EN ISO 5771:2024

Rubber hoses and hose assemblies for transferring anhydrous ammonia - Specification (ISO 5771:2024)

This document specifies the minimum requirements for rubber hoses used for transferring ammonia, in liquid or in gaseous form, at ambient temperatures from −40 °C up to and including +55 °C at a working pressure of 2,5 MPa (25 bar). It does not include specifications for end fittings and is limited to the performance of the hoses and hose assemblies.

Gummischläuche und -schlauchleitungen für den Transport von wasserfreiem Ammoniak - Anforderungen (ISO 5771:2024)

Dieses Dokument legt Mindestanforderungen an Gummischläuche fest, die bei Umgebungstemperaturen zwischen −40 °C und +55 °C bei einem Betriebsdruck von 2,5 MPa (25 bar) zum Transport von flüssigem oder gasförmigen Ammoniak verwendet werden. Nicht eingeschlossen sind Anforderungen an Armaturen; die Norm gilt nur für Schläuche und Schlauchleitungen.
WARNUNG   Anwender dieses Dokuments sollten mit der üblichen Laborpraxis vertraut sein. Dieses Dokument erhebt nicht den Anspruch, dass alle mit seiner Anwendung verbundenen Sicherheitsprobleme, soweit diese gegeben sind, angesprochen werden. Es liegt in der Verantwortung des Anwenders, angemessene Sicherheits- und Schutzmaßnahmen zu treffen und sämtliche anwendbare nationale Festlegungen zu bestimmen.
ACHTUNG   Das gesamte Personal, das mit wasserfreiem Ammoniak und seinen Liefersystemen arbeitet, sollte im Umgang damit vertraut sein und notwendige Sicherheitsanweisungen befolgen um die Gefahr für Personen- und Sachschäden zu minimieren. Schlauchleitungen für die Verwendung mit wasserfreiem Ammoniak nicht bei Temperaturen und Drücken oberhalb der vom Schlauchhersteller empfohlenen Temperaturen und Drücke benutzen. Niemals einen Schlauch für wasserfreies Ammoniak abkuppeln. Schläuche, die nach dieser Spezifikation hergestellt werden, sind nur für den Gebrauch mit wasserfreiem Ammoniak zu verwenden.

Tuyaux et flexibles en caoutchouc pour le transfert d'ammoniac anhydre - Spécifications (ISO 5771:2024)

Le présent document spécifie les exigences minimales relatives aux tuyaux en caoutchouc utilisés pour le transfert d'ammoniac sous forme gazeuse ou sous forme liquide à des températures ambiantes de −40 °C à +55 °C compris à une pression de service de 2,5 MPa (25 bar). Il ne contient pas de spécifications relatives aux extrémités de raccordement et se limite à la performance des tuyaux et des assemblages flexibles.
