles conformément au chapitre 6.7 du RID/ADR (colonne de droite).

Cisterne za prevoz nevarnega blaga - Kovinske tlačne posode - Konstruiranje in izdelava

Ta evropski standard določa minimalne zahteve za konstruiranje in izdelavo kovinskih tlačnih posod z najvišjim delovnim ali preskusnim tlakom nad 50 kPa (0,5 bara) za prevoz nevarnega blaga po cesti, železnici in morju. Ta evropski standard zajema zahteve za odprtine, zaključke in strukturno opremo; ne vključuje zahtev za obratovalno opremo. Za posode za prevoz kriogenih tekočin se uporabljata standarda EN 13530-1 in EN 13530-2.
OPOMBA 1:   Za zasnovo in izdelavo tlačnih posod v skladu s področjem uporabe tega evropskega standarda se prvotno uporabljajo zahteve določb RID/ADR, točke 6.8.2.1, 6.8.3.1 in 6.8.5, kot je ustrezno. Poleg tega veljajo ustrezne zahteve določb RID/ADR, stolpca 12 in 13 preglednice A za poglavja 3.2, 4.3 in 6.8.2.4. Za strukturno opremo se uporabljata pododdelka 6.8.2.2 in 6.8.3.2. Navedene so definicije določbe RID/ADR 1.2.1. Za prenosne posode glejte tudi poglavje 4.2, oddelka 6.7.2 in 6.7.3 določb RID in ADR. Poleg tega veljajo ustrezne zahteve določb RID/ADR, stolpca 10 in 11 preglednice A za poglavja 3.2, 4.2, 6.7.2 in 6.7.3. Zgornje številke odstavkov veljajo za izdajo RID/ADR iz leta 2013 in so predmet rednih revizij. To lahko povzroči začasno neskladnost s standardom EN 14025. Upoštevati je treba, da imajo zahteve RID/ADR prednost pred katero koli točko tega standarda.
OPOMBA 2:   Ta standard se uporablja za utekočinjene pline, vključno z utekočinjenim naftnim plinom (LPG), vendar za ustrezni standard za LPG glej EN 12493.
Če ni navedeno drugače, se določbe, ki so navedene na celotni širini strani, uporabljajo za vse vrste posod. Določbe v posameznih stolpcih se uporabljajo samo za:
– cestne in železniške tlačne posode v skladu s poglavjem RID/ADR 6.8 (stolpec na levi strani);   – prenosne posode v skladu s poglavjem RID/ADR 6.7 (stolpec na desni strani).
